Cable Techniques Low Profile Right-Angle XLR 3-Pin Female Connector with B-Shell, Standard/Yellow Cap

SKU: CTBX3FY MFR: CT-BX3F-Y
$9.99
Earn VIP Reward Points

Key Features

  • Achieve superior sound quality with this low-profile, right-angle female XLR connector.
  • Customize your setup; the adjustable cap angles from 60° to 300° for easy cable management.
  • Built to last, the durable zinc diecast shell ensures reliable performance for over 1,000 uses.
  • Perfect for tight spaces, its compact design offers a short 0.98" in-use length XLR solution.
  • Enjoy broad compatibility; this 3-Pin female XLR connector works in diverse audio applications.
  • Secure your connections with anodized stainless steel set screws on this robust XLR adapter.
See More Product Details
Ships from Manufacturer?
Calculate Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Cable Techniques XLR Connector Specifications

  • Color

    Cap: Yellow
    Shell: Black

  • Material

    Contact: Bronze
    Set Screw: Anodized Stainless Steel
    Plastic Cap: Molded ABS thermoplastic

  • Category

    XLR

  • Mounting Style

    Cable Mount

  • Pins

    3

  • Gender

    Female

  • Termination Style

    Solder

  • RoHS

    Yes

  • Cable Outlet Diameter

    0.12 - 0.13" (3.2 - 3.4mm) (Max)

  • Shell

    Zinc Diecast

  • Voltage Rating

    50V

  • Current Rating

    10A

  • In-Use Length

    0.98" (25mm) exposed lengthin-use

  • Set Screw Hex Size

    0.059" (1.5mm)

  • Cap Angle Adjust

    60 Degree to 120 Degree and 240 Degree to 300 Degree

  • Life

    >1,000 operations

  • Thermal Range

    -58 Degree F to +176 Degree F (-50 Degree C to + 80 Degree C)

  • Dimensions

    1.45 x 0.74 x 0.74" (37 x 19 x 19mm) (with Cap)

  • Weight

    1.2 oz (34g)

About Cable Techniques XLR Connector

Bring precision and reliability to your audio and video setups with the Low Profile Right-Angle XLR 3-Pin Female Connector with B-Shell. Crafted by Cable Techniques, a brand synonymous with high-quality audio and video cables, this connector is designed to meet the demands of professional applications.

This durable connector features a right-angle design, making it an ideal choice for tight spaces and preventing cable damage or kinking. It's versatile, offering an adjustable multi-angle cable exit that can be set at 120 degrees around either the 6 o'clock or 12 o'clock position. This unique feature allows for greater flexibility in arranging your equipment, ensuring optimal performance.

The connector comes with a matte black shell and gold pins, a testament to its high-quality construction. The standard yellow cap can accommodate cable diameters up to 3.4mm, providing a secure and reliable connection.

Compatibility is key with this connector. The standard cap is designed to work seamlessly with popular slim cable models such as Belden 1804A, Mogami W2901, W3031, W2697, and Sommer Isopod SO-F22.

In short, this Low Profile Right-Angle XLR 3-Pin Female Connector with B-Shell is an affordable, high-quality solution for your professional audio and video needs.

Cable Techniques XLR Connector Features

  • Low Profile Right Angle
  • B-Shell
  • Black shell, Gold Contacts

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Achieve superior sound quality with this low-profile, right-angle female XLR connector.
  • Customize your setup; the adjustable cap angles from 60° to 300° for easy cable management.
  • Built to last, the durable zinc diecast shell ensures reliable performance for over 1,000 uses.
  • Perfect for tight spaces, its compact design offers a short 0.98" in-use length XLR solution.
  • Enjoy broad compatibility; this 3-Pin female XLR connector works in diverse audio applications.
  • Secure your connections with anodized stainless steel set screws on this robust XLR adapter.

What's in the box:

  • Cable Techniques B-Shell
  • 3-Pin Insert
  • Standard/Yellow Cap
  • 2x Set Screws
  • Zip-Tie
  • Cable Techniques 1 Year Limited Warranty
