About Cinegears Ghost-Eye 700M
The Cinegears Ghost-Eye 700M is at the cutting edge of wireless video and audio transmission technology. Providing maximum functionality with HDMI/SDI cross-compatibility, 10-bit color and SDI loop-out, the 700M now comes in a form more robust and powerful than its predecessors and its competitors. With the antennas, which are made of high grade porcelain, built into the receiver this impressive 700 meter range unit is now more compact than ever. The 700M features indictor lights on the side, allowing the user to sandwich the unit with a front and back mount. A further exciting new feature is the LED screen, which allows the user easier access to channel selection. The Ghost-Eye 700M is the new standard in the wireless video and audio transmission market.
FCC & IC Requirements
All Ghost-Eye transmitter and receiver devices comply with the Federal Communications Commission requirement and the Industry Canada Certification standard.
10-Bit 4:2:2 Video
Transmit uncompressed 1080p, 60fps video with any Ghost-Eye transmitter to a virtually unlimited number of simultaneous receivers.
lms Latency, 300mb/s
Never miss a frame; the broadcasting capacity of the Ghost-Eye wireless transmission protocols exceeds the maximum resolution!
Cross-Convertible
Each Ghost-Eye transmitter and receiver has both HDMI and SDI output/input, and features in-unit cross conversion; send via SDI and receive via HDMI, or vice versa!
X-Sync
All Ghost-Eye transmitter and receiver models are cross compatible; transmit videofrom 400M transmitters to 150M and 300M receivers and vice versa!
10 Selectable Channels
Each Ghost-Eye transmitter and receiver has maximum 10 frequency channels manual selection, Coexist with Wi-Fi.
Auto-Relink
Signals dropped due to interference or loss of line-of-sight are automatically re-connected within lms of the obstacle being removed.
Intuitive Signal
Small obstacles in the line-of-sight are accommodated with an adaptive signal logarithm, keeping your signal connected.
High Sensitivity
Antennas Omni-directional antennas broadcast your signal with integrity.
Cinegears Ghost-Eye 700M Features
- Zero Latency Wireless HD video and audio transmission over 700 meters
- Transmits 1080p resolution at up to 60fps with 10-bit 4:2:2 color
- HDMI/SDI Cross Conversion with SDI Loop-Out on Tx and RX
- Limited REC Start/Stop Functionality
- Fully supports 3G SDI type A and 3G SDI type B
- Unlimited number of Ghost-Eye Receivers
- Full cross-compatibility with other Ghost-Eye models
- Auto-relink once transmitter is carried back within range
- Powered by 2-Pin Lemo to D-Tap
- Receiver with built-in internal antennas
- Heavy duty casing with durable inset SDI ports to prevent damage
