DJI Spreading Wings S1000 Octocopter with Wookong-M Multi Rotor Stabilization Controller, Zenmuse Z15-5D Mark II Aerial Gimbal

The DJI DJIS1000W5D2 is a pack of Spreading Wings S1000 Octocopter with Wookong-M stabilization controller and Zenmuse Z15-5D Mark II Gimbal.

Spreading Wings S1000
Spreading Wings S1000 is specially designed for High level professional aerial photography and cinematography.

Safe And Stable
The S1000's V type mixer design provides large amounts of propulsion while improving power efficiency. Combined with a DJI flight controllers, it is promised to remain stable even with the loss of a rotor. Integrated into the center frame is a power distribution system using patented coaxial cable connector. It is more efficient, reliable and easy to install and eliminates the need for soldering. All frame arms as well as the retractable landing gear are made from carbon fiber, ensuring light weight and high structural stability.

Portable Easy To Use
All eight arms can be completely folded down and the 1552 folding propeller can be tucked away, minimizing the S1000's size for transportation. To fly, simply lift the frame arms up, lock them in place with the red clips and power up the system. This greatly saves on pre-flight prep time.

Sparkproof Plug
Its main power cord uses an AS150 sparkproof plug and an XT150 plug, preventing creators from mixing up polarity when plugging in the battery and preventing short circuits.

Professional Octocopter
Weighing approximately 4kg with a maximum takeoff weight of about 11kg, the S1000 can easily carry equipment as heavy as a 5D mark 3. Used with a 6S 15000mAh battery it can fly for up to 15 minutes.

Low Gimbal Mounting Position
The gimbal is mounted low on the frame on a specially designed bracket. When combined with retractable landing gear, it offers a clear and wide shooting angle.

New Damping Design
Gimbal and battery are mounted to the same bracket, with dampers placed between the bracket and the frame. This significantly reduces high-frequency vibrations and makes shots clearer and sharper. The battery tray's position also makes it more stable and convenient for mounting and dismounting.

Innovative Frame Arm Design
Each frame arm is designed with an 8deg. inversion and a 3deg. inclination, making the aircraft more stable when rolling and pitching yet more flexible when rotating.

Propulsion System
Each frame arm has a built-in 40A electronic speed controller (ESC). When combined with its 4114 pro motor and high performance 1552 folding propellers, it is capable of a maximum thrust of 2.5Kg.

Wookong-M
DJI Wookong Multi-Rotor stabilization controller is a complete flight system for all multi-rotor platforms for commercial and industrial AP applications. Unlike others, WooKong allows the use of regular ESC commonly used in RC helicopters without any wiring modification. Heli mode setup provides a seamless transition for current Ace One AP professionals. WK-M utilizes high quality components precisely calibrated with temperature compensation in all gyros and sensors, industry renowned flight algorithm in autopilot and UAV field.

9 Types Of Multi-Rotors And A Customized Motor Mixer
Support 9 traditional motor mixer: Quad I, Quad X, Hexa I, Hexa V, Hexa Y, Hexa IY, Octo X, Octo I, Octo V. It's a UAS that targeted at commercial and industrial multicolor platforms with simple configuration, easy installation and stable performance.

Built-In Gimbal Stabilization Function
The gimbal stabilization module is compatible with most 2-axis gimbal systems. The system will adjust the camera according to the attitude of the aircraft after setting the parameters the first time. The scope of the gimbal servo output frequency is 400hz, 200hz, 100h and 50hz, the higher frequency output makes the adjustment more efficient. At the same time, the limit of the gimbal servo rolling and pitching is extended to 90deg..

Support iPad Ground Control Station (GCS)
WooKong-M GCS now supports iPad (currently iPad 3, iPad4, iPad mini), the only thing you need to do is to plug in a Bluetooth datalink and the BTU module. Gone are the days of the heavy laptop, now you don't need to install maps and drivers, forget about the Windows OS version compatibility problems and don't worry about Google Earth. Without long cables, it is as easy to control the aircraft with ground station as play a game on your iPad. More-over the trend of using the iPad Waypoint will be another highlight.

New Assistant Software for Smartphone
The WooKong-M now provides assistant software for iPhone4s, iPhone5, iPad3, iPad4, iPadmini, iPod5. You can do parameter adjustments at any time on your mobile devices, using only an LED indicator with a built-in Bluetooth module which makes it easier and convenient. It uses low power Bluetooth to minimize the power consumption of mobile devices. It is easy to use and will automatically save your last connection records. The password mechanism ensures safety link. Parameters can be automatically synchronized to the Cloud Server and can be restored immediately when you changed mobile devices.

Supporting Futaba S-bus receiver
Compatible with almost all radios-PCM or 2.4Ghz

Power Monitoring Unit
Specially designed for WKM to solve the high power consumption problem of the power support system. It contains two power outputs for the entire WKM system and receiver separately, a battery voltage monitor and two CAN-Bus interfaces.

Built-in Damper
Small footprint and weight offer ease of installation in tight spaces, for various aircraft sizes.

Precise Position and Altitude hold
With WKM, the multirotors will have position and altitude lock in windy conditions. Precise hovering in less than 2m horizontal and 0.5m vertical.

High Accuracy and Driving Handfeel
With the WKM, flying a multi-rotor will be as easy as driving a car. The pilot is released from the stress of controlling the multi-rotor and able to pay more attention to other tasks such as camera angle, instead of focus on flying.

Zenmuse Z15-5D Gimbal
The DJI Zenmuse Z15-5D Gimbal, based on the technology of the Zenmuse Z15 series gimbal, inherited its predominant strength/weight ratio because of its unique structural design. This release marks another breakthrough in gimbal systems and the precision range of the control angle is within +/-0.02deg.. When used with DJI A2 professional flight controller and an Octo-copter, it will remain stable and precisely with the highest level of stability in controlling any camera equipment even if the aircraft is in strong wind or at high speed. Undeniably, it is the top choice in professional filming or aerial photography.

Multiple Control Modes
The Zenmuse Gimbal system offers three types of control modes. Orientation-locked control mode, Non Orientation-locked control mode and Back to Mid-point mode (Horizontal mode). These three modes can be switched both quickly and easily to support the many different requirements of aerial photography.

3-Axis Rotation Control
The 3-axis Zenmuse Gimbal system has a creative mechanical design. The control method is simple and easy to use as the movement range of the transmitter stick has direct control over the relative rotation speed. The tail potentiometer greatly increases control, stability and precision and the internal slip rings avoid needlessly complicated wiring. Both the power and signal lines are integrated into the tubes of the Gimbal, which presents a completely unhindered control axis without limitation providing a maximum Yaw of +/-360deg., a maximum Pitch of -120deg.to +15deg.and a maximum Roll of +/-25deg..

Built-In Independent Imu Module And Infrared Module
The new stabilizing algorithm represents the latest in innovation which, together with highly-precise induction devices, provides perfect performance of attitude control. This integration means that without the requirement of extra installation and connection of extra wires, it is both easy to assemble and extremely stable during flight. The gimbal also provides a specially designed and customized video output module, which includes an infrared shutter control function.
