ClearOne CONVERGE Pro 2 DSP Mixer with 12 Mic/Line Inputs (AEC), 8 Mic/Line Outputs and Built-in USB Audio

SKU: CO9103200001 MFR: 910-3200-001
Earn VIP Reward Points

Key Features

  • Experience pristine audio clarity with the ClearOne DSP mixer for your conferences.
  • Enhance collaboration using 12 mic/line inputs on this advanced audio conferencing system.
  • Enjoy seamless USB audio integration for PC-based conferencing with this versatile mixer.
  • Easily manage your audio with the intuitive CONSOLE software for Windows & Mac.
  • Expand your audio setup using the C-link expansion bus for enhanced audio channels.
  • Control your audio environment with the integrated GPIO interface for customized setups.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$299.99

3 Year

$449.99

5 Year

$949.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

ClearOne CONVERGE Pro 2 Specifications

System
  • Mic/Line inputs

    12

  • Mic/Line outputs

    8

  • AEC

    Yes

  • C-link expansion bus

    Yes

  • P-link peripheral bus

    Yes

  • USB audio interface

    Yes

  • Ethernet, RS-232, GPIO interface

    Yes

Applications

Jump to...
  • Built-in USB for PC-based conferencing

    Yes

  • Built-in Telco for teleconferencing

    No

  • Built-in VoIP for VoIP conferencing

    No

  • Microsoft Skype

    For Business audio conferencing: No

  • Sound Reinforcement applications

    Yes

  • Built-in Dante for audio networking

    No

Peripheral Devices

Jump to...
  • Beamforming Mic Array 2

    Yes

  • DIALOG 20 - Wireless Mic System

    Yes

  • GPIO Expander

    Yes

  • USB Expander

    Yes

Configuration, Management & Control

Jump to...
  • New CONSOLE software

    Yes

  • Dialer app - Win, Mac, iOS, Android

    Yes

  • Touch Panel Controller

    Yes

  • Third-party control modules

    Yes

Mic/line Inputs & Outputs

Jump to...
  • Inputs

    Balanced audio inputs, 3.81mm Orange color Phoenix/Euroblock type male header, Push-on mini-terminal block

  • Outputs

    Balanced audio outputs, 3.81mm Black color Phoenix/Euroblock type male header, Push-on mini-terminal block

  • Frequency Response

    20Hz - 22kHz at +4dBu, +/- 0.5dBu

  • EIN (Equivalent Input Noise)

    20kHz BW, max gain, Rs = 150Ohms, -126dBu

  • THD + N

    20Hz - 22kHz at +4dBu, line level, 0.006%
    20Hz - 22kHz at -56dBu, mic level, <0.04%

  • Dynamic Range

    20Hz - 20kHz at 0dB, >105dB

  • Crosstalk (Mic/Line)

    Channel to Channel, stimulus at 20dBu to receptor at -56dBu, 1kHz, < -98dB

  • Input Impedance

    Balanced (line to ground), 2.2kOhms, 1%

  • Nominal Input Level

    Adjustable -56dB to 0dB, 7dB step coarse gain

  • Maximum Input Level:

    -65dBu to 20dBu

  • Phantom Power

    48V, Impedance 6.81kOhms

  • Output Impedance

    Balanced (line to ground), 95Ohms, 1%

  • Output Level:

    0dBu (Nominal), 20dBu (Max), -40dBu (Selectable)

USB Audio

Jump to...
  • Port Type

    USB-B connector

  • Audio

    Digital Audio, 2 x 2 bidirectional channels

  • Sample Rate:

    48kHz

  • Sample Bit Depth:

    24-Bit

  • Compatible

    USB 2.0
    USB 3.0

Ethernet

Jump to...
  • Port Type

    RJ-45, 10/100Mbps Ethernet Network, Auto Negotiation

  • IP address:

    IPv4 (IPv6 upgradeable through future s/w, f/w upgrade)

  • Port Type

    DB9 Female

  • Settings

    9600/19200/38400/57600/115200 Baud; Serial Echo; Flow Control

  • Support

    Serial commands

  • Port Type

    5.08mm Green color Phoenix/Euroblock type male header

  • Support

    Control, Status, Variable Voltage Control

  • Power Pin:

    5V DC at 350mA Power Source

  • Pin 1 to 4

    Open Collector Outputs: 40VDC at 250mA
    Active Outputs (Source/Sink): 5VDC at 25mA
    Logic Inputs: 40.2kOhms pull up
    Variable Voltage Control Inputs: 5VDC max

  • Ground Pin

    GND

USB Control

Jump to...
  • Port Type

    USB-B connector

  • Location

    Front Panel

  • Compatible

    USB 2.0
    USB 3.0

  • Location

    Front Panel

  • Status LED

    Off: Unit still initializing
    Blue - Fast Blinking: Stack Syncing in progress
    Blue - Slow Blinking: Unit not configured
    Blue - Solid: Configured unit
    Red - Fast Blinking: Stack Sync error

  • Locate LED

    Blue - Blinking: Unit "Locate" command received

  • Power LED:

    Blue - Solid: Unit is powered on

Touch Sensor

Jump to...
  • Sensor Type:

    Capacitive Touch Button

  • Location

    Front Panel

Power & Thermal

Jump to...
  • Port Type

    AC Inlet

  • Mains Voltage:

    100-240V AC, 50/60Hz

  • Power Consumption:

    50 Watts Typical

  • Thermal

    170 BTU/Hr Typical

  • Operating Temperature:

    14 deg. F (-10 deg. C) to 104 deg. F (40 deg. C) Ambient Temperature

General

Jump to...
  • RU size

    1 RU

  • Dimensions (WxDxH)

    Without rack-ears: 17 x 10.73 x 1.72" (43.18 x 27.25 x 4.37cm)

    With rack-ears: 19 x 10.73 x 1.72" (48.26 x 27.25 x 4.37cm)

  • Weight

    9.3 lbs (4.22kg) (Approximately)

  • UPC Code

    671010009422

About ClearOne CONVERGE Pro 2

If you're seeking a sophisticated and advanced solution for your professional audio needs, look no further than the CONVERGE Pro 2 DSP Mixer. This high-quality, innovative device is the industry's leading professional audio DSP platform, designed for both conferencing and sound reinforcement applications.

The CONVERGE Pro 2 excels in any room size, audio environment, and application, making it a versatile choice for your audio needs. This model boasts 12 mic/line inputs with Acoustic Echo Cancellation (AEC), 8 mic/line outputs, and built-in USB audio for seamless PC-based conferencing.

In addition to its powerful architecture, the CONVERGE Pro 2 offers scalable connectivity. You can stack units to achieve up to 144 mic/line inputs and utilize the "C-Link" expansion bus with 64 channels. The "P-Link" bus allows you to connect peripheral devices with ease.

The device's configuration and management are simplified with the new CONSOLE software, which features auto-discovery of devices, MatrixView for the entire system, and FlowView for visualized audio signal paths. This makes system monitoring and troubleshooting a breeze.

The CONVERGE Pro 2 is equipped with next-gen Acoustic Echo Cancellation processing, Distributed Echo Cancellation on every mic input, and Noise Cancellation with Adaptive-Ambience. It also features Acoustic Intelligence with faster convergence, DARE feedback elimination, and advanced microphone gating.

This DSP mixer is perfect for PC-based conferencing and Unified Communications, as well as video codec-based Video Conferencing. It offers flexible control options, including a dialer app for Windows, Mac, iOS, Android, and a Touch Panel Controller with tabletop and wall mount options.

The CONVERGE Pro 2 is also optimized to work with the new Beamforming Mic Array 2 and DIALOG 20 2-Channel Wireless Microphone System through its native connection, making it a comprehensive solution for your professional audio needs.

ClearOne CONVERGE Pro 2 Features

  • Advanced professional audio DSP mixer perfect for conferencing and sound reinforcement
  • Features 12 mic/line inputs with Acoustic Echo Cancellation (AEC) and 8 mic/line outputs
  • Built-in USB audio for seamless PC-based conferencing
  • Scalable connectivity with stackable units and expansion bus options
  • Equipped with next-gen audio signal processing technologies for superior sound quality
  • Offers flexible control options including a dialer app and a Touch Panel Controller

Key Features

  • Experience pristine audio clarity with the ClearOne DSP mixer for your conferences.
  • Enhance collaboration using 12 mic/line inputs on this advanced audio conferencing system.
  • Enjoy seamless USB audio integration for PC-based conferencing with this versatile mixer.
  • Easily manage your audio with the intuitive CONSOLE software for Windows & Mac.
  • Expand your audio setup using the C-link expansion bus for enhanced audio channels.
  • Control your audio environment with the integrated GPIO interface for customized setups.

What's in the box:

  • ClearOne CONVERGE Pro 2 DSP Mixer
  • 6' Grounded Power Cord
  • 12x 3-Position Terminal Block Input Connector (Orange)
  • 8x 3-Position Terminal Block Output Connector (Black)
  • 6-Position Terminal Block GPIO Connector (Green)
  • 18 " RJ-45 to RJ-45 C-Link Cable
  • 6' USB Type A to USB Type B Cable
  • 4x Screw/Washer Kit
  • ClearOne Warranty
