Chrosziel MN-200 MagNum 2-Channel Wireless Lens Control System with Heden M21VE-L Motor

Take control of your filmmaking with the MN-200 MagNum 2-Channel Wireless Lens Control System, featuring the advanced Heden M21VE-L Motor. This comprehensive system is designed for precision and reliability, making it an essential tool for professional filmmakers and drone operators alike.

The MagNum 200 2-Channel Wireless Lens Control Hand Unit offers seamless remote control over focus and iris adjustments. Its fluid-dampened hand wheel ensures smooth focus transitions, while a linear slider on an aluminum scale allows precise iris control. Set hard stops along the focus rotation for accurate focus marks. The compact transmitter is ergonomically designed with a rounded handle and finger grip for secure handling during operation. It includes an internal 2.4 GHz antenna and a BNC spigot for an external 434 MHz antenna, optimizing transmission with an integrated spectrum analyzer to avoid radio interference. The OLED display facilitates easy menu navigation, and the package includes a BNC antenna and a hand strap for added convenience.

The MagNum 200 2-Channel Wireless Lens Control Receiver is equipped with a 2.4 GHz antenna and an additional BNC 430MHz antenna, ensuring robust connectivity. It features dual outputs capable of driving up to two motors via 7-pin LEMO connections. The receiver can independently calibrate motors to the lens, and once connected to a camera via the serial port, it allows remote start/stop control from the transmitter. Operating on both 2.4GHz and 430MHz frequencies, the system ensures maximum working distance and reliability.

The Heden M21VE-L Digital Motor, now enhanced with a dual-pin hub and snap-on gear with a dual-pin lock mechanism, offers increased durability and reliability. This lightweight motor is ideal for professional film and broadcasting cameras, particularly in tight spaces or when used with drones. It mounts vertically on a 19 mm rod without tools, and a bracket reduction insert is available for 15 mm rods. The motor's versatility is further enhanced by interchangeable snap-on gears, supplied with a 0.8 gear module, with additional modules available.

Additional components include the Chrosziel Antenna (Straight) for transceiver use, a 7-Pin LEMO Motor Cable compatible with various digital motors, and a Chrosziel Scale Ring for focus hand wheel adjustments. The system also includes a padded neck strap for comfortable carrying, the MN-RMB1 Mounting Bracket for secure receiver attachment, and the MN-BAT 7.2 VDC Lithium-ion Battery with the MN-CH Charger for reliable power supply. A D-Tap Power Cable and a Chrosziel Case with insert complete this comprehensive lens control system, ensuring you have everything you need for professional-grade lens management.
