2019-10-04T10:14:17

Rated 5 out of 5

E500L is a solid buy.

There is a lot to like about this case that find more important than a few minor criticisms of it. For those looking for their first case, this is a fantastic option. The Pros: - Lots of room around the motherboard area, which helps with cable management. Cable management is easy for the most part. - See-through plastic panel on the right and metal panel on the left come off via thumb screws. Easy for component swaps. - Space for an optical drive if you need to install your OS via disc. - Comes with 2x 2.5" and 2x 3.5" form factor drive slots. - Case itself is very light. Cons: - The one area with difficult cable management would be on the side of the 2.5" form factor drives that utilize SATA 3.0 memory bus. Being inside the left panel and on the outside of the chassis, getting the SATA cables connected can be tricky with the limited space between the IO cables running through and the holes allowing movement to the motherboard. Still, for the price, it's hard to beat.

Thomas R.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

CoolerMaster MasterBox E500L Specifications

  • Materials

    Steel, Plastic

  • Motherboard Support

    ATX, Micro-ATX, Mini-ITX

  • Expansion Slots

    7

  • 5.25" Drive Bays

    1

  • 3.5" Drive Bays

    2

  • 2.5" Drive Bays

    2

  • I/O Port

    2x USB 3.0, Audio In / Out

  • Pre-Installed Fans

    Front: 1x 120mm LED fan
    Rear: 1x 120mm Black fan

  • Fan Support

    Front: 2x 120mm / 140mm
    Top: 2x 120mm
    Rear: 1x 120mm

  • Radiator Support

    Front: 120 / 140 / 240 / 280mm radiator
    Rear: 120mm radiator (Need to install fan first)

  • Clearance

    CPU Cooler: 157mm
    PSU: 220mm
    GPU: 399mm

  • Cable Routing

    BehindMB Tray: 22mm

  • Dust Filters

    Front, Top, Bottom

  • Power Supply

    Bottom mount, ATX

  • Power Supply Cover

    Included

  • Dimensions (LxWxH)

    490 x 203 x 426mm (19.29 x 7.99 x 16.77")

  • Weight

    4.55kg (10.03 lbs)

  • UPC Code

    884102042546

About CoolerMaster MasterBox E500L

FEATURED REVIEWS

E500L is a solid buy.

By Thomas R.

There is a lot to like about this case that find more important than a few minor criticisms of it. For those looking for their first case, this is a fantastic option. The Pros: - Lots of room around the motherboard area, which helps with cable management. Cable management is easy for the most part. - See-through plastic panel on the right and metal panel on the left come off via thumb screws. Easy for component swaps. - Space for an optical drive if you need to install your OS via disc. - C...

View full Review

Clean and Elegant
The brushed front slide panel gives the case not only an elegant look, but also provides you can hide your I/O ports behind it to keep a clean design.

Color Plan of Side Trims
Choose from 3 different colors of side trims to suit your style: Red, Blue and Silver.

Edge to Edge Transparent Side Panel
Show off your build in style through the edge to edge transparent side panel.

Versatile Cooling Options
The front supports up to two 120mm/140mm fans and up to a 280mm radiator. The Rear supports a 120mm fan or radiator. It comes with one pre-installed 120mm LED fan in the front and a single 120mm fan in the rear. All to ensure you don't have to compromise on performance.

Main Components Clearance
The E500L case supports CPU-Coolers up to a height of 157mm, Graphic Cards up to a length of 399mm and Power Supplies up to a length of 220mm.

Expanding The Possibilities
The spacious interior fits all standard motherboards for your system needs. Black coating and an included PSU cover that allows for easy, simple configurations for your system build. Let your configuration stand out with an all-black background.

What's in the box:

  • CoolerMaster MasterBox E500L ATX Mid-Tower with Front Sliding Brushed Top Panel
  • Power Supply Cover
  • CoolerMaster 2 Year Limited Warranty
