ClearOne CONVERGE Pro 2 DSP Mixer with 12 Mic/Line Outputs and Built-in USB Audio, Output-only Mixer

SKU: CO9103200007 MFR: 910-3200-007
Earn VIP Reward Points

Key Features

  • Experience superior sound quality with this ClearOne DSP mixer for crystal-clear audio.
  • Enjoy seamless USB audio integration for PC-based conferencing and collaboration sessions.
  • This audio mixer features 12 mic/line outputs, perfect for large conference rooms or venues.
  • Easily manage your audio with the intuitive CONSOLE software for Windows, Mac, iOS & Android.
  • Expand your system using the C-Link expansion bus for enhanced audio networking capabilities.
  • Control devices via Ethernet, RS-232, and GPIO interfaces for versatile system integration.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$219.99

3 Year

$349.99

5 Year

$689.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking ā€œAdd to Cartā€.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

ClearOne CONVERGE Pro 2 Specifications

System
  • Mic/Line inputs

    No

  • Mic/Line outputs

    12

  • AEC

    No

  • C-link expansion bus

    Yes

  • P-link peripheral bus

    Yes

  • USB audio interface

    Yes

  • Ethernet, RS-232, GPIO interface

    Yes

Applications

Jump to...
  • Built-in USB for PC-based conferencing

    Yes

  • Built-in Telco for teleconferencing

    No

  • Built-in VoIP for VoIP conferencing

    No

  • Microsoft Skype

    For Business audio conferencing: No

  • Sound Reinforcement applications

    Yes

  • Built-in Dante for audio networking

    No

Peripheral Devices

Jump to...
  • Beamforming Mic Array 2

    No

  • DIALOG 20 - Wireless Mic System

    Yes

  • GPIO Expander

    Yes

  • USB Expander

    Yes

Configuration, Management & Control

Jump to...
  • New CONSOLE software

    Yes

  • Dialer app - Win, Mac, iOS, Android

    Yes

  • Touch Panel Controller

    Yes

  • Third-party control modules

    Yes

Mic/line Inputs & Outputs

Jump to...
  • Outputs

    Balanced audio outputs, 3.81mm Black color Phoenix/Euroblock type male header, Push-on mini-terminal block

  • Frequency Response

    20Hz - 22kHz at +4dBu, +/- 0.5dBu

  • THD + N

    20Hz - 22kHz at +4dBu, line level, 0.006%
    20Hz - 22kHz at -56dBu, mic level, <0.04%

  • Dynamic Range

    20Hz - 20kHz at 0dB, >105dB

  • Crosstalk (Mic/Line)

    Channel to Channel, stimulus at 20dBu to receptor at -56dBu, 1kHz, < -98dB

  • Output Impedance

    Balanced (line to ground), 95Ohms, 1%

  • Output Level

    0dBu (Nominal), 20dBu (Max), -40dBu (Selectable)

USB Audio

Jump to...
  • Port Type

    USB-B connector

  • Audio

    Digital Audio, 2 x 2 bidirectional channels

  • Sample Rate

    48kHz

  • Sample Bit Depth

    24-Bit

  • Compatible

    USB 2.0
    USB 3.0

Ethernet

Jump to...
  • Port Type

    RJ-45, 10/100Mbps Ethernet Network, Auto Negotiation

  • IP address

    IPv4 (IPv6 upgradeable through future s/w, f/w upgrade)

  • Port Type

    DB9 Female

  • Settings

    9600/19200/38400/57600/115200 Baud; Serial Echo; Flow Control

  • Support

    Serial commands

  • Port Type

    5.08mm Green color Phoenix/Euroblock type male header

  • Support

    Control, Status, Variable Voltage Control

  • Power Pin

    5V DC at 350mA Power Source

  • Pin 1 to 4

    Open Collector Outputs: 40VDC at 250mA
    Active Outputs (Source/Sink): 5VDC at 25mA
    Logic Inputs: 40.2kOhms pull up
    Variable Voltage Control Inputs: 5VDC max

  • Ground Pin

    GND

USB Control

Jump to...
  • Port Type

    USB-B connector

  • Location

    Front Panel

  • Compatible

    USB 2.0
    USB 3.0

  • Location

    Front Panel

  • Status LED

    Off: Unit still initializing
    Blue - Fast Blinking: Stack Syncing in progress
    Blue - Slow Blinking: Unit not configured
    Blue - Solid: Configured unit
    Red - Fast Blinking: Stack Sync error

  • Locate LED

    Blue - Blinking: Unit "Locate" command received

  • Power LED

    Blue - Solid: Unit is powered on

Touch Sensor

Jump to...
  • Sensor Type

    Capacitive Touch Button

  • Location

    Front Panel

Power & Thermal

Jump to...
  • Port Type

    AC Inlet

  • Mains Voltage

    100-240V AC, 50/60Hz

  • Power Consumption

    50 Watts Typical

  • Thermal

    170 BTU/Hr Typical

  • Operating Temperature

    -10 to 40 deg. C (14 to 104 deg. F) Ambient Temperature

General

Jump to...
  • RU size

    1 RU

  • Dimensions (WxDxH)

    Without rack-ears: 17 x 10.73 x 1.72" (43.18 x 27.25 x 4.37cm)

    With rack-ears: 19 x 10.73 x 1.72" (48.26 x 27.25 x 4.37cm)

  • Weight

    9.3 lbs (4.22kg) (Approximately)

About ClearOne CONVERGE Pro 2

Just when you thought professional audio DSP platforms couldn't get any better, the CONVERGE Pro 2 steps in to redefine industry standards. This advanced mixer is designed for both conferencing and sound reinforcement applications, delivering superior performance regardless of room size, audio environment, or application type.

The 012 model of the CONVERGE Pro 2 DSP Mixer boasts 12 mic/line outputs and built-in USB audio. It also features a variety of control interfaces, including GPIO, RS232, and IP, along with P-Link and C-Link expansion buses. This device is specifically optimized to seamlessly integrate with the DIALOG 20 2-Channel Wireless Microphone System via its native connection.

The powerful architecture of the CONVERGE Pro 2 includes 12 mic/line inputs with AEC, increased mic/line inputs for other CP2 units, and an output-only DSP mixer. The built-in USB facilitates PC-based conferencing, while its reduced footprint and power consumption make it an eco-friendly choice.

The mixer's scalable connectivity allows for both standalone and daisy-chained systems. It features a 64-channel "C-Link" expansion bus and a "P-Link" bus for connecting peripheral devices.

The CONVERGE Pro 2 also offers a new CONSOLE software for easy configuration and management. This includes auto-discovery of devices, MatrixView for viewing the entire system, FlowView for visualizing audio signal paths, and system monitoring and troubleshooting.

The mixer's audio signal processing capabilities include Acoustic Intelligence with faster convergence and DARE feedback elimination. It is suitable for a range of applications, including PC-based conferencing, unified communications, video codec-based video conferencing, and sound reinforcement applications.

To ensure flexible control options, the CONVERGE Pro 2 is compatible with a dialer app for Windows, Mac, iOS, and Android. It also supports a Touch Panel Controller with tabletop and wall mount options, as well as third-party control modules.

In conclusion, the CONVERGE Pro 2 DSP Mixer is not just a device; it's a comprehensive solution for all your professional audio needs.

ClearOne CONVERGE Pro 2 Features

  • Advanced professional audio DSP mixer for conferencing and sound reinforcement applications
  • Includes 12 mic/line outputs and built-in USB audio for PC-based conferencing
  • Features control interfaces such as GPIO, RS232, IP, and expansion buses P-Link and C-Link
  • Offers new CONSOLE software for easy device configuration, system monitoring, and troubleshooting
  • Equipped with Acoustic Intelligence and DARE feedback elimination for superior audio signal processing
  • Provides flexible control options with compatibility for Windows, Mac, iOS, Android, and third-party modules

Key Features

  • Experience superior sound quality with this ClearOne DSP mixer for crystal-clear audio.
  • Enjoy seamless USB audio integration for PC-based conferencing and collaboration sessions.
  • This audio mixer features 12 mic/line outputs, perfect for large conference rooms or venues.
  • Easily manage your audio with the intuitive CONSOLE software for Windows, Mac, iOS & Android.
  • Expand your system using the C-Link expansion bus for enhanced audio networking capabilities.
  • Control devices via Ethernet, RS-232, and GPIO interfaces for versatile system integration.

What's in the box:

  • ClearOne CONVERGE Pro 2 DSP Mixer
  • 6' Grounded Power Cord
  • 12x 3-Position Terminal Block Output Connector (Black)
  • 6-Position Terminal Block GPIO Connector (Green)
  • 18 " RJ-45 to RJ-45 C-Link Cable
  • 6' USB Type A to USB Type B Cable
  • 4x Screw/Washer Kit
  • ClearOne Warranty
