Cinegears Wireless Prime 4K HDMI 4-Set Kit

SKU: CG5319 MFR: 5-319
Earn VIP Reward Points

Key Features

  • Experience reliable connection with this Cinegears wireless video transmitter & receiver kit.
  • Achieve high resolution 4K HDMI video transmission up to 200m with low latency.
  • Enjoy easy setup with this compact size wireless broadcast equipment for any event.
  • Control your devices remotely using the included IR transmitter and IR receiver set.
  • This wireless prime kit supports a wide range of resolutions, up to 4Kx2K@30Hz.
  • Rely on this wireless video transmitter for long range, stable signal for your needs.
See More Product Details
FREE 2-Day Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$59.99

2 Year

$99.99

3 Year

$149.00

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Cinegears Wireless Prime Specifications

  • HDMI Signal

    Fully compatible with HDCP

  • Transport Protocol

    HDbitT

  • Supported Resolution

    480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz, 4Kx2K@30Hz/24Hz/25Hz

  • IR Remote Control

    Supports 20-60kHz wide frequency IR remote device

  • Transmission Distance

    200m at 4Kx2K@30Hz

  • Working Temperature

    32 Degree F - 140 Degree F (0 Degree C - 60 Degree C)

  • Power Supply

    DC5V/3.5A

  • Power Consumption

    TX: <15W
    RX: <15W

  • Material

    Metal

  • Dimensions (L x W x H)

    7.6 x 5.3 x 1.2" (195 x 137 x 32mm)

  • Weight

    TX: 19.7 oz (560g)
    RX: 19.7 oz (560g)

  • UPC Code

    714983521888

About Cinegears Wireless Prime

After eliminating the hassle of tangled wires, enjoy the freedom of streaming digital content seamlessly on any screen with the Cinegears Wireless Prime 4K HDMI 4-Set Kit. This plug-and-play system can be effortlessly set up in mere minutes, offering an impressive wireless broadcast range of up to 200 meters.

Designed to deliver high-quality, low-latency broadcasts, the Wireless Prime is 4K ready, ensuring you experience the best in visual quality. Say goodbye to the days of routing video cables around corners and embrace the convenience of a wireless setup.

With the built-in infrared pass-through capabilities, you can remotely control your playback, adding an extra layer of convenience to your viewing experience. The Cinegears Wireless Prime comes complete with everything you need for a wireless broadcast right out of the box.

Ideal for a variety of applications, it's perfect for home and office use, video conferencing, security camera systems, digital signage, and much more. Showcasing wide-ranging compatibility, it works seamlessly with Blu-Ray, PC, Mac, Apple TV, PS4, Xbox One, WiiU, Nintendo Switch, and many other devices. Experience the future of wireless broadcasting with the Cinegears Wireless Prime 4K HDMI 4-Set Kit.

Cinegears Wireless Prime Features

  • Wirelessly transmits HDMI signal up the 200 meters (656')
  • Supports resolutions up to 4kx2k@30Hz
  • Supports up to 7.1 HD surround sound
  • Pairing encryption protects your signal
  • Plug & Play operation, no set-up or software required
  • Supports IR wide frequency range 20kHz-60kHz
  • Encrypted Wireless Video Transmission
  • Supports IR pass-back function, control your playback device remotely
  • Use multiple Wireless Prime Kits with no interference between
  • HDMI1.4, HDCP1.4

Warranty Information

This product has a limited warranty of 36 months for parts and 36 months for labor.

Key Features

  • Experience reliable connection with this Cinegears wireless video transmitter & receiver kit.
  • Achieve high resolution 4K HDMI video transmission up to 200m with low latency.
  • Enjoy easy setup with this compact size wireless broadcast equipment for any event.
  • Control your devices remotely using the included IR transmitter and IR receiver set.
  • This wireless prime kit supports a wide range of resolutions, up to 4Kx2K@30Hz.
  • Rely on this wireless video transmitter for long range, stable signal for your needs.

What's in the box:

  • Wireless Prime Receiver
  • Wireless Prime Transmitter
  • 4x High Power Antennas
  • 2x Power Supply
  • IR Transmitter and IR Receiver Set
  • Cinegears 3 Year Limited Warranty
