What type of devices is the PR2200RTXL2UN UPS suitable for?

The PR2200RTXL2UN UPS is suitable for sensitive electronic equipment such as servers, workstations, networking hardware, and other critical devices that require consistent power and protection from power interruptions.

Can I manage the PR2200RTXL2UN UPS remotely?

Yes, the PR2200RTXL2UN UPS comes with a pre-installed RMCARD205 network management card, allowing for remote management and monitoring through a standard web browser or network management system.

What does the multifunction LCD panel on the UPS display?

The rotatable multifunction LCD panel displays 47 different settings, including UPS status, setup and control management, battery life, load capacity, and various testing options.

Is the PR2200RTXL2UN UPS energy efficient?

Yes, the PR2200RTXL2UN UPS is ENERGY STAR certified, indicating high energy efficiency. It also features CyberPower's GreenPower UPS Bypass Design which reduces energy consumption and heat generation.

How does the Automatic Voltage Regulation (AVR) feature work?

The Automatic Voltage Regulation (AVR) feature in the PR2200RTXL2UN UPS corrects minor power fluctuations without switching to battery power, thereby providing clean, consistent AC power to your devices.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

CyberPower PR2200RTXL2UN Specifications

General

General

Jump to...
  • Active PFC Compatible

    Yes

  • Energy Saving

    GreenPower UPS Bypass Technology

  • Energy Star Certified

    Yes

  • UPS Topology

    Line-Interactive

Battery

Jump to...
  • Battery Quantity

    4

  • Battery Size

    12V/9Ah

  • Battery Type

    Sealed Lead-Acid

  • Extended Battery Module

    BP48VP2U02

  • Extended Battery Option

    Yes

  • Hot-Swappable

    Yes

  • Replacement Battery Cartridge

    RB1290X4J

  • Replacement Battery Cartridge Quantity

    1

  • Runtime at Full Load

    3.2 minutes

  • Runtime at Half Load

    10 minutes

  • Typical Recharge Time

    3 hrs

  • User Replaceable

    Yes

  • Adjustable Voltage Range

    70 - 155 Vac

  • Circuit Breaker

    30A

  • Cord Length

    10' (3m)

  • Frequency Range

    47 - 63 Hz

  • Input Voltage

    100 - 120 Vac

  • Input Voltage Range

    75 - 149 Vac

  • Plug Style

    Straight, Twist Lock

  • Plug Type

    NEMA L5-30P

  • Automatic Voltage Regulation

    Double boost, single buck

  • On Battery Frequency

    50/60Hz +/- 1%

  • On Battery Voltage

    100/110/120Vac +/- 5%

  • On Battery Waveform

    Sine wave

  • Outlet Type

    NEMA 5-20R

  • Outlets - Battery & Surge Protected

    8

  • Outlets - Critical Load

    4

  • Outlets - Total

    8

  • Overload Protection

    Internal Circuitry Limiting, Circuit Breaker

  • Rated Power Factor

    1

  • Transfer Time

    4ms typical

  • VA

    2200

  • Watts

    2200

Surge Protection & Filtering

Jump to...
  • EMI/RFI Filtration

    Yes

  • Network Protection RJ45

    1-in, 1-out

  • Surge Suppression

    2430 J

Management & Communications

Jump to...
  • Audible Alarms

    Battery Mode, Low Battery, Overload, Overcharge, Overheat

  • Dry Contacts

    Yes

  • Emergency Power Off (EPO) Port

    Yes

  • HID Compliant USB Port

    Yes

  • LED Indicators

    Power on, Line mode, Battery mode, Fault, Night mode, Wiring Fault

  • Management Cable

    USB Cable, EPO Cable

  • Multifunction LCD Panel

    47 Settings (27 setup and control items + 20 status updates and log menus)

  • SNMP / HTTP Remote Monitoring

    Yes - pre-installed RMCARD205

  • Serial Port

    Yes

  • Software

    PowerPanel Business Edition

Environmental

Jump to...
  • Audible noise at 1m from surface of unit

    57.5 dBA

  • Maximum Operating Elevation

    10,000' (3,000m)

  • Maximum Storage Elevation

    50,000' (15,000m)

  • Online Thermal Dissipation

    116 BTU/hr

  • Operating Relative Humidity

    0 - 95% (non-condensing)

  • Operating Temperature

    32 Degree F to 104 Degree F (0 Degree C to 40 Degree C)

  • Storage Relative Humidity

    0 - 95% (non-condensing)

  • Storage Temperature

    5 Degree F to 113 Degree F (-15 Degree C to 45 Degree C)

Certifications

Jump to...
  • Environmental

    RoHS Compliant

  • Safety

    UL1778, VCCI, FCC Class A

Physical

Jump to...
  • Color

    Black

  • Enclosure Construction

    Metal

  • Form Factor

    Rack/Tower

  • Rack Size

    2U

  • Dimensions (W x H x D)

    17.1 x 3.4 x 19.7" (43.43 x 8.64 x 50.04cm)

  • Weight

    79.6 lbs (36.11kg)

About CyberPower PR2200RTXL2UN

Discover the PR2200RTXL2UN 2200VA/2200W Smart App Sinewave Rack/Tower UPS, a reliable and high-performance power backup solution from CyberPower. This advanced UPS system is designed with line-interactive topology, providing consistent AC power and protecting your sensitive electronic equipment from power gaps, surges, and spikes.

The PR2200RTXL2UN is not just a UPS, it's an innovative power management system. It features a pre-installed RMCARD205 network management card, allowing for remote monitoring and control of the UPS via a standard web browser or network management system. This means you can manage your power backup system from anywhere, at any time, adding an extra layer of convenience and control.

This UPS system is designed with an extended battery module, providing longer runtimes during power outages. It also features fast charge technology, allowing the UPS batteries to return to full capacity more rapidly, ensuring your equipment is always protected.

The PR2200RTXL2UN is equipped with an easy-to-access toolless front panel and color-coded rear panel, making battery changes and installations simple and fast. It also features a rotatable multifunction LCD panel that provides information on 47 different settings, including UPS stats, setup and control management, and testing options.

This UPS system is ENERGY STAR certified, meaning it's energy-efficient and environmentally friendly. It also features GreenPower UPS Bypass Design, which improves operating efficiency, reduces heat generation, and consumes less power than conventional UPS models.

Whether you're looking to protect your home office equipment or ensure your business's critical servers and workstations are safe from power disruptions, the PR2200RTXL2UN 2200VA/2200W Smart App Sinewave Rack/Tower UPS is a durable and advanced solution that delivers reliable, high-quality power protection.

CyberPower PR2200RTXL2UN Features

  • Battery Backup
  • Line-Interactive Topology
  • Automatic Voltage Regulation (AVR)
  • Sine Wave Output
  • Battery Equalization Technology
  • Fast Charge Technology
  • Rotatable Multifunction LCD Panel
  • Toolless Battery Panel Access
  • RMCARD205 Factory Installed
  • Extended Battery Modules (EBMs)
  • Surge Protection
  • Data-Line Protection
  • GreenPower UPS Bypass Design
  • Rack/Tower Versatility
  • PowerPanel Business Edition Software
  • ENERGY STAR
  • Higher Capacity UPS for Longer Runtimes
  • Efficient Remote Management
  • Safe Shutdown
  • Programmable Outlet Control
  • Sine Wave Power

Key Features

  • High-capacity 2200VA/2200W Smart App Sinewave Rack/Tower UPS for reliable power backup
  • Extended Battery Module and Fast Charge Technology for longer runtimes and rapid recharging
  • Rotatable multifunction LCD panel providing detailed information on 47 different settings

What's in the box:

  • PR2200RTXL2UN 2200VA/2200W Smart App Sinewave Rack/Tower UPS
  • Faceplate
  • 2-Post Rack Mounting Hardware
  • 4-Post Rail Rack Mounting Hardware
  • Tower Mounting Hardware
  • Emergency Power Off Cable (Gray)
  • USB A+B Type Cable
  • User Manual
  • CyberPower 3 Year Limited Warranty
