Cable Techniques Low Profile Right-Angle XLR 3-Pin Male Connector with B-Shell, Standard/Green Cap

SKU: CTBX3MG MFR: CT-BX3M-G
$9.99
Earn VIP Reward Points

Key Features

  • Achieve superior sound quality with this low profile, right-angle 3-Pin Male XLR connector.
  • Customize your setup with the adjustable cap, offering versatile angle options from 60° to 300°.
  • Ensure long-lasting performance; this durable XLR connector is rated for over 1,000 operations.
  • Experience reliable connectivity with a robust design tested within a wide thermal range.
  • Simplify cable management using this compact XLR connector, ideal for tight spaces and clean setups.
  • Enjoy a secure and stable connection with the anodized stainless steel set screws on this XLR.
See More Product Details
Ships from Manufacturer?
Calculate Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Cable Techniques XLR Connector Specifications

  • Color

    Cap: Green
    Shell: Black

  • Material

    Contact: Bronze
    Set Screw: Anodized Stainless Steel
    Plastic Cap: Molded ABS thermoplastic

  • Category

    XLR

  • Mounting Style

    Cable Mount

  • Pins

    3

  • Gender

    Male

  • Termination Style

    Solder

  • RoHS

    Yes

  • Cable Outlet Diameter

    0.12 - 0.13" (3.2 - 3.4mm) (Max)

  • Shell

    Zinc Diecast

  • Voltage Rating

    50V

  • Current Rating

    10A

  • In-Use Length

    0.98" (25mm) exposed lengthin-use

  • Set Screw Hex Size

    0.059" (1.5mm)

  • Cap Angle Adjust

    60 Degree to 120 Degree and 240 Degree to 300 Degree

  • Life

    >1,000 operations

  • Thermal Range

    -58 Degree F to +176 Degree F (-50 Degree C to + 80 Degree C)

  • Dimensions

    1.37 x 0.70 x 0.70" (35 x 18 x 18mm) (with Cap)

  • Weight

    0.7 oz (19.8g)

About Cable Techniques XLR Connector

Make your audio connections seamless and efficient with the Low Profile Right-Angle XLR 3-Pin Male Connector with B-Shell. This professional-grade connector, crafted by the reputable brand Cable Techniques, is renowned for its durability and high-quality performance in audio and video applications.

Designed with a versatile and adjustable multi-angle cable exit, it offers 120-degree rotation around either the 6 o'clock or 12 o'clock position. This feature allows for optimal cable management and placement, particularly in tight spaces. The connector's matte black shell houses gold pins, ensuring reliable and superior signal transmission for your audio needs.

The standard green cap not only aids in easy identification of your cables but also accommodates cable diameters up to 3.4mm. This makes it a versatile choice for various audio setups, from connecting a microphone to a mixer or soundboard.

Moreover, this Low Profile Right-Angle XLR 3-Pin Male Connector is compatible with popular slim cable models such as Belden 1804A, Mogami W2901, W3031, W2697, and Sommer Isopod SO-F22. This compatibility further enhances its versatility, making it a valuable addition to your audio equipment collection.

In summary, this connector is a reliable, high-quality, and versatile solution for your audio connection needs, offering professional-grade performance and easy cable management.

Cable Techniques XLR Connector Features

  • Low Profile Right Angle
  • B-Shell
  • Black shell, Gold Contacts

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Achieve superior sound quality with this low profile, right-angle 3-Pin Male XLR connector.
  • Customize your setup with the adjustable cap, offering versatile angle options from 60° to 300°.
  • Ensure long-lasting performance; this durable XLR connector is rated for over 1,000 operations.
  • Experience reliable connectivity with a robust design tested within a wide thermal range.
  • Simplify cable management using this compact XLR connector, ideal for tight spaces and clean setups.
  • Enjoy a secure and stable connection with the anodized stainless steel set screws on this XLR.

What's in the box:

  • Cable Techniques B-Shell
  • 3-Pin Insert
  • Standard/Green Cap
  • 2x Set Screws
  • Zip-Tie
  • Cable Techniques 1 Year Limited Warranty
