CHAUVET DJ onAir IP Panel Min LED Soft Light, Black

SKU: CHONIRPMINIP MFR: ONAIRPANELMINIP
Earn VIP Reward Points

Key Features

  • Achieve perfect on-air visuals with this pro-grade LED soft light panel, offering superior sound quality.
  • This durable DJ light features an IP65 rating, perfect for temporary outdoor broadcasts and events.
  • Enjoy simple control with multiple DMX channels, making this DJ lighting easy to integrate into any setup.
  • Create stunning effects with independent color mixing and built-in automated programs for dynamic shows.
  • Experience exceptional value with a long-lasting LED light source, up to 50,000 hours of reliable use.
  • Easily connect using the Seetronic Powerkon IP65 for a secure and robust power connection every time.
See More Product Details
Special Order?Estimated to Ship: 09/16/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$139.99

3 Year

$184.99

5 Year

$339.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

CHAUVET DJ onAir IP Panel Min Specifications

Optical

Optical

Jump to...
  • Light source

    40 LEDs (tri-color RGB) 1.4 W, (150 mA), 50,000 hours life expectancy
    40 LEDs (WW) 0.50 W, (150 mA), 50,000 hours life expectancy

  • Color temperature (range)

    2800 to 8000 K

  • Color temperature (at max)

    6367 K

  • CRI (3200 K)

    94.9

  • Beam Angle

    94.9 Degree

  • Field Angle

    149.4 Degree

  • Lumens

    2573

  • Illuminance

    47 lux @ 5 m

  • Selectable PWM

    600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

Dynamic Effects

Jump to...
  • Dimmer

    Electronic

  • Shutter/Strobe

    Electronic

  • Strobe Rate

    0 to 27 Hz

  • Independent color mixing

    Yes

  • Color temperature presets

    Yes

  • Dimming modes

    4

  • Dim Curves

    4

  • Built-in automated programs

    Yes

Connections

Jump to...
  • Power connection

    Edison plug (local) to Seetronic Powerkon IP65

  • Power Input

    Seetronic Powerkon IP65
    28 VDC, 3-pin IP65 XLR

  • Cable Length

    Power: 5' (1.5m)

  • Software Connection

    USB

Control

Jump to...
  • Control Protocol

    CRMX, RDM

  • DMX Channels

    1, 3, 4, 5, 6, 8, 10, 11, 15

  • Modes/Personalities

    9 personalities (1, 3, 4, 5, 6, 8, 10, 11, 15Ch1)

Electrical

Jump to...
  • Input Voltage

    100 to 240 VAC, 50/60 Hz (auto-ranging)

  • Power and Current

    49 W, .419 A @ 120 V, 60 Hz
    52 W, .260 A @ 208 V, 60 Hz
    57 W, .246 A @ 230 V, 50 Hz

Certifications/Qualifications

Jump to...
  • Certifications / Qualifications

    CE, MET, FCC

  • IP Rating

    IP65, temporary outdoor use, with pressure equalizing M12 GORE valve

  • Temperature (Ambient)

    -4 Degree F to 113 Degree F (-20 Degree C to 45 Degree C)

Construction/Physical

Jump to...
  • Color

    Exterior: Black

  • Material

    Aluminum Alloy

  • Dimensions

    With PSU: 10 x 5.62 x 4.29" (254 x 143 x 109mm)
    Without PSU: 10 x 4.13 x 4.29" (254 x 105 x 109mm)

  • Weight

    With PSU: 6.2 lbs (2.9kg)
    Without PSU: 4.2 lbs (2kg)

  • UPC Code

    781462221409

About CHAUVET DJ onAir IP Panel Min

From the reputable brand Chauvet DJ comes the onAir IP Panel Min LED Soft Light, a compact, durable, and versatile lighting solution designed to withstand all elements, whether used indoors or outdoors. This full-spectrum LED soft light is perfect for on-location shoots or for fitting into tight studio spaces, thanks to its low-trim design.

The onAir Panel Min IP is renowned for its superior quality of white light, boasting high CRI/TLC and TM-30 scores. It features a smooth 16-bit dimming curve, +/- green adjustment, and an emulated redshift, allowing you to create the exact ambiance you're aiming for. With its ability to produce a pop of color and built-in customizable effects accessible from the onboard LED menu, this LED soft light is a reliable tool for photographers and videographers alike.

Switching mounting options is a breeze with the Ball Head Mount, which includes adapters for a Baby Pin Receiver or a threaded insert for attaching a clamp. The rugged build of this LED soft light includes a drop-in slot, designed to simplify the process of changing accessories.

The onAir IP Panel Min LED Soft Light is equipped with PWM, DMX, RDM, CRMX, Art-Net, sACN, and an onboard control option, ensuring it's ready for camera use. Its compact size enhances portability, and the main power supply can be removed for a 28 VDC input via a 3-pin XLR, allowing the fixture to be powered from an external battery pack. This feature adds increased flexibility, making it an ideal choice for all your remote lighting needs.

CHAUVET DJ onAir IP Panel Min Features

  • Full-spectrum LED mini soft light panel style fixture for broadcast, film, and special events
  • IP65 rating for all weather use indoors or out
  • Linear color temperature presets from 2800 K to 8000 K with high CRI and CQS
  • Virtual color wheel with color matched to popular gel colors
  • +/- Green adjustment and emulated red-shift via DMX or on-board control
  • RDM (Remote Device Management) and CRMX Wireless Control for added flexibility
  • Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
  • Completely silent operation for use in studio applications
  • Ultra-smooth 16-bit dimming curves and speeds to complement any lighting scheme
  • Easily switch mounting options from Clamp mount on a ball head to Baby Pin
  • Drop-in slot for accessories (sold separately)
  • Rugged design for years of rough use in the most extreme conditions
  • Easy to use on-board control with full access to all the features of the fixture without the need for a dedicated controller
  • USB port for fixture software updates
  • Compact design perfect for run-and-gun or indoor installation
  • 28 VDC power input via 3-pin XLR to power the fixture from an external battery pack

Warranty Information

This product has a limited warranty of 12 months for parts and 24 months for labor.

Key Features

  • Achieve perfect on-air visuals with this pro-grade LED soft light panel, offering superior sound quality.
  • This durable DJ light features an IP65 rating, perfect for temporary outdoor broadcasts and events.
  • Enjoy simple control with multiple DMX channels, making this DJ lighting easy to integrate into any setup.
  • Create stunning effects with independent color mixing and built-in automated programs for dynamic shows.
  • Experience exceptional value with a long-lasting LED light source, up to 50,000 hours of reliable use.
  • Easily connect using the Seetronic Powerkon IP65 for a secure and robust power connection every time.

What's in the box:

  • CHAUVET Professional onAir IP Panel Min LED Soft Light (Black)
  • Seetronic Powerkon IP65
  • Mounting Hardware
  • CHAUVET Professional 1 Year Limited Warranty
