DJI Matrice 30 Specifications

General

General

Jump to...
  • Number of Rotors

    4

  • Configuration

    Drone Kit

  • Edition

    Thermal

  • FAA Registration (Non-Commercial Usage)

    Required

  • Features

    IP Rated

  • Kit Style

    With Enterprise Basic & Batt Kit

  • Model

    DJI Matrice 30

  • Skill Level

    Enterprise

Aircraft

Jump to...
  • Color

    Black

  • Maximum Flight Time

    41 minutes

  • Takeoff Weight

    8.97 lbs (4069g)
    For C2 Certification in EU: 8.81 lbs (3998g)

  • Max Ascent/Decent Speed

    Ascent/Descent: 6 m/s, 5 m/s

  • Max Horizontal Speed

    23 m/s

  • Max Wind Speed Resistance

    15 m/s
    12 m/s during taking off and landing

  • Max Takeoff Altitude

    5,000 m (with 1671 propellers)
    7,000 m (with 1676 propellers) (without other payload)

  • Max Hovering Time

    36 minutes

  • Max Tilt Angle

    35 Degree (N-mode and Forward Vision System enabled: 25 Degree )

  • Max Angular Velocity

    Pitch: 150 Degree /sec.; Yaw: 100 Degree /sec.

  • Global Navigation Satellite System

    GPS+Galileo+BeiDou+GLONASS (GLONASS is supported only when RTK module is enabled)

  • Hovering Accuracy Range

    Vertical: +/-0.1m (Vision System enabled); +/-0.5m (N-mode with GPS); +/-0.1 m (RTK)
    Horizontal: +/-0.3m (Vision System enabled); +/-1.5m (N-mode with GPS); +/-0.1m (RTK)

  • Operating Temperature

    (Aircraft, TB30 Intelligent Flight Battery, Remote Controller):
    -4 Degree to 122 Degree F (-20 Degree to 50 Degree C)

    BS30 Intelligent Battery Station:
    -4 Degree to 104 Degree F (-20 Degree to 40 Degree C)

  • IP Rating

    Aircraft:
    IP55

    Remote Controller:
    IP54

    BS30 Intelligent Battery Station:
    IP55

  • Internal Storage

    No

  • Camera Still Resolution

    48 MP

  • Video Resolution

    4K

  • Image Sensor

    Zoom Camera:
    1/2" CMOS, Effective pixels: 48M

    Wide Camera:
    1/2" CMOS, Effective pixels: 12M

  • Lens

    Zoom Camera:
    Focal length: 21-75 mm (equivalent: 113-405 mm)
    Aperture: f/2.8-f/4.2
    Focus: 5 m to Infinite

    Wide Camera:
    DFOV: 84 Degree
    Focal length: 4.5mm (equivalent: 24mm)
    Aperture: f/2.8
    Focus: 1m to Infinite

    Thermal Camera:
    DFOV: 61 Degree
    Focal length: 9.1mm (equivalent: 40mm)
    Aperture: f/1.0
    Focus: 5m to Infinite
    Sensitivity<=30 mk@F1.1

    FPV Camera:
    161 Degree

  • ISO Range

    100-25600

  • Shutter Speed

    Auto Mode:
    Photo: 1/8000-1/2 s
    Video: 1/8000-1/30 s

    M Mode:
    Photo: 1/8000-8 s
    Video: 1/8000 -1/30 s

  • Max Image Size

    Zoom Camera:
    8000 x 6000

    Wide Camera:
    4000 x 3000

    Thermal Camera:
    Infrared Image Super-resolution Mode: 1280 x 1024
    Normal Mode: 640 x 512

    FPV Camera:
    161 Degree

  • Still Photography Modes

    Single Shot

  • Photo Format

    JPEG

  • Digital Zoom

    Thermal
    20x
    Wide
    5x
    Telephoto
    20x

  • Gimbal Option

    Flight Camera

  • Mechanical Range

    Pan:'+/-105 Degree
    Tilt: -135 Degree to'+60 Degree
    Roll:'+/-45 Degree

  • Controllable Range

    Pan:'+/-90 Degree
    Tilt: -120 Degree to'+45 Degree

  • Angular Vibration Range

    +/-0.01 Degree

Sensing

Jump to...
  • Sensing Type

    Omnidirectional

  • Forward

    Detection Range: 2.0 to 124.7' / 0.6 to 38 m
    Field of View: 65° (Horizontal) / 50° (Vertical)

  • Backward

    Detection Range: 1.6 to 108.3' / 0.5 to 33 m
    Field of View: 65° (Horizontal) / 50° (Vertical)

  • Lateral

    Detection Range: 1.6 to 108.3' / 0.5 to 33 m
    Field of View: 65° (Horizontal) / 50° (Vertical)

  • Upward

    Detection Range: 1.6 to 108.3' / 0.5 to 33 m
    Field of View: 50° (Front-to-Back) / 65° (Side-to-Side)

  • Downward

    Detection Range: 1.6 to 108.3' / 0.5 to 33 m
    Field of View: 65° (Front-to-Back) / 50° (Side-to-Side)

  • Operating Environment

    Vision Systems:
    Surfaces with clear patterns and adequate lighting (> 15 lux)

    Infrared Sensing Systems:
    Large, diffuse, and reflective obstacles (reflectivity >10%)

Video Transmission

Jump to...
  • Video Transmission System

    O3 Enterprise

  • Operating Frequency

    2.4000-2.4835GHz
    5.725-5.850GHz

  • Transmitter Power (EIRP)

    2.4GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)
    5.8GHz: <33 dBm (FCC); <14 dBm (CE); <23 dBm (SRRC)

  • Max Transmission Distance

    O3 Enterprise:
    Max Transmission Distance w/o Interface:
    2.4000-2.4835 GHz: 15 km (FCC); 8 km (CE/SRRC/MIC) (unobstructed, free of interference)

    Max Transmission Distance with Interface:
    Strong Interference (urban landscape, limited line of sight, many competing signals): 1.5-3 km (FCC/CE/SRRC/MIC)
    Medium Interference (suburban landscape, open line of sight, some competing signals): 3-9 km (FCC); 3-6 km (CE/SRRC/ MIC)
    Weak Interference (open landscape abundant line of sight,

Battery

Jump to...
  • Capacity

    TB30 Intelligent Flight Battery:
    5880 mAh

    Remote Controller:
    Internal Battery: 6500 mAh

    External Battery: 4920 mAh

  • Voltage

    TB30 Intelligent Flight Battery:
    26.1 V

    Remote Controller:
    Internal Battery: 7.2 V

    External Battery: 7.6 V

  • Battery Material

    Aircraft:
    Lithium ion

  • Energy

    TB30 Intelligent Flight Battery:
    131.6 Wh

    Remote Controller:
    External Battery: 37.39 Wh

  • Battery Quantity

    2

Remote Controller

Jump to...
  • Remote Controller

    with Remote Controller

  • Max Operating Time

    Internal Battery: Approx. 3 hours 18 min
    Internal Battery'+ External Battery: Approx. 6 hours

  • Operating Temperature

    (Aircraft, TB30 Intelligent Flight Battery, Remote Controller):
    -4 Degree to 122 Degree F (-20 Degree to 50 Degree C)

    BS30 Intelligent Battery Station:
    -4 Degree to 104 Degree F (-20 Degree to 40 Degree C)

Physical

Jump to...
  • Dimensions

    Aircraft:
    Unfolded, excl. propellers: 18.5 x 23 x 8.4" (470 x 585 x 215mm)
    Folded: 14.3 x 8.4 x 7.6" (365 x 215 x 195mm)

    BS30 Intelligent Battery Station:
    13.8 x 10.5 x 5.8" (353 x 267 x 148mm)

  • Weight

    Aircraft:
    8.3 lbs (3.77kg) (+/- 10g) (incl. two batteries)

    TB30 Intelligent Flight Battery:
    24.1 oz (685g) (Approx.)

    BS30 Intelligent Battery Station:
    8.7 lbs (3.95kg)

  • UPC Code

    192223202771

18 Accessories for DJI Matrice 30T (Thermal) with Care Enterprise BASIC and 2 Batteries

  • All Accessories (18)
  • Drone Accessories (4)
  • Remote & Remote Accessories (2)
  • Batteries & Power Supply (2)
  • Propellers & Guards (2)
  • Brackets & Mounts (1)
  • Bags & Cases (5)
  • Landing Gear (2)

About DJI Matrice 30

FEATURED REVIEWS

Excellent bundle!

By Jeff B.

This is an excellent bundle and a must have for public safety!

Powerful Flight Performance.

A balance of power and portability delivers higher operational efficiency

• 41 minute max flight time
• 15 m/s wind resistance
• 7000m service ceiling
• 23 m/s max speed

Powerful Flight Performance.

Environmental Adaptablility.

With IP55 protection, the M30 can easily handle adverse weather and temperatures ranging from -20C to 50C.

Environmental Adaptablility.

The Matrice 30T Thermal Quadcopter represents the pinnacle of commercial drone technology, offering a powerful blend of flight performance and environmental adaptability. With its IP55 rating, this robust drone effortlessly withstands adverse weather conditions and operates seamlessly in temperatures ranging from -20°C to 50°C, ensuring reliability across diverse climates.

Safety and reliability are paramount with the M30T. It features dual-vision and ToF sensors on all six sides, providing comprehensive obstacle sensing for enhanced mission safety. The integrated ADS-B receiver delivers real-time alerts of crewed aircraft in the vicinity, further ensuring operational security.

The M30T is engineered with advanced redundancy systems, which maintain flight operations even in unexpected scenarios, highlighting its commitment to mission-critical reliability. Enhanced transmission capabilities are achieved through OcuSync 3 Enterprise, which supports triple-channel 1080p video transmission and allows for seamless input feed swapping, even in complex environments.

Designed for convenience, the M30T is both lightweight and portable. Its compact, foldable design makes it easy to transport and deploy, catering to the needs of professionals on the move. The drone's integrated camera system captures comprehensive aerial data with a wide camera, zoom camera, and thermal imaging camera, complemented by a laser rangefinder.

The wide camera boasts a 24mm equivalent focal length, an 84° DFOV, a 12 MP 1/2" CMOS sensor, and 4K/30fps video resolution. The zoom camera features a 48 MP 1/2'' CMOS sensor, 5x-16x optical zoom, up to 200x max. hybrid zoom, 8K photo resolution, and 4K/30fps video resolution. The thermal imaging camera offers a 40mm equivalent focal length, 640x512 resolution, 30fps frame rate, and measurement accuracy within ±2°C or ±2%.

For precise measurements, the laser rangefinder covers a range of 3m to 1200m with an accuracy of ±(0.2m+D x0.15%). Superior image quality is guaranteed even during night flights, thanks to the FPV camera optimized for low-light conditions. The Smart Low-Light Photo feature captures bright, clear images in dim settings, while the high-resolution thermal capabilities enable the detection of hotspots and heat signatures.

The M30T revolutionizes flight control with the 7-inch widescreen DJI RC Plus, designed specifically for commercial drone pilots. It offers IP54 protection against water and dust, and its ergonomic design enhances safety and efficiency. The improved stability and extended battery life are supported by the four-antenna OcuSync 3 Enterprise system, which provides stable video transmission and allows for battery hot-swapping.

DJI Pilot 2 introduces a reimagined user interface for improved piloting efficiency and flight safety. The pre-flight checklist, navigation display, and alert notifications contribute to a comprehensive flight safety system. FlightHub 2 enhances ground-to-cloud synergy with features like 2.5D Base Map, One-Tap Panorama Sync, Cloud Mapping, and mission live streaming with low latency.

The M30T is compatible with the DJI Dock for non-stop operations, featuring IP55 weather resistance and fast charging capabilities. The BS30 Intelligent Battery Station offers a smart, portable charging solution, while the TB30 Intelligent Flight Battery ensures optimal performance with self-heating and hot-swapping capabilities.

User data security is a top priority, with features like SD Card AES Encryption, Local Data Mode, One-Tap Clear All Device Data, AES-256 Video Transmission Encryption, and Cloud API.

The Care Enterprise Basic package enhances the M30T's value by offering the opportunity to renew DJI Care Enterprise Basic, extending the warranty by at least 12 months and providing comprehensive protection for your fleet. This includes one additional replacement within a year to cover accidental damage, ensuring total peace of mind with quality assurance and free shipping for replacement services.

DJI Matrice 30 Features

  • Unique aerial intelligence to capture everything
  • Reliable in the harshest of environments
  • Portable to go wherever you go
  • Ready, when you are, to overcome the unknown
  • 41-min Max Flight Time
  • 15 m/s Wind Resistance
  • 7000 m Service Ceiling
  • 23 m/s Max Speed

Warranty Information

This product has a limited warranty of 12 months.

Product Documents

User Manual

Key Features

  • Advanced commercial drone with powerful flight performance and IP55 environmental adaptability
  • Lightweight, compact, and foldable design for easy transportation and deployment
  • Extended warranty and comprehensive protection with Care Enterprise Basic package

What's in the box:

  • DJI Matrice 30T Thermal Quadcopter
  • RC Plus Controller
  • BS30 Intelligent Battery Station
  • Storage Case
  • USB-C Cable
  • USB-C to USB-C Cable
  • Screws and Tools
  • 1671 Propeller (CW)
  • 1671 Propeller (CCW)
  • (1676 High Altitude Propellers Not Included)
  • DJI 1 Year Limited Warranty
  • Bundle With:
  • 2x DJI TB30 Intelligent Flight Batteries
  • DJI M30T Care Enterprise Basic
