CHAUVET Professional Ovation F-415FC 6" RGBAL Fresnel-Style Fixture, 2800-6500 K Color Temperature

SKU: CHOVATF415FC MFR: OVATIONF415FC
Earn VIP Reward Points

Key Features

  • Experience superior color mixing with the Ovation F-415FC RGBAL Fresnel spotlight.
  • Achieve precise lighting control with motorized zoom, adjustable from 14° to 68°.
  • Enjoy flicker-free operation for broadcast use with selectable PWM frequencies.
  • Create stunning visual effects with electronic dimming and strobe capabilities.
  • Easily integrate into existing setups with 3- and 5-pin XLR DMX connectivity.
  • Rely on long-lasting performance with a 50,000-hour LED light source lifespan.
See More Product Details
FREE 2-Day Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$179.99

3 Year

$249.99

5 Year

$489.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

CHAUVET Professional Ovation F-415FC Specifications

Optical

Optical

Jump to...
  • Light Source

    46 LEDs (10 red, 10 green, 6 blue, 8 amber, 12 lime) 3 to 5 W, (1 A), 50,000 hours life expectancy.

  • Color Temperature (range)

    2800 to 6500 K

  • CRI (3200 K)

    91

  • Beam Angle

    14 Degree to 43 Degree

  • Field Angle

    27 Degree to 68 Degree

  • Zoom Range

    14 Degree to 68 Degree

  • Lumens (27 Degree )

    1,877
    (68 Degree ): 2,815

  • Illuminance (27 Degree )

    915 lux @ 5 m
    (68 Degree ): 190 lux @ 5 m

  • Selectable PWM

    600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz

Dynamic Effects

Jump to...
  • Dimmer

    Electronic

  • Shutter/Strobe

    Electronic

  • Zoom

    Motorized

  • Strobe Rate

    0 to 27 Hz

  • Standalone Color Mixing

    Yes

  • Color Temperature Presets

    Yes

  • Dim Modes

    4

  • Built-in Automated Programs

    Yes

Connections

Jump to...
  • Power Connection

    Edison (Local) plug to Neutrik powerCON

  • Power Input

    Neutrik powerCON

  • Power Output

    Neutrik powerCON

  • Data Connectors

    3- and 5-pin XLR

  • Cable Length (power)

    5' (1.5m)

Control

Jump to...
  • Control Protocol

    DMX, RDM

  • DMX Channels

    1, 3, 5, 7, 10, 12, 13 or 15

  • Modes/Personalities

    9 personalities (HSV, 1CH, 3CH, 5CH, 7CH, 10CH, 12CH, 13CH, 15CH)

Electrical

Jump to...
  • Input Voltage

    100 to 240 VAC, 50/60 Hz (auto-ranging)

  • Power Linking

    13 units @ 120 V; 22 units @ 208 V; 24 units @ 230 V

  • Power and Current

    124 W, 1.027 A @ 120 V, 60 Hz
    124 W, 0.608 A @ 208 V, 60 Hz
    126 W, 0.546 A @ 230 V, 50 Hz

Certifications / Qualifications

Jump to...
  • Certification

    CE, MET, FCC

  • IP Rating

    IP20, dry location

  • Temperature (Ambient)

    -4 Degree F to 113 Degree F (-20 Degree C to 45 Degree C)

Construction / Physical

Jump to...
  • Exterior Color

    Black

  • Housing Material

    Aluminum alloy, Aluminum die-cast

  • Accessory Holder/Gel Frame Size

    6.25 in (158.75 mm)

  • Dimensions

    15.80 x 11.22 x 9.51 in (401.46 x 285 x 241.65mm)

  • Weight

    12 lbs (5.6kg)

  • UPC Code

    781462218300

About CHAUVET Professional Ovation F-415FC

Make your lighting setup stand out with the Ovation F-415FC, a 6" RGBAL Fresnel-Style Fixture that boasts a versatile color temperature range of 2800-6500 K. This advanced lighting solution is powered by a state-of-the-art RGBAL LED system, capable of projecting a brilliantly bright and beautifully soft field of light. Whether you're aiming for subtle pastels or punchy saturates, this fixture delivers with precision and consistency.

The Ovation F-415FC is not just about color versatility; it also offers a motorized zoom with a field range of 14 to 68 degrees, enabling you to direct light exactly where it's needed. This feature makes it an ideal choice for professional photographers, videographers, and stage designers who require precise light control.

Equipped with a virtual color wheel, this Fresnel-style fixture allows for seamless color transitions and adjustments. Control the color wheel, zoom, and output either via DMX or the on-board dials, providing you with flexibility and ease of use.

Furthermore, the Ovation F-415FC is RDM-enabled, simplifying the installation process and making it a user-friendly choice for both professionals and beginners. It also offers adjustable PWM, ensuring flicker-free use on camera, making it an excellent choice for video production.

Incorporate the Ovation F-415FC 6" RGBAL Fresnel-Style Fixture into your lighting setup and experience the difference in color, control, and convenience.

CHAUVET Professional Ovation F-415FC Features

  • Full Color LED (RGBAL) Fresnel lighting fixture for theatre, film and production
  • Soft and even field of light
  • Smooth, motorized zoom from 14 Degree to 68 Degree
  • Beautiful 16-bit dimming of master dimmer and individual colors
  • Easy to use on board control of color, zoom and dimming
  • Virtual Color wheel with color matched to popular gel colors
  • Color Temperature Presets from 2800 K to 6500 K
  • RDM (Remote Device Management) for added flexibility
  • Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
  • Virtually silent operation for use in studio and theatre applications

Warranty Information

This product has a limited warranty of 24 months for parts and 24 months for labor.

Product Documents

User Manual

Key Features

  • Experience superior color mixing with the Ovation F-415FC RGBAL Fresnel spotlight.
  • Achieve precise lighting control with motorized zoom, adjustable from 14° to 68°.
  • Enjoy flicker-free operation for broadcast use with selectable PWM frequencies.
  • Create stunning visual effects with electronic dimming and strobe capabilities.
  • Easily integrate into existing setups with 3- and 5-pin XLR DMX connectivity.
  • Rely on long-lasting performance with a 50,000-hour LED light source lifespan.

What's in the box:

  • CHAUVET Ovation F-415FC 6" RGBAL Fresnel-Style Fixture
  • Neutrik powerCON Power Cord
  • Gel Frame (6.25" / 158.75 mm Accessories)
  • Quick Reference Guide
  • CHAUVET 2 Year Limited Warranty
