Dahua PFH610V-IR 14" Vandal-Proof Outdoor Housing with IR, IP67, IK10
See all dahua items

Dahua PFH610V-IR 14" Vandal-Proof Outdoor Housing with IR, IP67, IK10

SKU: DHPFH610VIR
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Dahua PFH610V-IR Specifications

  • Material

    Aluminum

  • Power Supply

    AC24V/5A, DC24V

  • Operting Temperature

    Set: -40 to + 140 Degree F (-40 to 60 Degree C)

    Heater
    On: 5 +/- 5 Degree C ( 41 Degree F) /Off: >=15 +/- 5 Degree C (59 +/- 41 Degree F)

    Cooler
    ON: 37 +/- 5 Degree C (98.6 +/- 41 Degree F) /OFF: 20 +/- 5 Degree C ( 68 +/- 41 Degree F)

  • Humidity

    <90% RH

  • Ingree Protection

    IP67

  • Vandal Resistance

    IK10

  • Certification

    CE, FCC, UL, EAC, ICES

  • RS485 Control

    Yes, use RS484 to Control IR light

  • Power Consumption

    Without Camera: 67W

  • IR Distance

    0 to 328.08' (0 to 100m)

  • Dimensions (L x W x H)

    Overall: 15.91 x 6.46 x 5.2" (404 x 164 x 132mm)
    Internal: 8.46 x 3.54 x 3.27" (215 x 90 x 83mm)
    Window (Diameter): 2.36" (60mm)

  • Weight

    6.61 lb (3kg)

  • UPC Code

    819290021783

About Dahua PFH610V-IR

14" housing, provides all-weather protection for box cameras and lens. All-aluminum shell design, IP67, IK10, 14" housing with different function modules: Built-in heating and cooling system, windows adopt water-proof films, 0-100m IR, built-in PoE module and support remote control of IR light and wiper function by RS485, Aesthetic design.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • PFH610V-IR 14 " Vandal-Proof IR Housing
  • 2x M20 Water Joint
  • 2x 1/4/20x8UNC Screw
  • S5.0 Wrench
  • Installation Instruction
  • Connecting Line (Link Camera to IR Driver Board)
  • Dahua 3 Year Limited Warranty
