Cooke 135mm T2.3 Anamorphic/i 1.8x Plus SF Prime Lens for PL Mount

SKU: COEAFFSF135 MFR: CKEAFFSF 135
Earn VIP Reward Points

Key Features

  • Capture stunning full-frame footage with this 135mm Cooke Anamorphic/i Prime Lens.
  • Achieve a beautiful bokeh effect with the wide T2.3 aperture for cinematic shots.
  • Enjoy precise manual focus with clearly marked scales in both feet and meters.
  • Create unique visuals with the 1.8x anamorphic squeeze, enhancing your video projects.
  • Benefit from robust build quality, ensuring durability for professional filmmaking.
  • Experience exceptional image quality and sharpness across the entire full frame.
See More Product Details
Special Order?Estimated to Ship: 12/04/2025
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the main purpose of the 135mm T2.3 Anamorphic/i 1.8x Plus SF Prime Lens for PL Mount?

This lens is designed for professional photography and filmmaking. It is particularly well-suited for large format production with anamorphic characteristics, including distinctive flare and oval bokeh.

What is the /i Technology feature in this lens?

/i Technology allows for frame by frame digital information capture. This feature is found in all modern Cooke cine lenses and is particularly useful for both film and digital capture.

What does the cam-type focus mechanism do?

The cam-type focus mechanism allows for smooth and precise focus adjustments, giving the user more control over the image.

What is the benefit of the lens's modular construction?

The modular construction of the lens simplifies maintenance and boosts serviceability, enhancing the lens's longevity and performance.

What does a 1.8 squeeze mean?

A 1.8 squeeze refers to the lens's ability to cover a full 24 x 36 still size sensor, striking a balance between retaining pixels and providing anamorphic character to the image.

Reviews about this item

Review Summary

Cooke Anamorphic/I 1.8x Plus SF Specifications

  • Focal Length

    135mm

  • T Stop Range

    T2.3-T22

  • Angular Rotation of Iris Scale

    90 Degree

  • Marked Object Distance

    Minimum: 58" (1500mm)

  • Close Focus from Lens Front

    46" (1166mm)

  • Angular Rotation to MOD Endstop

    270 Degree

  • Diagonal Angle of View

    Maximum: 30 Degree (Super 35 Format)

  • Format Cover

    Maximum: 1.41 x 0.94" (36 x 24mm)

  • Focus Scales

    Two opposing focus scales - metric & footage. Scales marked from infinity to MOD

  • Focus Drive Gear

    140 teeth 0.8 metric module x 6.0mm wide 102mm from the image plane

  • Iris Scales

    Two opposing linear T scales - whole and third stops marked

  • Iris Drive Gear

    134 teeth 0.8 metric module x 4.0mm wide x 82mm from image plane

  • Dimensions (Dia. x L)

    4.33 x 10.7" (110 x 271mm)

  • Weight

    11.0 lbs (5.0kg)

Models
Cooke 135mm T2.3 Anamorphic/i 1.8x Plus SF Prime Lens for PL Mount
$36,500.00

Special Order

Generally ships in 7-14 days, subject to availability

Cooke 100mm T2.3 Anamorphic/i 1.8x Plus Lens for PL Mount
$36,500.00

Special Order

Generally ships in 7-14 days, subject to availability

Cooke 180mm T2.0 S7/i Plus Prime Lens for PL Mount
$32,000.00

Special Order

Generally ships in 7-14 days, subject to availability

Kit StyleBaseBaseBase
FormatFull FrameFull FrameFull Frame
Lens TypeTelephotoTelephotoTelephoto
Fixed Focal Length135mm100mm180mm
Lens MountPL MountPL MountPL Mount
Maximum ApertureT2.3T2.3T2.0
Zoom Focal LengthNANANA
Focus TypeManual FocusManual FocusManual Focus

About Cooke Anamorphic/I 1.8x Plus SF

While maintaining the renowned quality of Cooke lenses, the 135mm T2.3 Anamorphic/i 1.8x Plus SF Prime Lens for PL Mount takes the art of filmmaking and photography to new heights. This high-quality lens is designed for large format production, offering anamorphic characteristics such as distinctive flare and oval bokeh. Its coverage circle comfortably accommodates a full 24 x 36 still size sensor, providing a 1.8 squeeze that hits the sweet spot between pixel retention and anamorphic character.

The lens's professional-grade optical and mechanical performance ensures control over flare, distortion, veiling glare, and spherical aberrations even at full aperture. This versatile lens features a cam-type focus mechanism, allowing for smooth and precise focus adjustments, enhancing the user's control over the image.

Constructed with durability in mind, this lens boasts a modular design that simplifies maintenance and boosts serviceability. The 135mm T2.3 Anamorphic/i 1.8x Plus SF Prime Lens is also equipped with /i Technology, a feature found in all modern Cooke cine lenses. This technology enables frame by frame digital information capture, making it a reliable choice for both film and digital capture.

With a 1.8x squeeze and a T2.3 stop, this lens offers a unique, cinematic look, making it an ideal choice for professional photographers and filmmakers seeking to elevate their craft.

Cooke Anamorphic/I 1.8x Plus SF Features

  • Coverage circle covers a full 24 x 36 still size sensor with 1.8 squeeze
  • Superb optical and mechanical performance, control of flare, distortion, veiling glare and spherical aberrations at full aperture
  • Modular construction increases ease of maintenance and serviceability
  • Anamorphic/i Full Frame Plus lenses come equipped with /i Technology

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Capture stunning full-frame footage with this 135mm Cooke Anamorphic/i Prime Lens.
  • Achieve a beautiful bokeh effect with the wide T2.3 aperture for cinematic shots.
  • Enjoy precise manual focus with clearly marked scales in both feet and meters.
  • Create unique visuals with the 1.8x anamorphic squeeze, enhancing your video projects.
  • Benefit from robust build quality, ensuring durability for professional filmmaking.
  • Experience exceptional image quality and sharpness across the entire full frame.

What's in the box:

  • Cooke 135mm T2.3 Anamorphic/i 1.8x Full Frame Plus SF Prime Lens
  • Cooke 1 Year Limited Warranty
