Comprehensive 246' (75m) LC Male to SC Male OM1 MM 3.0 MM Duplex Plenum Patch Cable

SKU: CVLCSCMMP75M MFR: LC-SC-MMP-75M
Earn VIP Reward Points

Key Features

  • Experience reliable connectivity with this 246' LC to SC fiber optic cable.
  • Ensure optimal performance with a low maximum connector loss of just 0.30 dB.
  • This durable plenum patch cable is built to last, featuring robust PVC buffer material.
  • Enjoy peace of mind with our lifetime limited warranty on this premium fiber cable.
  • Perfect for high-density networking, offering a minimum bend radius of 3.0cm.
  • Trust in consistent data transfer with a typical return loss of -25 dB on connectors.
See More Product Details
Temporarily On Backorder?Expected Availability: 09/2025Request assistance or get notified
Free Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

1 Year

$29.99

2 Year

$53.99

3 Year

$69.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Comprehensive LC-SC-MMP-75M Specifications

  • Connector 1

    LC Male

  • Connector 2

    SC Male

  • Length

    246' (75m)

  • Maximum Connector Loss

    0.30 dB

  • Typical Connector Loss

    0.20 dB

  • Typical Return Loss

    -25 dB

  • Buffer Material

    PVC

  • Buffer OD

    900 um

  • Jacket Material

    PVC (OFNR riser-rated)

  • Jacket OD

    3.0mm / 0.11"

  • Installation Tensile Load

    100 N (445 lbs)

  • Long-Term Tensile Load

    50 N (222 lbs)

  • Maximum Tensile Load

    100 N/cm

  • Installation (Loaded) Bend Radius

    Minimum: 5.0cm (1.97")

  • Long-Term (Unloaded) Minimum Bend Radius

    3.0cm (1.2")

  • Crush Resistance

    750 N/cm

  • Impact Resistance

    1,000 cycles

  • Flex Resistance

    5,000 cycles

  • Attenuation at 1300 nm

    1.0 dB/km

  • Attenuation at 850 nm

    3.5 dB/km

  • Operating Temperature

    -20C to +80C

  • RoHS Compliant

    Yes

  • Dimensions (H x W x D)

    LC Connector: 10.75 x 12.5 x 50mm / 0.42 x 0.49 x 1.96" (with installed duplex clip)
    SC Connector: 10.6 x 26 x 58mm / 0.41 x 1.02 x 2.28" (with installed duplex clip)

  • Weight

    2.75lbs (1.25kg)

  • UPC Code

    808447069532

About Comprehensive LC-SC-MMP-75M

Where high-speed data transfer is a necessity, the Comprehensive 246' (75m) LC to SC OM1 MM 3.0 MM Duplex Plenum Patch Cable stands out as a superior choice. Crafted from the highest quality materials, this durable and reliable fiber optic patch cable is designed to support fast Ethernet, fibre channel, Infiniband, ATM, and gigabit Ethernet applications, ensuring optimal performance in all your networking needs.

This 62.5/125 micron cable, highlighted in a distinctive orange color, signifies its function as an optical fiber cable, utilizing light to transmit data at impressive speeds. The duplex design of this cable allows for bidirectional data transmission, making it an ideal solution for complex networking applications.

The cable features a male LC connector at one end and a male SC connector at the other, providing easy and flexible installation. The connectors are color-coded for your convenience, simplifying the process of connecting your devices. Each cable is 100% optically inspected and rigorously tested for insertion loss, guaranteeing a high-quality, reliable connection every time.

Whether you're connecting computers, routers, switches, or other networking equipment, the Comprehensive 246' (75m) LC to SC OM1 MM 3.0 MM Duplex Plenum Patch Cable delivers the quality and reliability you need for your Ethernet networking requirements.

Comprehensive LC-SC-MMP-75M Features

  • Exceptional Value
  • Comprehensive Reliability
  • Designed for Gigabit Ethernet applications
  • 100% Optically Inspected and Tested

Warranty Information

This product has a limited lifetime warranty.

Key Features

  • Experience reliable connectivity with this 246' LC to SC fiber optic cable.
  • Ensure optimal performance with a low maximum connector loss of just 0.30 dB.
  • This durable plenum patch cable is built to last, featuring robust PVC buffer material.
  • Enjoy peace of mind with our lifetime limited warranty on this premium fiber cable.
  • Perfect for high-density networking, offering a minimum bend radius of 3.0cm.
  • Trust in consistent data transfer with a typical return loss of -25 dB on connectors.

What's in the box:

  • Comprehensive 246' (75m) Duplex Plenum Patch Cable
  • Comprehensive Lifetime Limited Warranty
