Cable Techniques Low Profile Right-Angle XLR 3-Pin Female Connector with A-Shell, Standard/Yellow Cap

SKU: CTAX3FY MFR: CT-AX3F-Y
$9.99
Earn VIP Reward Points

Key Features

  • Achieve superior sound with this low profile, right-angle female XLR connector.
  • Customize your setup; cap adjusts from 60 to 300 degrees for perfect cable runs.
  • Built tough with zinc diecast shell; this durable XLR connector lasts over 1,000 uses.
  • Ensure reliable audio; features bronze contacts and a 50V voltage rating.
  • Simplify connections; solder termination and included set screws make setup easy.
  • Compact design (1.45") fits tight spaces; ideal for pro audio & custom cabling.
See More Product Details
Ships from Manufacturer?
Calculate Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the unique feature of the A-Shell in this XLR connector?

The A-Shell of this XLR connector allows for an adjustable multi-angle cable exit. This means you can rotate the cable outlet 120 degrees around the 3 o'clock or 9 o'clock positions, providing flexibility in tight spaces or specific setup requirements.

Is this XLR connector compatible with any professional audio cables?

Yes, the standard yellow cap of this connector can accommodate cable diameters up to 3.4mm. It is also designed to work seamlessly with popular slim cable models, including Belden 1804A, Mogami W2901, W3031, W2697, and Sommer Isopod SO-F22.

Why does the connector use gold pins?

Gold is known for its excellent electrical conductivity and resistance to corrosion. The gold pins in this connector ensure a secure and high-quality connection with minimal signal loss, making it ideal for professional audio and video applications.

What are some typical uses for this XLR connector?

This low-profile right-angle XLR connector is perfect for use in professional audio and video applications. It's often used for connecting microphones or other audio devices to a mixer or recorder, especially in settings where space is limited or a low profile is desired.

Reviews about this item

Review Summary

Cable Techniques XLR Connector Specifications

  • Color

    Cap: Yellow
    Shell: Black

  • Material

    Contact: Bronze
    Set Screw: Anodized Stainless Steel
    Plastic Cap: Molded ABS thermoplastic

  • Category

    XLR

  • Mounting Style

    Cable Mount

  • Pins

    3

  • Gender

    Female

  • Termination Style

    Solder

  • RoHS

    Yes

  • Cable Outlet Diameter

    0.12 - 0.13" (3.2 - 3.4mm) (Max)

  • Shell

    Zinc Diecast

  • Voltage Rating

    50V

  • Current Rating

    10A

  • In-Use Length

    0.98" (25mm) exposed lengthin-use

  • Set Screw Hex Size

    0.059" (1.5mm)

  • Cap Angle Adjust

    60 Degree to 120 Degree and 240 Degree to 300 Degree

  • Life

    >1,000 operations

  • Thermal Range

    -58 Degree F to +176 Degree F (-50 Degree C to + 80 Degree C)

  • Dimensions

    1.45 x 0.74 x 0.74" (37 x 19 x 19mm) (with Cap)

  • Weight

    1.2 oz (34g)

About Cable Techniques XLR Connector

Where space is at a premium and audio quality is essential, the Low-Profile Right-Angle XLR 3-Pin Female Connector with A-Shell stands out as the professional's choice. This durable and high-quality connector is designed to facilitate a seamless and reliable connection in even the most compact and demanding environments. The A-Shell feature offers an adjustable multi-angle cable exit, providing flexibility with a 120-degree rotation around the 3 o'clock or 9 o'clock positions. The matte black shell, complemented by corrosion-resistant gold pins, ensures a secure connection with minimal signal loss, making it a versatile addition to any audio technician's toolkit.

The standard yellow cap of this connector is engineered to accommodate cable diameters up to 3.4mm, ensuring compatibility with a wide range of professional audio cables. For those who prefer custom solutions, Cable Techniques offers high-quality bulk cable sold by the meter, perfect for DIY projects tailored to specific needs. Moreover, this connector is designed to work seamlessly with popular slim cable models, including Belden 1804A, Mogami W2901, W3031, W2697, and Sommer Isopod SO-F22, offering a reliable and affordable solution for high-fidelity audio transmission.

Whether you're connecting microphones, mixers, or recorders, this Low-Profile Right-Angle XLR Connector is the ideal choice for audio professionals seeking a compact, high-performance, and easy-to-use interface. Its robust construction and thoughtful design by Cable Techniques underscore a commitment to quality that audio and video professionals have come to trust.

Cable Techniques XLR Connector Features

  • Low-Profile Right Angle
  • A Shell
  • 120 Degree adjustment swing
  • Black shell, Gold Contacts

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Achieve superior sound with this low profile, right-angle female XLR connector.
  • Customize your setup; cap adjusts from 60 to 300 degrees for perfect cable runs.
  • Built tough with zinc diecast shell; this durable XLR connector lasts over 1,000 uses.
  • Ensure reliable audio; features bronze contacts and a 50V voltage rating.
  • Simplify connections; solder termination and included set screws make setup easy.
  • Compact design (1.45") fits tight spaces; ideal for pro audio & custom cabling.

What's in the box:

  • Cable Techniques A-Shell
  • 3-Pin Insert
  • Standard/Yellow Cap
  • 2x Set Screws
  • Zip-Tie
  • Cable Techniques 1 Year Limited Warranty
