Chroma-Q Color Force II Plus 72 6' RGBA LED Fixture with Trunnion, TRUE1 to 15-5P Cable, Black

SKU: CQ16413000 MFR: CQ1641-3000
Earn VIP Reward Points

Key Features

  • Experience superior color mixing with the Color Force II Plus 72 RGBA LED fixture.
  • Achieve vibrant lighting with a wide, adjustable color temperature range (1,000-10,000K).
  • Enjoy flicker-free operation with the theatrical dimming curve, great for on-camera use.
  • Easily control your lighting setup using ANSI E1.11 USITT DMX 512-A control protocol.
  • Benefit from a long-lasting LED lamp life of L70 at 50,000 hours for years of use.
  • Create dynamic effects with built-in strobe and random strobe variable effects engine.
See More Product Details
Special Order Item?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$499.99

3 Year

$649.99

5 Year

$949.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Chroma-Q Color Force II Plus 72 Specifications

  • Color

    Black

  • Power Supply

    Built-in

  • Power Input Rating

    100-240V AC 50-60Hz 800VA

  • Power Factor

    0.96 @ 120V AC, 0.99 @ 240V AC

  • Power Consumption

    800W @ 120V AC, 800W @ 240V AC

  • Inrush Current

    80A @ 120V AC

  • Idle Power Consumption

    29W @ 120V AC, 32W @ 240V AC

  • Typical Power & Current

    Measurements done with all LEDs at maximum intensity. Measurements made at nominal voltage. Allow for a deviation of +/- 10%

  • Power Connectors In/Out

    Neutrik powerCON TRUE1

  • Data Connectors In/Out

    Neutrik XLR 5-pin

  • Max Fixtures in Series

    2x fixtures @110V, 4x Fixtures @220V

  • Control Protocol

    ANSI E1.11 USITT DMX 512-A

  • Cooling System

    Forced

  • Operating Temperature

    32 to 104 Degree F (0 to 40 Degree C)

  • Construction

    Anodized aluminum extrusion

  • Built-In Hardware

    Quick release lever for tilt adjustment

  • IP Rating

    IP20

  • Control Modes

    Strobe Options, RGBA, RGB, HSI, 1x, 2x, 3x, 4x, 6x, 8x, 12x, 24x, Look Select, Master, Odd / Even, Skip2, Skip3, Skip6

  • Dimming Curve

    Theatrical

  • Variable Effects Engine

    Strobe, Strobe on Top, Strobe Random

  • Hot Lumen Output (Combined)

    27,000 lm

  • Optics

    Fully homogenized lenses

  • Beam Angle

    26 Degree (approx.)

  • Beam Distribution

    Asymmetrical direct illumination

  • CCT

    Adjustable 1,000 - 10,000K

  • Color Gamut

    Performance enhanced

  • CRI

    92

  • Lamp Life

    L70 at 50,000 hours

  • Approvals

    CISPR 22: 2006/EN55022: 2006 & CISPR 24: 1997/EN55024: 1998, ICES-003: 2004 & FCC Part 15 Subpart B: 2007, CSA C22. No. 166-M1983:R2008 UL 1573: 2003; UL 8750

  • Dimensions (L x W x H)

    69.25 x 6.5 x 7.5" (175.89 x 16.51 x 19.05cm)

  • Weight

    53 lbs (24kg)

About Chroma-Q Color Force II Plus 72

With the Color Force II Plus 72 6' RGBA LED Fixture, Chroma-Q once again sets the standard for professional LED lighting. This updated version of the acclaimed Color Force II luminaire offers enhanced brightness and a richer color palette, all while maintaining the sleek form factor that made its predecessor a market leader. Designed for versatility, this fixture excels in cyc, wash, and effects lighting, providing powerful and precise illumination for applications up to 12 meters.

The innovative optical system features individually controlled pixels, ensuring smooth and even coverage without unsightly color shadowing. Utilizing the latest fully homogenized optics from the award-winning Chroma-Q range, the Color Force II Plus delivers a single, clean beam of light. This results in superior color blending with no color-mixing shadows, producing brighter, richer saturates, pastels, and a pure white from a single source.

The fixture's theatrical-grade dimming replicates the smooth dimming curve of traditional tungsten fixtures, enhancing its suitability for professional stage and studio environments. Proprietary calibration technologies ensure color consistency across all units, guaranteeing uniform colors even when fixtures are placed side by side.

For those seeking creative flexibility, the Color Force II Plus offers twice as many light engines within the same fixture length, with independently controllable cells every 3 inches. This allows for more intricate lighting designs and effects, making it an ideal choice for creative professionals.

Additionally, the fixture includes extensive RDM functionality, accessible through wired connections or the optional LumenRadio CRM, providing advanced control and monitoring capabilities. Experience the remarkable performance of the Color Force II Plus and elevate your lighting projects to new heights.

Chroma-Q Color Force II Plus 72 Features

  • Featuring Chroma-Q's proven award-winning technology
  • Fully useable along side original Color Force II
  • 27,000 hot lumens
  • Extremely smooth, uniform output
  • Unmatched cyc evenness
  • Homogenized RGBA color mixing
  • Rich saturated colors and smooth pastel colors
  • Pixel control to 3" (76mm) increments
  • High CRI of 92
  • Theatrical grade dimming
  • Rugged extruded aluminum body
  • Built-in power supply
  • Chroma-Q ColorSure calibration means superior fixture-to-fixture consistency
  • Works great in theatre, TV, concert touring, exhibitions, or corporate events
  • Optional internal LumenRadio
  • Touchscreen user interface

Warranty Information

This product has a limited warranty of 24 months.

Key Features

  • Experience superior color mixing with the Color Force II Plus 72 RGBA LED fixture.
  • Achieve vibrant lighting with a wide, adjustable color temperature range (1,000-10,000K).
  • Enjoy flicker-free operation with the theatrical dimming curve, great for on-camera use.
  • Easily control your lighting setup using ANSI E1.11 USITT DMX 512-A control protocol.
  • Benefit from a long-lasting LED lamp life of L70 at 50,000 hours for years of use.
  • Create dynamic effects with built-in strobe and random strobe variable effects engine.

What's in the box:

  • Chroma-Q Color Force II Plus 72 6' RGBA LED Fixture with Trunnion (Black)
  • TRUE1 to 15-5P Power Cord
  • Trunnion Mounting Bracket
  • User Manual
  • Chroma-Q 2 Year Limited Warranty
