Cartoni P70 Steering Pedestal with Master 65 Fluid Head, Dovetail Plate, 2x Pan Bars, Flat Base Adapter & Pump

SKU: CCP70SMA6 MFR: KP7SMA6
Earn VIP Reward Points

Key Features

  • Achieve smooth, professional shots with this Cartoni steering pedestal, perfect for studio use.
  • Enjoy precise control with the Master 65 fluid head, supporting cameras up to 176 lbs.
  • The adjustable height of this camera stand allows for versatile shooting positions on set.
  • Get creative with 360-degree pan and +/-65-degree tilt range for dynamic camera movements.
  • Durable build ensures stability; this robust pedestal supports up to 165.3 lbs payload.
  • Portable design with smooth-rolling wheels makes moving between sets a breeze.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

Qty
1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Cartoni P70 + Master 65 Specifications

P70 Steering Pedestal

P70 Steering Pedestal

Jump to...
  • Maximum Pressure

    9.0 atm
    132.3 psi

  • On-Shot Stroke

    45

  • Doorway Tracking Width

    Minimum: 17.7" (45cm)
    Maximum: 31.9" (81cm)

  • Payload Capacity

    165.3 lb (75kg)

  • Wheel Diameter

    4.9" (12.5cm)

  • Height

    Minimum: 31.5" (80cm)
    Maximum: 49.2" (125cm)

  • Weight

    99.2 lb (45kg)

Master 65 Fluid Head

Jump to...
  • Payload Capacity

    Minimum: 44 lb (20kg)
    Maximum: 176 lb (80kg)

  • Bowl Diameter

    Flat base

  • Fluid Drag

    Continuous

  • Counterbalance

    Continuous

  • Pan Range

    360 Degree

  • Tilt Range

    +/-65 Degree

  • Temperature Range

    -40 to 140 Degree F (-40 to 60 Degree C)

  • Weight

    35.3 lb (16kg)

About Cartoni P70 + Master 65

Experience the superior performance of the P70 Steering Pedestal with Master 65 Fluid Head, a versatile and robust solution for your filming and photography needs. This upgraded version of the popular P70 is a compact and portable steering system, designed for both studio and OB applications. It offers a smooth drive for easy traveling, making it an ideal choice for professionals on the go.

The P70 Steering Pedestal is renowned for its exceptional stability, despite its lightweight design. It can handle any camera or lens combination up to 75 Kg (165 lbs), making it a versatile choice for a range of shooting scenarios. The air-filled, "on-shot" column operates quickly and safely, using Nitrogen or clean compressed air, which can be loaded with any compressor or a simple hand pump. A safety air pressure valve ensures safe operation by preventing air overpressure.

The innovative column design of the P70 Steering Pedestal offers jerk-free control, outstanding stability, and precise movements. The robust dolly is equipped with three sets of double 12.5 cm (4.9 in.) diameter heavy-duty wheels, individually lockable and cast with a bi-component polyurethane mix for enhanced steering. An advanced design chain ensures accurate traveling in crab position even "on shot". The system is compatible with all flat base, 4-bore hole heads or any other bowl-based head with an adapter.

The Master 65 Fluid Head is designed to support camera weights from 20 Kg (44 lbs) to 65 Kg (143 lbs), making it ideal for outdoor broadcasting with bulky boxed lenses. It offers a wide range of counterbalance capabilities, ensuring perfect balance at any tilt angle. The new Cartoni Fluid drag system, based on silicon film, provides smooth and slow movements with long focal lengths. The head comes equipped with a standard Dovetail platform on a large sliding platform, with micrometric movements operated by a handy crank placed under the slide. All settings are ergonomically placed for ease of use. The Master 65 Fluid Head is compatible with the Vinten attachment and comes equipped with a digital readout for counterbalance reference and an illuminated spirit bubble. It interfaces with Mitchel mount tripods, pedestals, and other supports via a 4-bolt fixing system, 2 3/4" castle-nut, or a M12 threaded central knob.

In conclusion, the P70 Steering Pedestal with Master 65 Fluid Head, Dovetail Plate, 2x Pan Bars, Flat Base Adapter & Pump is a durable, high-quality, and professional choice for all your filming and photography needs.

Cartoni P70 + Master 65 Features

  • Versatile P70 Steering Pedestal with Master 65 Fluid Head, designed for both studio and OB applications
  • Lightweight yet sturdy design, capable of supporting camera/lens combinations up to 75 Kg (165 lbs)
  • Innovative air-filled, "on-shot" column for fast and safe operation, compatible with Nitrogen or clean compressed air
  • Equipped with three sets of double 12.5 cm (4.9 in.) diameter heavy-duty wheels for enhanced steering
  • Master 65 Fluid Head supports camera weights from 20 Kg (44 lbs) to 65 Kg (143 lbs), perfect for outdoor broadcasting
  • Comes with a standard Dovetail platform on a large sliding platform, providing smooth and slow movements with long focal lengths

Warranty Information

This product has a limited warranty of 60 months for parts and 36 months for labor.

Key Features

  • Achieve smooth, professional shots with this Cartoni steering pedestal, perfect for studio use.
  • Enjoy precise control with the Master 65 fluid head, supporting cameras up to 176 lbs.
  • The adjustable height of this camera stand allows for versatile shooting positions on set.
  • Get creative with 360-degree pan and +/-65-degree tilt range for dynamic camera movements.
  • Durable build ensures stability; this robust pedestal supports up to 165.3 lbs payload.
  • Portable design with smooth-rolling wheels makes moving between sets a breeze.

What's in the box:

  • P70 Steering Pedestal
  • Master 65 Fluid Head
  • Dovetail Plate
  • Telescopic Left Pan Bar
  • Short Right Pan Bar
  • Flat Base Adapter
  • Pump
  • Cartoni 5 Year Limited Warranty (3 Years + 2 Years with Registration) for Fluid Head
  • Cartoni 1 Year Limited Warranty for Other Kit Contents
