Cartoni P70 Steering Pedestal with Master MK2 Fluid Head, 2x Pan Bars, Flat Base Adapter & Pump

SKU: CCP70SMA1 MFR: P70SMA1
Earn VIP Reward Points

Key Features

  • Achieve smooth, professional shots with this Cartoni pedestal's precise steering.
  • Enjoy versatile camera support with the Master MK2 fluid head, up to 77 lb payload.
  • Get creative: This camera stand offers a wide 360° pan range for dynamic filming.
  • Rely on the durable Cartoni P70 pedestal for stable, on-shot strokes up to 45".
  • Easily adjust your camera height from 31.5" to 49.2" with this adjustable pedestal.
  • Trust in Cartoni's quality: Get a 5-year warranty on the Master MK2 fluid head.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What type of cameras can the P70 Steering Pedestal and Master MK2 Fluid Head support?

The P70 Steering Pedestal and Master MK2 Fluid Head can support a wide range of cameras, from the smallest HDV camera to fully loaded RED, Alexa, F65, C300 cameras, and more. It can handle camera and lens combinations up to 75 Kg (165 lbs).

What is the 'on-shot' column in the P70 Steering Pedestal?

The 'on-shot' column in the P70 Steering Pedestal is an air-filled column that operates quickly and safely. It uses either Nitrogen or clean compressed air, which can be loaded with any compressor or a simple hand pump included with the product.

What are the features of the Master MK2 Fluid Head?

The Master MK2 Fluid Head is designed specifically for HD, Film, ENG, and EFP camera systems. It features a frictionless variable fluid module for a wide range of fluid drag, digital readouts for drag and counterbalance settings, an illuminated spirit level, and a quick-release sliding camera plate. It has a flat Mitchell standard base and an available 150mm bowl converter.

What makes the P70 Steering Pedestal user-friendly?

The P70 Steering Pedestal is designed with user-friendly ergonomics in mind. All operating knobs and levers are conveniently located and easy to reach. The system also includes adjustable cable guards and a manual air pump.

How does the P70 dolly enhance steering and movement?

The P70 dolly features three sets of double 12.5 cm diameter heavy-duty wheels, each individually lockable. These wheels are cast with a bi-component polyurethane mix for enhanced steering. An advanced design chain ensures accurate traveling in crab position, even 'on shot'.

Reviews about this item

Review Summary

Cartoni P70 + Master MK2 Specifications

P70 Steering Pedestal

P70 Steering Pedestal

Jump to...
  • Maximum Pressure

    9.0 atm
    132.3 psi

  • On-Shot Stroke

    45

  • Doorway Tracking Width

    Minimum: 17.7" (45cm)
    Maximum: 31.9" (81cm)

  • Payload Capacity

    165.3 lb (75kg)

  • Wheel Diameter

    4.9" (12.5cm)

  • Height

    Minimum: 31.5" (80cm)
    Maximum: 49.2" (125cm)

  • Weight

    99.2 lb (45kg)

Master MK2 Fluid Head

Jump to...
  • Payload Capacity

    Minimum: 11 lb (5kg)
    Maximum: 77 lb (35kg)

  • Bowl Diameter

    Flat

  • Fluid Drag

    Continuous

  • Counterbalance

    Continuous

  • Pan Range

    360 Degree

  • Tilt Range

    +/-90 Degree

  • Temperature Range

    -40 to 140 Degree F (-40 to 60 Degree C)

  • Weight

    18.7 lb (8.5kg)

About Cartoni P70 + Master MK2

With the Cartoni P70 Steering Pedestal and Master MK2 Fluid Head, you're investing in a professional-grade, high-quality camera support system that's both durable and versatile. This updated version of the best-selling P70 is a compact, portable steering system designed for a variety of studio and OB applications. Its super-smooth drive ensures easy traveling, while its lightweight yet sturdy construction can support camera and lens combinations up to 75 Kg (165 lbs).

The P70's air-filled, "on-shot" column operates quickly and safely, using either Nitrogen or clean compressed air. This can be loaded with any compressor or the included manual hand pump. A safety air pressure valve eliminates the risk of overpressure, while the innovative column design offers exceptional stability, jerk-free control, and precise movements.

The robust P70 dolly features three sets of double 12.5 cm (4.9 in.) diameter heavy-duty wheels, each individually lockable. The wheels are cast with a bi-component polyurethane mix for enhanced steering. An advanced design chain ensures accurate traveling in crab position, even "on shot". The system is compatible with all flat base, 4-bore hole heads or any other bowl-based head with an adapter.

The Master MK2 Fluid Head is Cartoni's ultimate fluid head, designed specifically for HD, Film, ENG, and EFP camera systems. It can counterbalance cameras from 3 Kg (6.6 lbs) to 35 Kg (77 lbs), making it suitable for everything from the smallest HDV camera to fully loaded RED, Alexa, F65, C300 cameras, and more. The frictionless variable fluid modules offer a wide range of fluid drag for smooth and precise movement in any shooting situation. All operating knobs and levers are conveniently located for user-friendly ergonomics. The Master MK2 comes equipped with one telescopic pan bar, a standard quick-release sliding camera plate, an illuminated spirit level, and digital readouts for drag and counterbalance settings. It has a flat Mitchell standard base and an available 150mm bowl converter, making it suitable for all leg options and dollies.

Cartoni P70 + Master MK2 Features

  • High-quality P70 Steering Pedestal and Master MK2 Fluid Head, designed for professional film and video production
  • Durable and versatile system, supporting camera and lens combinations up to 75 Kg (165 lbs)
  • Features air-filled, "on-shot" column for fast and safe operation, with included manual hand pump
  • Robust P70 dolly with individually lockable, heavy-duty wheels for enhanced steering and precise movement
  • Master MK2 Fluid Head designed for a wide range of cameras, from HDV to fully loaded RED, Alexa, F65, C300, and more
  • User-friendly ergonomics with conveniently located operating knobs and levers, digital readouts, and an illuminated spirit level

Warranty Information

This product has a limited warranty of 60 months for parts and 36 months for labor.

Key Features

  • Achieve smooth, professional shots with this Cartoni pedestal's precise steering.
  • Enjoy versatile camera support with the Master MK2 fluid head, up to 77 lb payload.
  • Get creative: This camera stand offers a wide 360° pan range for dynamic filming.
  • Rely on the durable Cartoni P70 pedestal for stable, on-shot strokes up to 45".
  • Easily adjust your camera height from 31.5" to 49.2" with this adjustable pedestal.
  • Trust in Cartoni's quality: Get a 5-year warranty on the Master MK2 fluid head.

What's in the box:

  • P70 Steering Pedestal
  • Master MK2 Fluid Head
  • 2x Pan Bars
  • Flat Base Adapter
  • Pump
  • Cartoni 5 Year Limited Warranty (3 Years + 2 Years with Registration) for Fluid Head
  • Cartoni 1 Year Limited Warranty for Other Kit Contents
