Cartoni P70 Steering Pedestal with Master 40 Fluid Head, Dovetail Wedge Plate, 2x Pan Bars, Flat Base Adapter & Pump

SKU: CCP70SMA4 MFR: KP7SMA4
Earn VIP Reward Points

Key Features

  • Achieve smooth, professional camera movements with this Cartoni steering pedestal system.
  • Enjoy precise control with the Master 40 fluid head, perfect for cinematic shots and broadcasts.
  • Supports up to 88 lb (40kg) with the fluid head, ideal for various camera and lens setups.
  • Easily adjust height from 31.5" to 49.2" using the P70 pedestal for dynamic perspectives.
  • The robust pedestal supports up to 165.3 lb (75kg), ensuring stability for heavy cameras.
  • Navigate tight spaces with the adjustable doorway tracking width on this versatile pedestal.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Cartoni P70 + Master 40 Specifications

P70 Steering Pedestal

P70 Steering Pedestal

Jump to...
  • Maximum Pressure

    9.0 atm
    132.3 psi

  • On-Shot Stroke

    45

  • Doorway Tracking Width

    Minimum: 17.7" (45cm)
    Maximum: 31.9" (81cm)

  • Payload Capacity

    165.3 lb (75kg)

  • Wheel Diameter

    4.9" (12.5cm)

  • Height

    Minimum: 31.5" (80cm)
    Maximum: 49.2" (125cm)

  • Weight

    99.2 lb (45kg)

Master 40 Fluid Head

Jump to...
  • Payload Capacity

    Maximum: 88 lb (40kg)

  • Bowl Diameter

    Flat

  • Fluid Drag

    Continuous

  • Counterbalance

    Continuous

  • Pan Range

    360 Degree

  • Tilt Range

    +/-90 Degree

  • Temperature Range

    -40 to 140 Degree F (-40 to 60 Degree C)

  • Weight

    33.1 lb (15kg)

About Cartoni P70 + Master 40

Enhance your professional video and photography setup with the P70 Steering Pedestal coupled with the Master 40 Fluid Head, a premium combination designed for the utmost in stability and fluid motion. The upgraded P70 Steering Pedestal is a testament to Cartoni's commitment to innovation, offering a portable and compact steering system that excels in both studio and outdoor broadcast (OB) applications. Its super-smooth drive ensures effortless traveling shots, while the air-filled, "on-shot" column allows for rapid and secure height adjustments. Compatible with Nitrogen or clean compressed air, the system can be charged with any standard compressor or the included manual air pump. A safety air pressure valve is integrated to mitigate the risk of overpressure, ensuring safe operation at all times.

The P70's column design is a marvel of engineering, delivering unparalleled stability and jerk-free control, guaranteeing smooth and precise movements. The robust dolly features three sets of double 12.5 cm (4.9 in.) diameter wheels, each lockable and crafted from a cutting-edge bi-component polyurethane mix, enhancing steering responsiveness. The advanced chain design facilitates accurate crab position traveling, even during live shots. This versatile system is compatible with all flat base, 4-bore hole heads, or any other bowl-based head with an adapter, making it a sturdy and versatile choice for a wide array of camera setups. Additional features include a removable foot bar, 4x500 gr. (4x1.1 lbs) counterweights, adjustable cable guards, and a manual air pump for complete control over your filming environment.

The Master 40 Fluid Head is the pinnacle of support for broadcast camera configurations, accommodating up to 40 kg (88 lbs). It boasts a patented counterbalance system that ensures smooth operation and a fluid drag system that is both thin and robust. The Master 40's controls are thoughtfully positioned for ergonomic use, allowing camera operators to work comfortably in any setting. The digital display monitors drag and counterbalance settings, providing precise feedback for the operator. The payload capacity ranges from zero to 40 kg (88 lbs), maintaining perfect balance throughout the entire 180-degree tilt range. The continuous Fluid Drag System offers a spectrum of resistance, from near freewheeling to highly consistent drag, adding to the head's versatility. It also features a V wedge plate and a wide sliding platform for optimal camera centering. The Master 40 Fluid Head is built to be rugged and precise, setting a new industry standard for professional camera support systems.

With the combination of the P70 Steering Pedestal and Master 40 Fluid Head, professional videographers and photographers can expect a high-quality, durable, and versatile system that enhances the production value of their work. Whether in the studio or on location, this system provides the stability and control needed for capturing exceptional footage.

Cartoni P70 + Master 40 Features

  • High-quality P70 Steering Pedestal and Master 40 Fluid Head combo for professional video and photography
  • Advanced, air-filled "on-shot" column for rapid and secure height adjustments
  • Versatile compatibility with all flat base, 4-bore hole heads or any bowl-based head with an adapter
  • Master 40 Fluid Head supporting broadcast camera configurations up to 40 kg (88 lbs)
  • Continuous fluid drag system, offering a range of resistance for maximum versatility
  • Robust and precise construction, setting a new industry standard for camera support systems

Warranty Information

This product has a limited warranty of 60 months for parts and 36 months for labor.

Key Features

  • Achieve smooth, professional camera movements with this Cartoni steering pedestal system.
  • Enjoy precise control with the Master 40 fluid head, perfect for cinematic shots and broadcasts.
  • Supports up to 88 lb (40kg) with the fluid head, ideal for various camera and lens setups.
  • Easily adjust height from 31.5" to 49.2" using the P70 pedestal for dynamic perspectives.
  • The robust pedestal supports up to 165.3 lb (75kg), ensuring stability for heavy cameras.
  • Navigate tight spaces with the adjustable doorway tracking width on this versatile pedestal.

What's in the box:

  • P70 Steering Pedestal
  • Master 40 Fluid Head
  • Dovetail Wedge Plate
  • 2x Pan Bars
  • Flat Base Adapter
  • Pump
  • Cartoni 5 Year Limited Warranty (3 Years + 2 Years with Registration) for Fluid Head
  • Cartoni 1 Year Limited Warranty for Other Kit Contents
