Camplex TAC1 Simplex Singlemode LC Fiber Optic Single Channel Tactical Cable, 500'

SKU: CPT1SMLC500 MFR: HF-T1SM-LC-0500
Earn VIP Reward Points

Key Features

  • Ensure reliable data transfer with this 500' LC to LC singlemode fiber optic cable.
  • Our tactical fiber cable offers superior durability for demanding field applications.
  • Experience minimal signal loss with our high-quality single channel fiber optic cable.
  • This Camplex fiber optic cable supports 1310/1550nm wavelengths for optimal performance.
  • Built to last: This tactical cable withstands extreme temperatures and harsh conditions.
  • Enjoy a strong connection with low return loss using our LC singlemode fiber cable.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$79.99

3 Year

$109.99

4 Year

$129.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Camplex TAC1 Simplex Singlemode LC Fiber Optic Single Ch Tactical Cable, 500' Specifications

  • Cable Type

    Fiber Optic Tactical

  • Connector

    Connector 1: LC
    Connector 2: LC

  • Industry Standard Designation

    Single-Mode ITU-T G.652.A

  • Return Loss

    Less than 55 dB and IL less than 0.25 dB

  • Fiber

    SLS

  • Temperature

    Operating: -67-185 Degree F (-55-85 Degree C)
    Storage: -94-185 Degree F (-70-85 Degree C)
    Installation (Actual temp. Degree F cable): -13-140 Degree F (-25-60 Degree C)

  • Core/Cladding Diameter

    9/125 um

  • Wavelength (nm)

    1310/1550

  • Attenuation

    0.5/0.5 dB/km

  • Crush Resistance

    440 N/cm

  • Impact Resistance

    200 impacts

  • Jacket Material

    Polyurethane

  • Bend Radius

    Minimum: Installation: 1.1" (2.9cm)
    Operating: 0.6" (1.5cm)

  • Dispersion

    Zero Dispersion Slope: 0.092 ps/nm2-km

  • Pro Degree F Test Level

    100 kpsi

  • Tensile Strength

    Installation: 110lbs. (49.9kg) / 500 N
    Operating: 70lbs. (31.8kg) / 300 N

  • Jacket Color

    Black

  • Buffer Material

    Hard elastomeric

  • Weight

    6lbs./1000' (8.4kg/km)

  • Diameter

    Cable: 0.11" (2.9mm)
    Primary Coating Diameter: 500 um
    Secondary Buffer Diameter: 900 um

  • Length

    500' (152.4m)

About Camplex TAC1 Simplex Singlemode LC Fiber Optic Single Ch Tactical Cable, 500'

Are you in search of a robust and lightweight fiber optic solution for your broadcast and professional audio needs Look no further than the TAC1 Simplex Singlemode LC Fiber Optic Single Channel Tactical Cable, spanning an impressive 500 feet. Engineered to withstand the rigors of military tactical deployment, this cable is tailored to meet the stringent requirements of outdoor tactical environments where durability is paramount.

Constructed with a rugged Polyurethane Core-Locked design, this cable transcends the limitations of standard PVC jacket cables by offering superior crush and impact resistance. It's an ideal choice for field applications where environmental hazards and mechanical stresses are a concern.

The TAC1 Tactical Cable is equipped with premium Senko ST and LC fiber connectors, renowned for their high-quality performance and reliability. Each connector is meticulously machine polished, ensuring low insertion loss and high return loss, which translates to a stable and efficient signal transmission.

To guarantee optimal performance, every assembly undergoes rigorous interferometer testing, adhering to industry standards. This ensures that each cable not only meets but exceeds the expectations for high-quality signal integrity and durability.

For professionals who demand excellence and reliability, the TAC1 Simplex Singlemode LC Fiber Optic Single Channel Tactical Cable is the definitive choice. It's not just a cable; it's a commitment to quality and performance in the most demanding of environments. Plus, for those who require it, a complete set of test documentation for your specific cable assembly is available upon request, providing you with the assurance of its exceptional quality and performance.

Camplex TAC1 Simplex Singlemode LC Fiber Optic Single Ch Tactical Cable, 500' Features

  • Broadcast Deployable
  • Indoor/Outdoor rated jacket
  • Typical RL less than-55dB and IL less than 0.25dB
  • Wide temperature range (typically -55 Degree C to 85 Degree C)
  • 500um primary acrylate buffer with 900um secondary hard elastomeric buffer (Ultra-Fox Plus)
  • Excellent crush and impact resistance due to their polyurethane Core-Locked outer jacket
  • Designed to withstand crush and impact after deployment
  • Strong, lightweight and extremely durable cable

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Ensure reliable data transfer with this 500' LC to LC singlemode fiber optic cable.
  • Our tactical fiber cable offers superior durability for demanding field applications.
  • Experience minimal signal loss with our high-quality single channel fiber optic cable.
  • This Camplex fiber optic cable supports 1310/1550nm wavelengths for optimal performance.
  • Built to last: This tactical cable withstands extreme temperatures and harsh conditions.
  • Enjoy a strong connection with low return loss using our LC singlemode fiber cable.

What's in the box:

  • Camplex TAC1 Simplex Singlemode LC Fiber Optic Single Channel Tactical Cable
  • Camplex 1 Year Limited Warranty
