Cartoni P70 Steering Pedestal with Focus 22 Fluid Head, 2x Pan Bars, 100mm Adapter & Pump

SKU: CCP70SF22 MFR: KP7SF22
Earn VIP Reward Points

Key Features

  • Achieve smooth, professional shots with the Cartoni P70 steering pedestal's fluid head.
  • Enjoy precise control with continuous fluid drag and counterbalance for your camera work.
  • The robust pedestal supports up to 165.3 lbs, ensuring stability for heavy camera setups.
  • Quickly adjust your camera height from 31.5" to 49.2" with the easy-to-use pedestal system.
  • Navigate tight spaces with a doorway tracking width of 17.7" to 31.9" using this pedestal.
  • This durable camera stand kit includes a 5-year warranty on the fluid head for peace of mind.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$229.99

3 Year

$274.99

4 Year

$369.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Cartoni P70 + Focus 22 Specifications

P70 Steering Pedestal

P70 Steering Pedestal

Jump to...
  • Maximum Pressure

    9.0 atm
    132.3 psi

  • On-Shot Stroke

    45

  • Doorway Tracking Width

    Minimum: 17.7" (45cm)
    Maximum: 31.9" (81cm)

  • Payload Capacity

    165.3 lb (75kg)

  • Wheel Diameter

    4.9" (12.5cm)

  • Height

    Minimum: 31.5" (80cm)
    Maximum: 49.2" (125cm)

  • Weight

    99.2 lb (45kg)

Focus 22 Fluid Head

Jump to...
  • Payload Capacity

    Minimum: 7 lb (3kg)
    Maximum: 49 lb (22kg)

  • Bowl Diameter

    100 mm

  • Fluid Drag

    Continuous

  • Counterbalance

    Continuous

  • Pan Range

    360 Degree

  • Tilt Range

    +/-90 Degree

  • Temperature Range

    -40 to 140 Degree F (-40 to 60 Degree C)

  • Weight

    8.6 lb (3.9kg)

About Cartoni P70 + Focus 22

Be at the forefront of professional photography and videography with the P70 Steering Pedestal and Focus 22 Fluid Head. This high-quality, durable system is a new and improved version of the bestselling P70, offering a compact and portable steering solution for both studio and outdoor broadcasting (OB) applications.

The P70 Steering Pedestal is renowned for its super-smooth drive, making it an ideal companion for easy travelling. Despite its lightweight design, it provides exceptional stability, delivering superior performance with any camera or lens combination up to 75 Kg (165 lbs).

The air-filled, "on-shot" column is not only fast but also safe to operate. It works with Nitrogen or clean compressed air, which can be loaded with any compressor or a simple hand pump. A safety air pressure valve is included to prevent the risk of air overpressure.

The innovative column design of the P70 Steering Pedestal offers outstanding stability and jerk-free control, ensuring smooth and precise movements. The sturdy dolly is equipped with three sets of double 12.5 cm (4.9 in.) diameter heavy-duty wheels, individually lockable and cast with an innovative bi-component polyurethane mix for enhanced steering.

The Focus 22 Fluid Head is specifically designed to support a wide variety of new Electronic News Gathering (ENG) cameras. Compact yet fully accessorized, it features the patented CARTONI "wing" continuously adjustable counterbalance. With its broad range of payloads - 3 kg (6.5 lbs) to 22 kg (48.5 lbs) - the Focus 22 is the perfect partner for all news gathering and outdoor shooting jobs.

The Fluid Head is rugged yet easy to operate, with all the ergonomic settings placed conveniently. Fluid drag in both pan and tilt feature the distinctive renowned CARTONI patented infinitely adjustable labyrinth system. It comes with positive locks, a wide range sliding platform incorporating the European style quick release plate, and a switchable illuminated spirit level.

The Focus 22 Fluid Head weighs only 3.9 kg (8.6 lbs) thanks to the extensive use of extremely lightweight magnesium alloys. It interfaces with all 100 mm bowl base tripods, making it a versatile addition to your photography and videography equipment.

In conclusion, the P70 Steering Pedestal with Focus 22 Fluid Head, 2x Pan Bars, 100mm Adapter & Pump is a professional, high-quality, and durable solution for all your filming needs.

Cartoni P70 + Focus 22 Features

  • High-quality P70 Steering Pedestal with super-smooth drive for easy travelling and versatile application
  • Durable Focus 22 Fluid Head designed to support a wide variety of new ENG cameras
  • Innovative air-filled, "on-shot" column for fast and safe operation, compatible with Nitrogen or clean compressed air
  • Sturdy dolly equipped with lockable heavy-duty wheels for enhanced steering and stability
  • Patented CARTONI "wing" continuously adjustable counterbalance and labyrinth system for precise control
  • Lightweight design with extensive use of magnesium alloys, compatible with all 100 mm bowl base tripods

Warranty Information

This product has a limited warranty of 60 months for parts and 36 months for labor.

Key Features

  • Achieve smooth, professional shots with the Cartoni P70 steering pedestal's fluid head.
  • Enjoy precise control with continuous fluid drag and counterbalance for your camera work.
  • The robust pedestal supports up to 165.3 lbs, ensuring stability for heavy camera setups.
  • Quickly adjust your camera height from 31.5" to 49.2" with the easy-to-use pedestal system.
  • Navigate tight spaces with a doorway tracking width of 17.7" to 31.9" using this pedestal.
  • This durable camera stand kit includes a 5-year warranty on the fluid head for peace of mind.

What's in the box:

  • P70 Steering Pedestal
  • Focus 22 Fluid Head
  • 2x Pan Bars
  • 100 Adapter
  • Pump
  • Cartoni 5 Year Limited Warranty (3 Years + 2 Years with Registration) for Fluid Head
  • Cartoni 1 Year Limited Warranty for Other Kit Contents
