Comprehensive 328' (100m) LC to SC OM1 MM 3.0 MM Duplex Plenum Patch Cable
See all Comprehensive items
20% Off

Comprehensive 328' (100m) LC Male to SC Male OM1 MM 3.0 MM Duplex Plenum Patch Cable

SKU: CVLCSCMMP100 MFR: LC-SC-MMP-100M
Be the first to review this itemAsk a Question
$271.99
$339.99
Save: $68 (20%)
OR
$46/mo suggested payments with 6‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Ensure reliable data transfer with this 328ft LC to SC Fiber Optic cable.
  • Experience superior connectivity using our durable, high-quality plenum patch cable.
  • This OM1 Multimode duplex cable supports fast Ethernet for quick data transmissions.
  • Built for longevity, this Comprehensive cable offers a lifetime limited warranty.
  • Minimize signal loss with our low insertion loss LC to SC connectors (0.20dB typical).
  • Plenum-rated jacket ensures safe in-wall installations for your network cable setup.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

1 Year

$44.99

2 Year

$79.99

3 Year

$109.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Comprehensive LC-SC-MMP-100M Specifications

  • Connector 1

    LC Male

  • Connector 2

    SC Male

  • Length

    328' (100m)

  • Maximum Connector Loss

    0.30 dB

  • Typical Connector Loss

    0.20 dB

  • Typical Return Loss

    -25 dB

  • Buffer Material

    PVC

  • Buffer OD

    900 um

  • Jacket Material

    PVC (OFNR riser-rated)

  • Jacket OD

    3.0mm / 0.11"

  • Installation Tensile Load

    100 N (445 lbs)

  • Long-Term Tensile Load

    50 N (222 lbs)

  • Maximum Tensile Load

    100 N/cm

  • Installation (Loaded) Bend Radius

    Minimum: 5.0cm (1.97")

  • Long-Term (Unloaded) Minimum Bend Radius

    3.0cm (1.2")

  • Crush Resistance

    750 N/cm

  • Impact Resistance

    1,000 cycles

  • Flex Resistance

    5,000 cycles

  • Attenuation at 1300 nm

    1.0 dB/km

  • Attenuation at 850 nm

    3.5 dB/km

  • Operating Temperature

    -20C to +80C

  • RoHS Compliant

    Yes

  • Dimensions (H x W x D)

    LC Connector: 10.75 x 12.5 x 50mm / 0.42 x 0.49 x 1.96" (with installed duplex clip)
    SC Connector: 10.6 x 26 x 58mm / 0.41 x 1.02 x 2.28" (with installed duplex clip)

  • Weight

    3lbs (1.36kg)

  • UPC Code

    808447069549

About Comprehensive LC-SC-MMP-100M

The Comprehensive 328' (100m) LC TO SC OM1 MM 3.0 MM Duplex Plenum Patch Cable assemblies are made of the finest quality materials. Color coded connectors for convenience. LC/SC Duplex 62.5/125 MM Fiber Patch Cable - Orange 62.5/125 micron cable for fast ethernet, fibre channel, Infiniband, ATM and gigabit ethernet applications that require high speed data transfer. This cable is 100% optically inspected and tested for insertion loss.

Comprehensive LC-SC-MMP-100M Features

  • Exceptional Value
  • Comprehensive Reliability
  • Designed for Gigabit Ethernet applications
  • 100% Optically Inspected and Tested

Warranty Information

This product has a limited lifetime warranty.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Ensure reliable data transfer with this 328ft LC to SC Fiber Optic cable.
  • Experience superior connectivity using our durable, high-quality plenum patch cable.
  • This OM1 Multimode duplex cable supports fast Ethernet for quick data transmissions.
  • Built for longevity, this Comprehensive cable offers a lifetime limited warranty.
  • Minimize signal loss with our low insertion loss LC to SC connectors (0.20dB typical).
  • Plenum-rated jacket ensures safe in-wall installations for your network cable setup.

What's in the box:

  • Comprehensive 328' (100m) Duplex Plenum Patch Cable
  • Comprehensive Lifetime Limited Warranty
