CHAUVET Professional Ovation FD-105WW 230W Warm White LED Fresnel with powerCON Power Cord, 3069K Color Temperature

SKU: CHOVAFD205WW MFR: OVATIONFD205WW
Earn VIP Reward Points

Key Features

  • Experience superior lighting with the Ovation FD-205WW LED Fresnel spotlight, perfect for stage productions.
  • Achieve precise control with the motorized zoom feature, adjusting your LED spotlight from 20° to 72°.
  • Enjoy flicker-free operation for broadcast use with selectable PWM, enhancing your LED lighting setup.
  • Create stunning visuals with a high CRI of 96, ensuring accurate color rendering with this spotlight.
  • This durable Chauvet LED Fresnel features Neutrik powerCON, ensuring reliable power connectivity.
  • Customize your lighting with gel frame accessories, tailoring the spotlight's output for any event.
See More Product Details
Special Order?Estimated to Ship: 08/18/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$179.99

3 Year

$249.99

5 Year

$489.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

CHAUVET Professional Ovation FD-205WW Specifications

Optical

Optical

Jump to...
  • Light Source

    1 LEDs (WW) 230W, (2.5A), 3069 K, 50,000 hours life expectancy

  • Color Temperature Range

    3069K at full

  • CRI

    96

  • Beam Angle

    11 deg. to 53 deg.

  • Field Angle

    20 deg. to 72 deg.

  • Zoom Angle

    20 deg. to 72 deg.

  • Lumens

    At 20 deg. : 6414
    At 72 deg. : 9047

  • Illuminance

    At 20 deg. : 5678 lux at 5m
    At 72 deg. : 450 lux at 5m

  • Selectable PWM

    600Hz, 1,200Hz, 2,000Hz, 4,000Hz, 6,000Hz, 25,000Hz

Dynamic Effects

Jump to...
  • Dimmer

    Electronic or External Dimmer Rack

  • Shutter/Strobe

    Electronic

  • Zoom

    Motorized

  • Strobe Rate

    0 to 18Hz

  • Dim Modes

    5

  • Dim Curves

    4

Connections

Jump to...
  • Power Connection

    Edison (Local) plug to Neutrik powerCON

  • Power Input

    Neutrik powerCON

  • Power Output

    Neutrik powerCON

  • Data Connectors

    3- and 5-pin XLR

  • Cable Length

    Power: 5' (1.52m)

Control

Jump to...
  • Control Protocol

    DMX, RDM, Dimmer

  • DMX Channels

    1, 2 or 5

  • Modes/Personalities

    3 personalities (UNO, DOS, STD-P)

Electrical

Jump to...
  • Input Voltage

    120/230 VAC, 50/60Hz (switchable)

  • Power Linking

    8 units at 120 V; 16 units at 230 V

  • Power and Current

    182W, 1.52A at 120V, 60Hz
    188W, .819A at 230V, 50Hz

  • Breaker Size

    T3.15A, 250V

Certifications / Qualifications

Jump to...
  • Certifications / Qualifications

    CE, MET
    IP Rating: IP20, dry location
    Temperature (Ambient): -4 to 113 deg. F (-20 to 45 deg. C)

General

Jump to...
  • Accessory Holder/Gel Frame Size

    7.5" (190.50mm)

  • Dimensions

    16.22 x 11.18 x 10.28" (411.99 x 283.97 x 261.11mm)

  • Weight

    14 lbs (6.35kg)

  • UPC Code

    781462218041

About CHAUVET Professional Ovation FD-205WW

Bring your stage performances to life with the Ovation FD-105WW 230W Warm White LED Fresnel. This high-powered LED spotlight is equipped with advanced data and power sensors, enabling it to operate seamlessly on both conventional dimming power systems and constant power rigs.

Designed for professional use, this LED Fresnel wash features a remarkable zoom range of 20 degrees to 72 degrees, providing you with the flexibility to control the intensity and focus of your stage lighting. Its warm white wash, with a color temperature of 3069K, delivers a soft, inviting light that enhances the visual appeal of your performances.

The Ovation FD-105WW stands out for its high Color Rendering Index (CRI), making it an ideal LED replacement for aging incandescent eight-inch Fresnels. This feature ensures accurate color reproduction, adding depth and realism to your stage presentations.

One of the unique features of this LED Fresnel is its proprietary motorized zoom, which can be easily accessed via the rotary knob on the back of the fixture. This allows for smooth adjustments even when the fixture is run via a traditional dimming system.

With its durable metal housing, the Ovation FD-105WW is built to withstand the rigors of professional use. It also comes with a powerCON power cord for easy connectivity and setup.

Experience the advantages of LED lighting without compromising on the investments made in your existing dimming systems with the Ovation FD-105WW 230W Warm White LED Fresnel. This versatile and reliable lighting fixture is designed to meet the demands of theaters, concerts, and other live events.

CHAUVET Professional Ovation FD-205WW Features

  • Works perfectly on conventional dimmers or constant power with DMX
  • Auto-senses what kind of system (dimmers or constant power with DMX) and responds appropriately
  • Superior low end dimming regardless of power supplied (conventional dimmer/constant power with DMX)
  • Perfect fixture for the retrofit market, utilizes existing infrastructure flawlessly
  • Motorized zoom feature available in Dimmer, SENS or DMX modes
  • 16-bit dimming resolution (DMX mode) for smooth fades
  • Soft and even field of light
  • Virtually silent operation for use in any situation
  • Simple and complex DMX channel profiles for programming versatility
  • Warm white Fresnel-style lighting fixture
  • Motorized zoom angle between 20 deg. to 72 deg. , manually or via DMX

Warranty Information

This product has a limited warranty of 12 months for parts and 24 months for labor.

Product Documents

User Manual

Key Features

  • Experience superior lighting with the Ovation FD-205WW LED Fresnel spotlight, perfect for stage productions.
  • Achieve precise control with the motorized zoom feature, adjusting your LED spotlight from 20° to 72°.
  • Enjoy flicker-free operation for broadcast use with selectable PWM, enhancing your LED lighting setup.
  • Create stunning visuals with a high CRI of 96, ensuring accurate color rendering with this spotlight.
  • This durable Chauvet LED Fresnel features Neutrik powerCON, ensuring reliable power connectivity.
  • Customize your lighting with gel frame accessories, tailoring the spotlight's output for any event.

What's in the box:

  • CHAUVET Ovation FD-205WW 230W Warm White LED Fresnel
  • Neutrik powerCON Power Cord
  • Gel Frame (7.5 "/190.5mm Accessories)
  • Quick Reference Guide
  • CHAUVET 1 Year Limited Warranty
