Cable Techniques R/A XLR 3-Pin Female Connector w/A-Shell, Standard/Orange Cap
See all Cable Techniques items

Cable Techniques Low Profile Right-Angle XLR 3-Pin Female Connector with A-Shell, Standard/Orange Cap

SKU: CTAX3FN MFR: CT-AX3F-N
Be the first to review this itemAsk a Question
$9.99
Earn VIP Reward Points

Key Features

  • Achieve superior sound quality with this low profile, right-angle female XLR connector.
  • Customize your setup; adjust the cap angle from 60 to 300 degrees on this XLR adapter.
  • Enjoy long-lasting durability; this XLR connector is rated for over 1,000 operations.
  • This female XLR cable mount is perfect for tight spaces, with a compact 0.98" in-use length.
  • Ensure reliable connectivity with a robust 10A current rating on your audio cables.
  • Shield your audio signal; this XLR connector's zinc diecast shell minimizes interference.
See More Product Details
Ships from Manufacturer?
Calculate Shipping

See Options

1
Add to ListGet Sale Alert

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the purpose of the adjustable cable exit on the Low Profile Right-Angle XLR 3-Pin Female Connector?

The adjustable cable exit allows you to set the cable at a 120-degree angle around either the 3 o'clock or 9 o'clock position. This flexibility in positioning can help optimize your audio setup based on your specific needs and space constraints.

Why does the connector have a matte black shell and gold pins?

The matte black shell gives the connector a sleek, professional appearance. The gold pins are not just for aesthetics; they are known for their superior conductivity, which ensures optimal signal transmission for clear and uninterrupted audio.

Is the Low Profile Right-Angle XLR 3-Pin Female Connector compatible with other cables?

Yes, the connector is designed to be compatible with a variety of cables. It pairs well with our high-quality bulk cable sold by the meter, and it's also compatible with popular slim cable models like Belden 1804A, Mogami W2901, W3031, W2697, and Sommer Isopod SO-F22.

Can I use this connector for DIY audio projects?

Absolutely! The Low Profile Right-Angle XLR 3-Pin Female Connector is an excellent choice for DIY audio projects. Its compatibility with high-quality bulk cables and popular slim cable models makes it a versatile component for custom audio setups.

Reviews about this item

Review Summary

Cable Techniques XLR Connector Specifications

  • Color

    Cap: Orange
    Shell: Black

  • Material

    Contact: Bronze
    Set Screw: Anodized Stainless Steel
    Plastic Cap: Molded ABS thermoplastic

  • Category

    XLR

  • Mounting Style

    Cable Mount

  • Pins

    3

  • Gender

    Female

  • Termination Style

    Solder

  • RoHS

    Yes

  • Cable Outlet Diameter

    0.12 - 0.13" (3.2 - 3.4mm) (Max)

  • Shell

    Zinc Diecast

  • Voltage Rating

    50V

  • Current Rating

    10A

  • In-Use Length

    0.98" (25mm) exposed lengthin-use

  • Set Screw Hex Size

    0.059" (1.5mm)

  • Cap Angle Adjust

    60 Degree to 120 Degree and 240 Degree to 300 Degree

  • Life

    >1,000 operations

  • Thermal Range

    -58 Degree F to +176 Degree F (-50 Degree C to + 80 Degree C)

  • Dimensions

    1.45 x 0.74 x 0.74" (37 x 19 x 19mm) (with Cap)

  • Weight

    1.2 oz (34g)

About Cable Techniques XLR Connector

Experience superior connectivity with the Low Profile Right-Angle XLR 3-Pin Female Connector with A-Shell. This high-quality connector features an adjustable multi-angle cable exit that can be set at 120 degrees around either the 3 o'clock or 9 o'clock position, offering you flexibility and convenience in your audio setup.

The connector is housed in a sleek, matte black shell, fitted with gold pins for optimal signal transmission, ensuring clear and uninterrupted audio. Its standard cap is designed to accommodate cable diameters of up to 3.4mm, making it a versatile addition to your audio equipment.

The Low Profile Right-Angle XLR 3-Pin Female Connector is not just about functionality, it's also about compatibility. It pairs seamlessly with our high-quality bulk cable sold by the meter, perfect for those engaging in DIY projects. Moreover, it's compatible with popular slim cable models such as Belden 1804A, Mogami W2901, W3031, W2697, and Sommer Isopod SO-F22.

In essence, this connector is designed to deliver reliable performance and broad compatibility, making it an essential component for your audio and video equipment.

Cable Techniques XLR Connector Features

  • Low-Profile Right Angle
  • A Shell
  • 120 Degree adjustment swing
  • Black shell, Gold Contacts

Warranty Information

This product has a limited warranty of 12 months.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Achieve superior sound quality with this low profile, right-angle female XLR connector.
  • Customize your setup; adjust the cap angle from 60 to 300 degrees on this XLR adapter.
  • Enjoy long-lasting durability; this XLR connector is rated for over 1,000 operations.
  • This female XLR cable mount is perfect for tight spaces, with a compact 0.98" in-use length.
  • Ensure reliable connectivity with a robust 10A current rating on your audio cables.
  • Shield your audio signal; this XLR connector's zinc diecast shell minimizes interference.

What's in the box:

  • Cable Techniques A-Shell
  • 3-Pin Insert
  • Standard/Orange Cap
  • 2x Set Screws
  • Zip-Tie
  • Cable Techniques 1 Year Limited Warranty
