Dahua DH-IPC-HDBW4231FN-E2-M12 Specifications

Camera
  • Image Sensor

    2x 1/2.8" 2 MP STARVIS CMOS Sensors

  • Effective Pixels

    1920(H) x 1080(V)

  • RAM/ROM

    512MB / 256 MB

  • Scanning System

    Progressive

  • Electronic Shutter Speed

    Auto, Manual; 1/3 s to 1/100,000 s

  • Minimum Illumination

    Color: 0.009 lux at F2.0 (1/3 s, 30 IRE)
    Color: 0.07 lux at F2.0 (1/30 s, 30 IRE)
    0 lux at F2.0 with IR on

  • S/N Ratio

    More than 50 dB

  • IR Distance

    Distance up to 20.0m (65.62')

  • IR On/Off Control

    Auto, Manual

  • IR LEDs

    10 per each Sensor

  • Lens Type

    Fixed

  • Mount Type

    Board-in

  • Focal Length

    2.8 mm or 3.6 mm

  • Max. Aperture

    F2.0

  • Angle of View

    Horizontal: 110deg.
    Vertical: 60deg.

  • Focus Control

    Fixed

DORI Distance

Jump to...
  • 2.8mm Lens

    Detect (8 ppf): 41m (134')
    Observe (19 ppf): 16m (52')
    Recognize (38 ppf): 8m (26')
    Identify (76 ppf): 4m (13')

Installation Angle

Jump to...
  • Range

    Pan: +/-90deg.
    Tilt: 0deg. to 65deg.
    Rotation: 0deg.to 360

  • Compression

    H.265, H.264H, MJPEG (Sub Stream)

  • Streaming Capability

    2 Streams per Sensor

  • Resolution

    1080p (1920 x 1080), 1.3 MP (1280 x 960),
    720p (1280 x 720), D1 (704 x 480), CIF (352 x 240)

  • Frame Rate

    Main Stream:
    Channel 1: 1080p at 30 fps
    Channel 2: 1080p at 30 fps

    Sub Stream:
    Channel 1: D1 at 30 fps
    Channel 2: D1 at 30 fps

  • Bit Rate Control

    CBR, VBR

  • Bit Rate

    H.264: 32 to 10240 Kbps
    H.265: 12 to 6400 Kbps

  • Day/Night

    Auto (ICR), Color, B/W

  • BLC Mode

    BLC, HLC, True WDR (120 dB, channel 1 only)

  • White Balance

    Auto, Natural, Street Lamp, Outdoor, Manual, Regional

  • Gain Control

    Auto, Manual, Gain Priority, Shutter Priority

  • Noise Reduction

    3D DNR

  • Motion Detection

    Off, On (4 Zone, Rectangle)

  • Region of Interest

    Off, On (4 Zone)

  • Smart IR

    Support

  • Digital Zoom

    16x

  • Flip

    0deg., 90deg., 180deg., 270deg.

  • Mirror

    Off, On

  • Privacy Masking

    Off, On (4 Area, Rectangle)

  • Compression

    G.711a, G.711Mu, AAC, G.726

Network

Jump to...
  • Ethernet

    M12 D-coded Connector (10/100 Base-T)

  • Protocol

    HTTP, HTTPS, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP, Bonjour, 802.1x, Multicast, ICMP, IGMP

  • Interoperability

    ONVIF Profile S&G, API

  • Streaming Method

    Unicast. Multicast

  • Maximum User Access

    10 Users / 20 Users

  • Edge Storage

    Network Attached Storage (NAS)
    Local PC for Instant Recording
    Micro SD Card Slot, 128GB maximum

  • Web Viewer

    Internet Explorer

  • Management Software

    SmartPSS, DSS, DMSS

  • Mobile Operating System

    IOS, Android

Interface

Jump to...
  • Audio

    Built-in Microphone

Electrical

Jump to...
  • Power Supply

    PoE (IEEE 802.3af, Class 0)

  • Power Consumption

    < 6.5 W

Certifications

Jump to...
  • Safety

    EN 60950:2000
    UL 60950-1

  • Rolling Stock

    EN 50155 (EN 50121-3-2, IEC61373)

  • Electromagnetic Compatibility

    FCC CFR 47 Part 15 Subpart B
    E-mark (ECE-Regulation No.10)

Environmental

Jump to...
  • Operating Temperature

    -30 to 60 deg. C (-22 to 140 deg. F), Less than 95% RH

  • Storage Temperature

    -30 to 60 deg. C (-22 to 140 deg. F), Less than 95% RH

  • Ingress Protection

    IP67

  • Vandal Resistance

    IK10

General

Jump to...
  • Casing

    Metal

  • Dimensions

    Dia. 122.0 x 66.20mm (Dia. 4.80 x 2.61")

  • Weight

    1.12 lbs (0.51kg)

About Dahua DH-IPC-HDBW4231FN-E2-M12

The Dahua DH-IPC-HDBW4231FN-E2-M12 Dual-sensor Mobile Dome Camera features two (2) 1/2.8-in. 2 MP Progressive Scan STARVIS CMOS Sensors each with a 2.8mm fixed lens. Each sensor can be positioned and configured independently of the other allowing flexible, multi-directional video surveillance that is ideal for monitoring the front and rear of a bus or a train. The camera offers True Wide Dynamic Range, a True Day/Night IR Cut filter, IP67 Ingress protection and operation in extreme temperatures to deliver superior images in all lighting and environmental conditions.

Design for Mobile Surveillance
The compact housing blends in with most vehicle interiors and minimizes interference with other installed devices. The design also minimizes vibration and shock from normal driving situations. The hardware of the mobile camera is certified to EN50155 to avoid image distortions or connection failures. The camera uses an M12 D-coded Ethernet connector for an added level of stability.

Starlight Technology
For challenging low-light applications, Dahua's Basic Starlight Technology offers best-in-class light sensitivity, capturing details in low light down to 0.009 lux. The camera uses a set of optical features to balance light throughout the scene, resulting in clear images in dark environments.

True Wide Dynamic Range
The camera achieves vivid images, even in the most intense contrast lighting conditions, using industry-leading wide dynamic range (WDR) technology (channel 1 only). For applications with both bright and low lighting conditions that change quickly, True WDR (120 dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video.

High Efficiency Video Coding (H.265)
The H.265 (ITU-T VCEG) video compression standard offers double the data compression ratio at the same level of video quality or substantially improved video quality at the same bit rate, as compared to older video compression technologies. H.265 offers such impressive compression by expanding the pattern comparison and difference-coding, improving motion vector prediction and motion region merging and incorporating an additional filtering step called sample-adaptive offset filtering.

Environmental
With a temperature range of -30 deg.C to +60 deg.C (-22 deg.F to +140 deg.F), the camera is designed for extreme temperature environments. The camera complies with an IK10 impact rating making it capable of withstanding the equivalent of 5 kg (11.02 lbs) of force dropped from a height of 40 cm (15.75 in.). Subjected and certified to rigorous dust and water immersion tests, the IP67 rating makes it suitable for demanding outdoor applications.

Protection
Supporting +/-30% input voltage tolerance, this camera suits even the most unstable conditions for outdoor applications. Its 4KV lightning rating provides protection against the camera and its structure from the effects of lightning.

Dahua DH-IPC-HDBW4231FN-E2-M12 Features

  • 2x Independent 1/2.8" 2 MP STARVIS CMOS Sensors
  • Dual-stream Encoding per each Channel
  • H.265 and H.264 Dual Codecs
  • 2 MP at 30 fps Maximum Resolution per Sensor
  • 2.8 mm Fixed Lens per Sensor
  • M12 D-coded Ethernet Connector
  • Basic Starlight Technology for Low Light Sensitivity
  • True Wide Dynamic Range (Channel 1) and True Day/Night (ICR)
  • Built-in Microphone
  • Maximum IR LED Distance 20m (66') with Smart IR
  • EN 50155 Vibration Protection Certification
  • IP67 Ingress Protection and IK10 Vandal Resistance
  • Five-year Warranty

What's in the box:

  • Dahua Mobile Series DH-IPC-HDBW4231FN-E2-M12 2x 2MP Outdoor Day & Night Dual-Sensor Dome Camera with 2.8mm Lens
  • Installation Position Map
  • Waterproof Connector
  • Screw Pack
  • CD
  • Aviation Port
  • Wrench
  • Quick Start Guide
  • Dahua 5 Year Warranty
