Decimator Quad Miniature 3G/HD/SD-SDI Quad-Split with SD-SDI and Composite Outputs

The Decimator-Quad Miniature 3G/HD/SD-SDI Quad-Split with SD-SDI & Composite Outputs os low cost 4 to 1 Quad Split or Down-converter with 4 to 1 input multiplexer. The output is a choice of either a NTSC or PAL output. It has linked SD-SDI and composite outputs. It has 4x 3G/HD/SD-SDI inputs with auto detection (26 Formats supported in total). Each quadrant is independent of the others, allowing any 3G/HD/SD format of any frame rate to be displayed Simultaneously. The aspect ratios are variable as per quadrant. All 4 inputs can be displayed simultaneously on a single output. It has full-screen mode which allows any of the 4 inputs to be selected for output. In Full-screen mode the selected 3G/HD-SDI input is down-converted to either NTSC or PAL and a SD-SDI input is passed through untouched. An extensive selection of user controllable functions via an easy to use rotary encoder for menu selection. LEDs and apush button can then be used for status and control. It has locking DC Power Socket and comes with a Mounting Bracket.
