Denon AVR-X6800H 140W 11.4-Channel 8K AV Network Receiver with HEOS

SKU: DEAVRX6800H MFR: AVR-X6800H
(3)Ask a Question
$3,799.00
OR
$317/mo suggested payments with 12‑month special financing. Learn how.
Earn VIP Reward Points
See all Used options (5) from $2,365

Key Features

  • Experience immersive audio with the Denon AVR-X6800H's 11.4 channel processing.
  • Enjoy pristine sound with 140W power, perfect for home theater audio setups.
  • Connect all your devices with ease using multiple HDMI inputs and outputs.
  • Stream music effortlessly via HEOS, AirPlay 2, and Bluetooth connectivity options.
  • Elevate movie nights with 8K video and Dolby Atmos for a cinematic experience.
  • Customize your sound with Audyssey MultEQ XT32 for optimized acoustics.
See More Product Details
Free Shipping

See Options

1
Add to ListGet Sale Alert

Add Adorama Protect:

Available to U.S. customers only.
2-Year Adorama Protect$149.99
3-Year Adorama Protect$229.99
4-Year Adorama Protect$279.99

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

2025-05-31T20:00:00

Rated 5 out of 5

I love it had it

I love it had it coupled with my McIntosh amp well over 400 watts per left and right channels found balance and RCA inter connects via Amazon just love the results

Gregory A.

2024-12-20T19:00:00

Rated 5 out of 5

Music to my ears

Been waiting 45 years for an amp of this quality. Easy setup and awesome 2. 1 setup. Paired with Axiom M80's and a Sony subwoofer.

Barry

2024-12-20T19:00:00

Rated 5 out of 5

Excellent upgrade

This is my 6th avr purchase in over 20 years. My first 3 were Sony 5. 1 and 7. 2 systems followed by a Denon 7. 2 and a Marantz 6015 when I decided to build out a full Atmos home theater system. Since I'm running multiple subwoofers, staying within the Denon/Marantz ecosystem was a fairly simple choice for me. I was looking to get a Cinema 30, but the black Friday price drop on the 6800 changed my mind. I ordered directly from Denon. The avr was delivered 2 days late due to a goof up on FedEx's end. That aside, the unit was quickly unboxed and put into service. As when any and all new electronics, the updates were installed before starting the calibration process. Setup was very easy and straightforward. Definitely liking the slightly refreshed GUI, and the newer audio codecs that were missing from my Marantz 6015. Hdmi handshake was flawless with all of my connected devices including my Govee sync box 2. I also appreciate the ability to disable the avr's internal amps. I've been running this unit pretty hard for a week now with no complaints or issues. I have only 2 complaints. When Marantz got the refreshed look, Denon units should've been done at the same time. My last issue, and shame on you Denon for this one. A back-lit remote should be standard on all of your avr's, especially when the product cost over $2000. My Nividia Shield was only $200, but it comes with a back-lit remote. The 6800, so far has worked like a charm and I expect to get many years of enjoyment out of it. Definitely looking forward to getting Dirac Live & Bass control. Please feel free to send a back-lit remote. Will gladly pay for reverse shipping of the original remote.

Troy S.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Denon AVR-X6800H Specifications

Multichannel Surround

Multichannel Surround

Jump to...

  • DTS HD Master / DTS:X / DTS:X Pro

    Yes / Yes / Yes

  • DTS Neo:6 / DTS Neural:X

    No / Yes

  • DTS Virtual:X

    Yes

  • IMAX Enhanced

    Yes

  • Dolby TrueHD

    Yes

  • Dolby Atmos

    Yes

  • Dolby Atmos Height Virtualization

    Yes

  • Dolby Atmos Music

    Yes

  • Dolby ProLogic Il / Dolby Surround

    No / Yes

  • Auro 3D

    Yes

  • 360 Reality Audio / MPEG H

    Yes / Yes

  • Multichannel Stereo

    Yes

  • Max. number of processing (preamp) ch

    13

Sound Enhancements

Jump to...

  • Mono Block Power Amp Construction

    Yes

  • Discrete Power Amplifier

    Yes

  • D.D.S.C. HD Digital

    Yes (32 bit)

  • Pure Direct

    Yes

  • Gold Plated RCA Terminals

    Yes

  • Clock Jitter Reducer

    Yes

  • Alpha Processing

    AL32 Processing Multichannel

  • Audyssey

    MultEQ XT32

  • Audyssey Dynamic EQ / Dynamic Volume

    Yes / Yes

  • Audyssey LFC

    Yes

  • Dirac Live upgradability

    Yes

  • Compressed Audio Restorer

    Yes

Network

Jump to...

  • Media Server

    Yes

  • HEOS Wireless Multi-Room Technology

    Yes

  • Bluetooth Re-transmit for BT headphones

    Yes (With volume control)

  • Alexa / Google Voice Assistant

    Yes / Yes

  • Apple HomePod

    Yes

  • Lossy Formats: MP3 / WMA / AAC

    Yes / Yes / Yes

  • Lossless Formats

    FLAC / ALAC / WAV: Yes / Yes / Yes
    FLAC HD 192/24 / WAV 192/24 / ALAC 192/24: Yes / Yes / Yes

  • DSD Audio Streaming

    Yes (2.8/5.6MHz)

  • FLAC HD 192/24

    Yes

  • WAV 192/24

    Yes

  • ALAC 192/24

    Yes

  • Gapless playback

    Yes (FLAC, WAV, ALAC ,DSD)

  • AirPlay Audio Streaming

    Yes (AirPlay2)

  • Internet Radio

    Yes (TuneIn)

  • Spotify Connect

    Yes (connect)

  • Pandora

    Yes

  • SiriusXM

    Yes

  • Other Streaming Services

    Amazon Music HD/ Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix

  • Roon Tested

    Yes

  • HEOS App Control

    Yes

  • Compatible with Remote APP

    Smart Phones: Denon AVR Remote
    Tablets: Android / iOS / Amazon Kindle

  • Ethernet Ports

    Yes

  • Wi-Fi

    Yes

  • Bluetooth

    Yes

HDMI

Jump to...

  • HDMI Inputs: Back, Front

    7 / No

  • HDCP2.3 support

    Yes

  • HDMI Outputs: Main, Zone

    45293

  • Video conversion Analog -> HDMI

    Yes

  • HDMI to HDMI Scaling

    1080P/4K to 8K

  • HDMI 2.1: 8K/60 Hz AB / 4K/120 Hz AB

    Yes / Yes

  • AB Pass-Through In/Out

    7 / 2 (up to 40Gbps) 8K/60Hz / 4K/120Hz

  • HDMI 2.0: 3D/4K/CEC/ARC/InstaPrevue

    Yes / Yes / Yes / Yes / No

  • HDR/HLG/Dolby Vision/HDR10+/Dynamic HDR

    Yes / Yes / Yes / Yes / Yes

  • ALLM Pass-Through for Gaming

    Yes

  • VRR / Quick Flame Transport

    Yes / Yes

  • Quick Media Switching

    No

  • 3D Signal Pass-Through

    Yes

  • Through / Scaling / GUI Overlay

    8K Signal Pass: Yes / Yes / Yes
    4K Signal Pass: Yes / Yes / Yes

  • HDMI Pass-Though in Standby Mode

    Yes

  • CEC

    Yes

  • DSD Audio capability

    Yes

  • Audio Return Channel

    RC, eARC

  • Auto LipSync

    Yes

Multi-room / CI

Jump to...

  • Multi-Room Zones

    3

  • Zone Audio Source

    HDMI / Opt, Coax / Network, USB / Analog: Yes (2ch) / Yes (2ch) / Yes / Yes

  • Zone Audio Output: Speaker / Pre-Out

    Yes / Yes

  • Zone HDMI output from HDMI source

    Yes

  • IP Control / RS232 Control

    Yes / Yes

  • Web Control / App Control

    Yes / Yes

  • Remote In / Out

    Yes / Yes

  • DC Trigger output

    3

  • HDMI Diagnostics

    Yes

Others

Jump to...

  • Auto speaker setup by microphone

    Audyssey MultEQ XT32 Dirac Live (upgrade)

  • Front Display

    2 Line FLD

  • Graphic User Interface - GUI

    Modern HD GUI

  • GUI Languages

    3

  • Setup Assistent

    Yes

  • Quick Select Plus, Quick Select

    Yes / No

  • Firmware Update by Network / USB

    Yes / Yes

  • Variable cross over

    Yes

  • Optimized Bass Redirection

    Yes

  • Bass Sync

    Yes

  • ECO Mode

    Yes

  • Auto Power Off

    Yes

  • Sleep Timer

    Yes

Inputs Outputs

Jump to...

  • Composite In / Out

    2 / No

  • Component In / Out

    1 / No

  • HDMI In / Out

    45358

  • Multi-Room Video Out: Video / HDMI

    No / Yes

  • Analog In, Out

    6 / No

  • Phono (MM) In

    Yes

  • Digital in: Optical/Coaxial

    45324

  • Multi-Room Out: Analog/Digital

    2 / No

  • Multichannel Pre-out

    Yes (13.4)

  • Subwoofer Out

    4 (independent)

  • Speaker Terminal

    Gold-Plated Screw / Regular Screw: Yes / No

  • Number of Speaker Terminals

    13

  • Speaker A / B

    assignable

  • Bi-amp drive

    assignable

  • Multi-Room Speaker Terminal

    assignable

  • Front Inputs

    Audio / Composite / Digital (Opt) / HDMI / USB: No / No / No / No / Yes

  • USB Audio/Made for iPod/Made for iPhone

    Yes / No / No

  • USB Power Supply on Rear Panel

    Yes

  • AM/FM Tuner

    Yes

General

Jump to...

  • Number of Power Amps

    11

  • Power Output

    140 W (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)
    175 W (6 ohm, 1 kHz, 0.7% 2ch Drive)
    250 W (6 ohm, 1 kHz, 10% 1ch Drive)

  • Metal Front Panel

    Yes

  • System Remote Control

    RC-1256

  • Pre-programmed/Learnable/LCD Display

    Yes / No / No

  • Power Consumption

    750W

  • Power Consumption No-Sound

    65W / 110W (ECO On / Off)

  • Standby Consumption

    0.1W

  • CEC Standby Consumption

    0.5W

  • Network Standby Consumption

    Less than 2.0W

  • Power Supply

    AC 120 V, 60 Hz

  • Speaker Impedance

    4-16 Ohm/ohms

  • Input Sensitivity

    200 mV

  • Frequency Response

    10 Hz-100 kHz - +1, -3dB (Direct mode)

  • S/N Ratio

    102dB (IHF-A weighted, Direct mode)

  • FM section

    Tuning Frequency Range: 87.5-107.9 MHz

  • AM section

    Tuning Frequency Range: 520 kHz-1710 kHz

Physical

Jump to...

  • Dimensions

    With Horizontal Antenna: 17.1 x 15.3 x 6.6" (43.4 x 38.9 x 16.8cm)
    With Vertical Antenna: 17.1 x 15.3 x 9.3" (43.43 x 38.86 x 23.62cm)
    Without Antenna: 17.1 x 14.9 x 6.6" (43.4 x 37.84 x 16.8cm)

  • Weight

    34.4 lbs (15.60kg)

Other

Jump to...

  • UPC Code

    747192140359

About Denon AVR-X6800H

FEATURED REVIEWS

I love it had it

By Gregory A.

I love it had it coupled with my McIntosh amp well over 400 watts per left and right channels found balance and RCA inter connects via Amazon just love the results

Excellent upgrade

By Troy S.

This is my 6th avr purchase in over 20 years. My first 3 were Sony 5. 1 and 7. 2 systems followed by a Denon 7. 2 and a Marantz 6015 when I decided to build out a full Atmos home theater system. Since I'm running multiple subwoofers, staying within the Denon/Marantz ecosystem was a fairly simple choice for me. I was looking to get a Cinema 30, but the black Friday price drop on the 6800 changed my mind. I ordered directly from Denon. The avr was delivered 2 days late due to a goof up on FedEx...

View full Review

When it comes to elevating your home entertainment system, the Denon AVR-X6800H 140W 11.4-Channel 8K AV Network Receiver with HEOS stands out as a meticulously crafted powerhouse, engineered in Japan to deliver an unparalleled audio-visual experience. This high-performance receiver boasts an impressive 140 watts per channel, ensuring dynamic and precise sound that immerses you in the heart of the action.

Experience the future of sound with its 3D audio capabilities, featuring cutting-edge technologies such as Dolby Atmos, DTS:X, IMAX Enhanced, and Auro 3D. These advanced features, along with Dolby Surround, DTS Neural:X, and Auro-Matic upmixer, transform legacy content into a captivating 3D soundscape.

The AVR-X6800H excels not only in audio but also in video performance, supporting 8K video on all seven HDMI inputs and two of the three outputs. This ensures seamless compatibility with the latest high-definition content. With support for HLG, HDR, Dolby Vision, HDR10+, and Dynamic HDR pass-through, you can enjoy breathtaking picture quality without any compatibility concerns.

Integrated HEOS technology allows for wireless streaming from a variety of free and premium music services. Share your favorite tunes across multiple rooms by connecting to other HEOS-enabled devices, such as Denon Home speakers, for a seamless multi-room audio experience. The receiver also supports Hi-Res Audio decoding, enabling playback of ALAC, FLAC, and WAV lossless files up to 24-bit/192-kHz, as well as DTS 2.8MHz and 5.6MHz tracks, ensuring you hear every detail as the artist intended.

Voice control is made easy with support for Apple Siri and compatibility with Josh.ai, allowing you to manage your entertainment environment with simple voice commands. The AVR-X6800H is equipped with advanced features like Pre-Amplifier Mode, HDMI eARC and ARC, and Next Generation Gaming technologies, including Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM), providing a smooth, lag-free gaming experience with compatible devices.

In summary, the Denon AVR-X6800H 140W 11.4-Channel 8K AV Network Receiver with HEOS is a comprehensive solution for all your home entertainment needs, offering a perfect blend of advanced audio and video technologies, smart features, and flexible configuration options. Discover the Denon difference and transform your home entertainment experience today.

Denon AVR-X6800H Features

  • Powerful 11-channel amplifier
  • 3D audio experience
  • Configuration flexibility
  • Advanced 8K home theater
  • HEOS Built-in technology
  • Audyssey room correction technology
  • Built to high standards
  • Over a century of innovation

Warranty Information

This product has a limited warranty of 24 months.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Product Documents

User Manual

Key Features

  • Experience immersive audio with the Denon AVR-X6800H's 11.4 channel processing.
  • Enjoy pristine sound with 140W power, perfect for home theater audio setups.
  • Connect all your devices with ease using multiple HDMI inputs and outputs.
  • Stream music effortlessly via HEOS, AirPlay 2, and Bluetooth connectivity options.
  • Elevate movie nights with 8K video and Dolby Atmos for a cinematic experience.
  • Customize your sound with Audyssey MultEQ XT32 for optimized acoustics.

What's in the box:

  • Denon AVR-X6800H 140W 11.4-Channel 8K AV Network Receiver with HEOS
  • Remote Control with Batteries
  • AM Antenna
  • FM Antenna
  • Wire Labels
  • Audyssey Microphone
  • Cardboard Microphone Stand
  • 2x Detachable Antenna
  • Power Cord
  • Denon 2 Year Limited Warranty
