Rated output
Front: 95W + 95W (8 Ohms, 20Hz-20 kHz with 0.08% T.H.D.)
125W + 125W (6 Ohms, 1kHz with 0.7% T.H.D.)
Center: 95W (8 Ohms, 20Hz-20kHz with 0.08% T.H.D.)
125W (6 Ohms, 1kHz with 0.7% T.H.D.)
Surround: 95W + 95W (8 Ohms, 20Hz-20kHz with 0.08% T.H.D.)
125W + 125W (6 Ohms, 1kHz with 0.7% T.H.D.)
Surround back: 95W + 95W (8 Ohms, 20Hz-20kHz with 0.08% T.H.D.)
125W + 125W (6 Ohms, 1kHz with 0.7% T.H.D.)
4-16 Ohms
Input sensitivity: 200mV
Frequency response: 10 Hz-100 kHz - +1, -3 dB (Direct mode)
S/N: 100dB (IHF-A weighted, Direct mode)
Input sensitivity: 2.5mV
RIAA deviation: +/-1dB (20Hz to 20kHz)
S/N: 74dB (IHF-A)
Distortion factor: 0.03% (1kHz, 3V)
Input/output level and impedance: 1 Vp-p, 75 Ohms
Frequency response: 5 Hz-10 MHz - 0, -3dB
Input/output level and impedance: Y signal - 1 Vp-p, 75 Ohms
PB / CB signal - 0.7 Vp-p, 75 Ohms
PR / CR signal - 0.7 Vp-p, 75 Ohms
Frequency response: 5 Hz - 60 MHz - 0, -3dB
FM: 87.5MHz - 107.9MHz
AM:520kHz - 1710kHz
FM:1.2 Mu V (12.8dBf)
AM:18 Mu V
MONO - 2.8 Mu V (20.2dBf)
MONO - 70dB (IHF-A weighted, Direct mode)
STEREO - 67dB (IHF-A weighted, Direct mode)
MONO - 0.7 % (1kHz)
STEREO - 1.0 % (1kHz)
Conforming to IEEE 802.11a/b/g/n (Wi-Fi compliant)
WEP 64 bit, WEP 128 bit
WPA/WPA2-PSK (AES)
WPA/WPA2-PSK (TKIP)
2.4GHz, 5GHz
Bluetooth Specification Version 3.0 + EDR (Enhanced Data Rate)
Bluetooth Specification Power Class 1
Approx. 30m (98.42') in line of sight
2.4GHz
FHSS (Frequency-Hopping Spread Spectrum)
A2DP (Advanced Audio Distribution Profile) 1.2
AVRCP (Audio Video Remote Control Profile) 1.5
SBC
20Hz-20,000Hz
AC 120V, 60Hz
500W
0.1W
0.5W
17.1 x 6.6 x 13" (43.43 x 16.76 x 33.02cm)
9.4kg (20.72 lbs)
883795004480
Amazing
By Franklin D.
This receiver is great!
High quality sound
With discrete circuit technology, the power amplifier provides identical quality for all 7-channels (125 Watts x 7-channels)
For optimum realism and stunning dynamic range, the power amplifier section features discrete power devices (not integrated circuitry). By using high current, high power discrete power devices, the amplifier is able to easily drive high quality speakers.
Dolby Atmos
This unit is equipped with a decoder that supports Dolby Atmos audio format. The placement or movement of sound is accurately reproduced by the addition of overhead speakers, enabling you to experience an incredibly natural and realistic surround sound field.
DTS:X
This unit is equipped with the DTS:X decoder technology. DTS:X brings the home theater experience to new heights with its immersive object based audio technology which removes the bounds of channels. The flexibility of objects allows for sound to be scaled large or small and moved around the room with greater accuracy than ever before leading to a richer immersive audio experience.
DTS Virtual:X
DTS Virtual:X technology features DTS's proprietary virtual height and virtual surround processing to deliver an immersive sound experience from any type of input source (stereo to 7.1.4 channel) and speaker configuration. DTS Virtual:X is not for use when Height speakers are connected.
High performance
4K 60Hz input/output supported
When 4K Ultra HD (High Definition) is used, an input/output speed of 60 frames per second (60p) is achieved for video signals. When connected to 4K Ultra HD and 60p video signal input compatible TV, you can enjoy the sense of realism only available from high-definition images, even when viewing fast-moving video. This unit also supports image processing for 4K 60p, 4:4:4 and 24-bit videos. By processing the video at the original resolution, this unit lets you enjoy flawless, high-definition picture quality. This unit also supports HDR (High Dynamic Range) and BT.2020 wide color gamut.
HDCP 2.2
This unit is compatible with HDCP 2.2 copyright protection standard.
Digital video processor upscales video signals (SD resolution) to HD (720p/1080p) and 4K
This unit is equipped with a 4K video upscaling function that allows SD (Standard Definition) video to be output via HDMI at 4K (3840 x 2160 pixels) resolution. This function enables the device to be connected to a TV using a single HDMI cable and produces high definition images for any video source.
HDMI connections enable connection to various digital AV devices (8 inputs, 2 outputs)
This unit is equipped with 8 HDMI inputs and 2 HDMI outputs enabling connection to various HDMI compatible devices such as Blu-ray Disc players, game consoles and HD video camcorders. This unit is equipped with 2 monitor outputs, enabling you to project the same image at the same time using this unit.
The device is equipped with a AirPlay function in addition to network functions such as Internet radio etc
You can enjoy a wide variety of content, including listening to Internet Radio, playing audio files stored on your PC. This unit also supports Apple AirPlay which lets you stream your music library from an iPhone, iPad, iPod touch or iTunes.
Playback of DSD and FLAC files via USB and networks
This unit supports the playback of high resolution audio formats such as DSD (5.6 MHz) and FLAC 192 kHz files. It provides high quality playback of high resolution files.
Wireless connection with Bluetooth devices can be carried out easily
You can enjoy music simply by connecting wirelessly with your smartphone, tablet, PC, etc.
Multi-Room audio
You can select and play back the respective inputs in MAIN ZONE and ZONE2. In addition, when the All Zone Stereo function is used, the music being played back in MAIN ZONE can be enjoyed in all the zones at the same time. This is useful when you want to let the BGM propagate throughout the whole house.
Energy-saving design
This unit is equipped with an ECO Mode function that allows you to enjoy music and movies while reducing the power consumption during use and also an auto-standby function that automatically turns off the power supply when the unit is not in use. This helps reduce unnecessary power use.
Compatible with the "Denon 2016 AVR Remote" App for performing basic operations of the unit with an iPad, iPhone or Android devices (Google, Amazon Kindle Fire)
Along with many new features, the graphics and user interface have been completely overhauled. The new app gives you full control of the AVR as well as access to its setup menu for detailed adjustments from your phones or tablets. "Denon 2016 AVR Remote" App also gives you quick access to the receiver's status display, option menus, Denon Blu-ray Disc player control and online owner's manual for your convenience. Download the appropriate "Denon 2016 AVR Remote" App for your iOS or Android devices. This unit needs to be connected to the same LAN or Wi-Fi (wireless LAN) network that the iPhone or iPod touch is connected to.
HEOS provides streaming music from your favorite online music sources
HEOS wireless multi-room sound system that enables you to enjoy your favorite music anywhere and everywhere around your home. By utilizing your existing home network and the HEOS App (available for iOS, Android and Amazon devices), you can explore, browse and play music from your own music library or from many online streaming music services. When multiple HEOS devices are connected to the same network, HEOS devices can be grouped to play back the same music on all devices simultaneously or different music can be played on each separate HEOS device.
Easy operation
"Setup Assistant" provides easy-to-follow setup instructions
First select the language when prompted. Then simply follow the instructions displayed on the TV screen to set up the speakers, network, etc.
Easy to use Graphical User Interface
This unit is equipped with a Graphical User Interface for improved operability.
