Crown Audio LA4-D DSi 2.0 Series Next-Generation Amplifier with Dante for JBL Cinema Loudspeakers

SKU: CRLA4DNP MFR: LA4-D-NP
Earn VIP Reward Points

Key Features

  • Experience superior audio with this Crown Audio power amplifier, perfect for cinema sound systems.
  • Harness the power of 1,300W at 8 Ohms, ensuring pristine sound with low Total Harmonic Distortion.
  • Achieve optimal sound clarity with a high Signal-to-Noise Ratio, enhancing your audio experience.
  • This amplifier's high damping factor ensures tight, controlled bass for impactful low-frequency sound.
  • Benefit from reliable protection circuits, safeguarding your speakers and ensuring long-term amplifier life.
  • Integrate seamlessly with Dante/AES67 digital audio inputs for advanced network audio capabilities.
See More Product Details
Special Order?Estimated to Ship: 09/14/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$499.99

3 Year

$649.99

5 Year

$949.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Crown Audio LA4-D Specifications

User Interface

User Interface

Jump to...
  • Front-Panel Interface

    Mute and configuration with encoder

  • Front-Panel Display

    LCD display and signal LED's (input/output)

  • Channels

    4

Connectors

Jump to...
  • Analog Audio Input

    Block connector

  • Digital Audio Input (DANTE/AES67)

    2x RJ-45

  • Speaker Output

    Barrier terminal block, accommodates 10AWG wire

  • Network/Monitoring/Control

    RJ-45

  • GPIO/AUX

    2in/2out block connector

  • Power

    Standard IEC

  • Rated Power (8 Ohm)

    1,300W x 4 (1khz, 20ms Burst, 2 Channels Driven, 0.5% THD Max)

  • Rated Power (4 Ohm)

    2,200W x 4 (1khz, 20ms Burst, 2 Channels Driven, 0.5% THD Max)

  • Rated Power (2 Ohm)

    1,200W x 4 (1khz, 20ms Burst, 2 Channels Driven, 0.5% THD Max)

  • Rated Power (8 Ohm Bridged)

    4,000W x 2 (1khz, 20ms Burst, 2 Channels Driven, 0.5% THD Max)

  • Rated Power (4 Ohm Bridged)

    2,300W x 2 (1khz, 20ms Burst, 2 Channels Driven, 0.5% THD Max)

Performance

Jump to...
  • Digital Signal Processing

    96kHz, 32-bit floating point

  • Voltage Gain

    38/32/26dB (AT 4,10,16dBu Sensitivity; 4/8ohm)

  • Frequency Response (4 Ohm, 20Hz - 20kHz)

    +/-0.5dB

  • Frequency Response (4 Ohm, 20Hz - 20kHz)

    +/-0.5dB

  • Total Harmonic Distortion

    0.0035 (At Full Rated Power, From 20Hz - 20kHz)

  • Analog Input Signal-Noise Ratio('A'-WTD)

    >104dB (Ref. Rated Power)

  • Analog Input Signal-Noise, 20Hz-20kHz

    >98dB (Ref. Rated Power)

  • Intermodulation Distortion

    +/- 0.35% (60Hz AND 7kHz AT 4:1, FROM - 30dBTo Full Rated Power)

  • Damping Factor (20Hz TO 100Hz)

    >1000

  • Crosstalk

    >80dB (Below Rated Power, 20HZ - 1kHZ)

  • Common Mode Rejection

    >70dB (20Hz - 1kHz, Typical)

  • DC Output Offset (With Inputs Shorted)

    +/-10mV

  • Input Impedance

    70 k ohm balanced, 35 k ohm unblanced (Nominally Balanced, Nominally Unbalanced)

  • Maximum Input Level (Low Amp Gain Mode)

    +21dBU

  • Load Impedance Stereo/Dual Mode

    2 ohm - 16 ohm

  • Load Impedance Bridge Mono

    4 ohm - 16 ohm

  • Maximum Fan Noise (REF. dB SPL @ 1M)

    51dBA

Physical

Jump to...
  • Power Supply

    100 - 220V +/-10%, 50/60Hz

  • Sleep

    GPIO/AUX connector

  • Dimensions (D x W x H)

    17.21 x 18.98 x 3.46" (437.2 x 482 x 88mm)

  • Weight

    23.15 lbs (10.5kg)

About Crown Audio LA4-D

Discover the power and precision of the LA4-D DSi 2.0 Series Next-Generation Amplifier with Dante for JBL Cinema Loudspeakers. This advanced amplifier is part of JBL's first-ever dedicated cinema amplifier line, building upon the renowned Crown DSI Digital Screen Array amplifier technology. It seamlessly integrates the best-in-class DSP from Crown's flagship CDi DriveCore series, delivering powerful, high-quality amplification for the entire range of JBL cinema loudspeakers.

Choose from three power configurations, available in both analog and analog-plus-digital "D" versions. The "D" versions feature Dante/AES67 connectivity, allowing for streamlined hardware needs and faster, easier system deployment. These amplifiers are specifically designed to meet the power requirements of JBL cinema speakers, providing a unified JBL cinema solution.

The D-models, including the LA4-D, interface directly with Dolby Atmos, eliminating the need for additional processing hardware. JBL Cinema Speaker presets are included to simplify configuration, optimize playback audio, and protect against equipment damage.

All DSi 2.0 amplifiers, including the LA4-D, feature SNMP connectivity for networked audio distribution and immersive installations. They also interface directly with third-party theater-management and cinema-control systems.

Each model provides 4 channels of amplification with bridgeable outputs in a compact 2RU footprint. They can power up to four JBL surround speakers with a single amp channel in high-power-density 2 Ohm mode.

The DSi 2.0 series amps, including the LA4-D, incorporate best-in-class, 32-bit/96kHz floating-point DSP and Crown DriveCore technology. This innovative technology replaces hundreds of internal components with a single processing chip, resulting in superior power density, stability, and audio fidelity.

For cinema managers and integrators looking to maximize their power investment and future-proof their systems, the LA4-D DSi 2.0 Series Next-Generation Amplifier with Dante for JBL Cinema Loudspeakers delivers robust, reliable amplification in an efficient, cost-effective package.

Crown Audio LA4-D Features

  • Each amp offers 4 channels with bridgeable outputs to easily power JBL's entire line of cinema speakers
  • Amplifiers are engineered to meet exact power requirements of JBL cinema speakers, for a single JBL cinema solution
  • A new amplifier design allows for high power output at 2 Ohm (SA and MA models), enabling up to 4 surround speakers to be powered by a single channel
  • D-models interface with Dolby Atmos directly, without the need for additional processing hardware. (Future firmware update required)
  • All models feature SNMP and ethernet connectivity for networking and third-party control; SA4-D, MA4-D and LA4-D models add Dante/AES67 connectivity. (Future firmware update required)
  • All models include a HiQ port to interface with HARMAN Audio Architect control software over a standard TCP/IQ network
  • Best-in-class, 96kHz/32-bit floating-point processing incorporates FIR filtering, LevelMAX limiting, 8-channel parametric EQ, delay settings and more
  • Crown DriveCore technology replaces hundreds of amplifier parts with a single chip, for superior efficiency and reliability
  • Built-in JBL Cinema Speaker presets match all JBL cinema loudspeakers; amps are power-matched with JBL cinema speakers for optimal performance and fast system configuration
  • Recall presets, mute channels, monitor amplifier health and power on and off through a combined GPIO/AUX port
  • SNMP connectivity allows direct interfacing with third-party theater-management and cinema-control systems
  • An intuitive front-panel LCD and encoder interface let you configure amplifier settings at the push of a button

Product Documents

User Manual

Key Features

  • Experience superior audio with this Crown Audio power amplifier, perfect for cinema sound systems.
  • Harness the power of 1,300W at 8 Ohms, ensuring pristine sound with low Total Harmonic Distortion.
  • Achieve optimal sound clarity with a high Signal-to-Noise Ratio, enhancing your audio experience.
  • This amplifier's high damping factor ensures tight, controlled bass for impactful low-frequency sound.
  • Benefit from reliable protection circuits, safeguarding your speakers and ensuring long-term amplifier life.
  • Integrate seamlessly with Dante/AES67 digital audio inputs for advanced network audio capabilities.

What's in the box:

  • DSi 2.0 Amplifier
  • IEC Power Cable
  • Quick Start Guide
  • Crown Audio 6 Year Warranty
