Comprehensive 3m LC Male to ST Male Duplex 62.5/125 Multimode Fiber Patch Cable
See all Comprehensive items
20% Off

Comprehensive 3M LC Male to ST Male Duplex 62.5/125 Multimode Fiber Patch Cable

SKU: CVLCSTMM3M MFR: LC-ST-MM-3M
Be the first to review this itemAsk a Question
$27.19
$33.99
Save: $6.8 (20%)
Earn VIP Reward Points

Key Features

  • This 3M fiber patch cable ensures reliable connectivity between LC and ST devices.
  • Experience minimal signal loss with our high-quality fiber optic cable (0.20 dB typical).
  • Built for durability, this Ethernet cable withstands 1,000 impact cycles easily.
  • Our multimode fiber cable is RoHS compliant, ensuring environmental responsibility.
  • Use this LC to ST cable in a wide range of temperatures (-20C to +80C)!
  • Get optimal performance with this Comprehensive fiber cable, featuring low return loss (-25dB).
See More Product Details
Free Shipping

See Options

1
Add to ListGet Sale Alert

Add Adorama Protect:

Available to U.S. customers only.
1-Year Adorama Protect$3.99
2-Year Adorama Protect$5.99
3-Year Adorama Protect$8.99

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Comprehensive LC-ST-MM-3M Specifications

  • Connector 1

    LC Male

  • Connector 2

    ST Male

  • Cable Length

    3m/9.84'

  • Maximum Connector Loss

    0.30 dB

  • Typical Connector Loss

    0.20 dB

  • Typical Return Loss

    -25 dB

  • Buffer Material

    PVC

  • Buffer OD

    900 um

  • Jacket Material

    PVC (OFNR riser-rated)

  • Jacket OD

    3.0mm / 0.11"

  • Installation Tensile Load

    100 N (445 lbs)

  • Long-Term Tensile Load

    50 N (222 lbs)

  • Maximum Tensile Load

    100 N/cm

  • Installation (Loaded) Bend Radius

    Minimum: 5.0cm (1.97")

  • Long-Term (Unloaded) Minimum Bend Radius

    3.0cm (1.2")

  • Crush Resistance

    750 N/cm

  • Impact Resistance

    1,000 cycles

  • Flex Resistance

    5,000 cycles

  • Attenuation at 1300 nm

    1.0 dB/km

  • Attenuation at 850 nm

    3.5 dB/km

  • Operating Temperature

    -20C to +80C

  • RoHS Compliant

    Yes

  • LC Connector Dimensions (H x W x D)

    10.75 x 12.5 x 50mm / 0.42 x 0.49 x 1.96" (with installed duplex clip)

  • ST Connector Dimensions (H x W x D)

    9.8 x 19.6 x 59mm / 0.38 x 0.77 x 2.32"

  • Weight

    0.6lbs / 0.27kg

  • UPC Code

    808447045734

About Comprehensive LC-ST-MM-3M

Overcome your data transfer challenges with the 3M LC Male to ST Male Duplex 62.5/125 Multimode Fiber Patch Cable. Crafted from the highest-quality materials, this durable and reliable fiber patch cable is designed to deliver superior performance for your Ethernet networking needs.

This 10-foot long, black duplex fiber optic cable is specifically engineered for high-speed data transfer applications such as Fast Ethernet, Fibre Channel, Infiniband, ATM, and Gigabit Ethernet. Its duplex design allows for faster and more efficient data transmission compared to single-mode cables, making it an ideal choice for connecting devices like computers, routers, switches, and other networking equipment.

The cable features color-coded connectors for easy identification and convenience, reducing the risk of incorrect connections. Each cable undergoes rigorous optical inspection and testing for insertion loss, ensuring you receive a product that meets the highest standards of quality and reliability.

Experience the difference in data transfer speed and efficiency with the 3M LC Male to ST Male Duplex 62.5/125 Multimode Fiber Patch Cable, a testament to 3M's reputation for producing high-quality, reliable networking solutions.

Comprehensive LC-ST-MM-3M Features

  • Exceptional Value
  • Comprehensive Reliability
  • Designed for Gigabit Ethernet applications
  • Optical Multimode 1 (OM1) fiber supporting 200/500 MHz.km OFL at 850/1300 nm
  • 100% Optically Inspected and Tested

Warranty Information

This product has a limited lifetime warranty.
