20% Off

Comprehensive Pro AV/IT HDBaseT 4K60 18G Single Gang HDMI/VGA/Audio Wall Plate Extender Kit, 230' Range

SKU: CVHDBTWP110K MFR: CHE-HDBTWP110K
Earn VIP Reward Points

Key Features

  • Extend HDMI, VGA, & Audio up to 230' with this HDBaseT extender kit, perfect for home or office use.
  • Enjoy stunning 4K@60Hz resolution with this HDMI wall plate extender, ensuring crystal-clear visuals.
  • This durable metal HDBaseT kit offers superior ESD protection, safeguarding your devices from damage.
  • Simplify installations with the included single-gang faceplate, making setup a breeze for any user.
  • Experience versatile connectivity with HDMI, VGA, & USB ports for seamless integration of your devices.
  • Power over HDBaseT (POH) delivers power and video over a single cable, reducing clutter and install time.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$79.99

2 Year

$139.00

3 Year

$199.00

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Comprehensive Wall Plate Extender Specifications

Performance & Resolution

Performance & Resolution

Jump to...
  • Audio Formats Supported

    LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD

  • CEC

    Yes

  • Color Bit Depth

    10-bit, 12-bit

  • Color Space

    RGB/YCbCr 4:4:4, YCbCr 4:2:2

  • Data Speed

    18Gbps (bandwidth)

  • Distances Supported

    4K@60Hz - 70M (230')
    1080p@60Hz - 100M (330')

  • HDCP Version

    2.2 version

  • Baud Rate

    Up to 115200bps

  • Resolution and Refresh Rate

    HDMI: 4K2K@60Hz(YUV4:4:4)
    VGA: 1080P 3D@60hz

  • Signal Technology Versions

    HDMI 2.0

Connections

Jump to...
  • Transmitter Inputs

    1x HDMI Type A (19-pin female)
    1x VGA (15-pin female)
    1x USB Type A
    3.5 mm Audio Port

  • Transmitter Outputs

    1x HDBaseT In (RJ-45)

  • Receiver Inputs

    1x HDBaseT In (RJ-45)
    1x 3.5 mm Audio Port

  • Receiver Outputs

    1x HDMI Type A (19-pin female)
    VGA (15-pin female)
    USB Type A
    3.5 mm Audio Port

Environmental

Jump to...
  • Humidity

    20-90% RH

  • Operating Temperature

    32 Degree - 104 Degree F (0 Degree - 40 Degree C)

  • Storage Temperature

    -4 Degree - 140 Degree F (-20 Degree - 60 Degree C)

  • Input

    AC100 - 240V 50/60Hz

  • Output

    12V/3A DC

  • P.O.H

    Yes

  • Power Consumption

    20 Watts

Regulatory Device

Jump to...
  • CE

    Yes

  • Prop 65 Compliant

    No

  • Rohs Compliant

    Yes

Regulatory Power Supply

Jump to...
  • CE

    Yes

  • Prop 65 Compliant

    No

  • Rohs Compliant

    Yes

  • UL

    Yes

Physical

Jump to...
  • Color

    Black

  • Material

    Metal

  • ESD Protection

    Human Body Model:
    +/-12kV (Air Discharge)
    +/-8kV (Contact Discharge)

  • Dimensions (W x H x D)

    Transmitter: 4.9 x 2.8 x 1.8" (12.45 x 7.12 x 4.57cm)
    Receiver: 9.12 x 0.98 x 4.25" (23.16 x 2.49 x 10.79cm)

  • UPC Code

    808447081756

About Comprehensive Wall Plate Extender

How can you extend your 4K HDMI, audio, and USB signals up to 330 feet with ease and reliability The answer lies in the Comprehensive's CHE-HDBTWP110K Wall Plate Extender kit. This innovative device is more than just an HDMI and VGA switch; it's a powerful tool that embeds audio and employs HDBaseT technology for superior output.

This transmitter is capable of sending uncompressed high-definition video and audio over a single cable, reaching distances of up to 330 feet at 1080p@60Hz. It's designed to support high-resolution inputs, with the HDMI input accommodating up to 4K@60Hz (4:4:4, 8-bit) for a distance of 230 feet, and the VGA input supporting resolutions up to 1920x1200.

Designed to fit U.S. single-gang sized enclosures, this high-quality, durable wall plate extender kit is a versatile solution for both commercial and residential settings. It features automatic input detection between the HDMI and VGA inputs, along with hot plug detection for easy, hands-free operation.

The device also includes a multi-function button on the unit's face, providing access to an information OSD and allowing manual input selection when necessary. With PoH (Power Over HDBaseT) capability, this transmitter can be powered locally or via 48V PoH from the HDBaseT Receiver (PSE), offering additional flexibility in installations.

Control is at your fingertips with this easy-to-use device. It can be managed via the front panel button with OSD, WebGUI, Telnet, and RS-232, making it exceptionally adaptable. When connected to the Receiver, you gain access to additional features such as EDID management, HDCP management, and basic signal event automation (via RS-232 or CEC).

Trust in the quality of Comprehensive's products, a company that has been manufacturing top-tier commercial-grade solutions for AV and IT professionals since 1974. The CHE-HDBTWP110K extender kit continues this tradition, crafted with high-end materials and components, and subjected to rigorous quality control to ensure years of worry-free use.

Comprehensive Wall Plate Extender Features

  • HDMI 2.0 and HDCP 2.2 compliant
  • HDMI, VGA with 3.5mm mini-jack audio input
  • Wall plate is designed for US one-gang sized enclosures
  • Supports HDMI input resolutions up to 4K@60Hz (4:4:4, 8-bit)
  • Supports VGA input resolutions up to 1920 x 1200
  • Analog stereo audio may be embedded with VGA or HDMI source
  • HDBaseT output supports resolutions up to 4K@60Hz (4:2:0, 8-bit) with automatic color space conversion of 4K@50/60Hz (4:4:4, 8-bit) or 4K@any (10/12-bit) sources
  • Simultaneous transmission of uncompressed video, audio and data over a single 100m/328ft Cat.5e/6/7 cable at 1080p/60 and 70m/230' at 4K
  • Supports CEC bypass
  • User activated information OSD
  • Unit may be powered locally or via 48V PoH from the HDBaseT Receiver (PSE)
  • Supports manual input selection or automatic input selection with hot plug detection
  • Basic signal event automation (via RS-232 or CEC w/ compatible Receiver)
  • USB port supports firmware update and powering of 5V/500mA devices
  • Front panel LEDs indicate HDCP mode, input source, and power
  • Controllable via a multi-function front panel button with OSD, or via WebGUI, Telnet, and RS-232
  • 1-Gang Wall plate is designed for US one-gang sized enclosures
  • TAA Compliant

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • Extend HDMI, VGA, & Audio up to 230' with this HDBaseT extender kit, perfect for home or office use.
  • Enjoy stunning 4K@60Hz resolution with this HDMI wall plate extender, ensuring crystal-clear visuals.
  • This durable metal HDBaseT kit offers superior ESD protection, safeguarding your devices from damage.
  • Simplify installations with the included single-gang faceplate, making setup a breeze for any user.
  • Experience versatile connectivity with HDMI, VGA, & USB ports for seamless integration of your devices.
  • Power over HDBaseT (POH) delivers power and video over a single cable, reducing clutter and install time.

What's in the box:

  • HDMI Over HDBaseT Wallplate Transmitter
  • HDMI Over HDBaseT Receiver
  • Single-Gang Faceplate
  • 2x Faceplate Screws
  • 2-Pin Terminal Block
  • IR Blast Cable
  • IR Extender Cable
  • 48V/0.83A DC Power Adapter
  • Power Cord
  • User Manual
  • Comprehensive 3 Year Limited Warranty
