DJI SDR Transmission Combo, 3 km/10,000 ft 1080p/60fps SDR Wireless Video Transmission, Transmitter & Receiver, Stable & Anti-Interference, Strong Penetration, High Bitrate + 2x Batteries & Charger

SKU: DJISDRTCK MFR: CP.RN.00000397.01 K
Earn VIP Reward Points

PACKAGE INCLUDES:

  • DJI SDR Transmission Combo
    DJI SDR Transmission Combo
  • +
  • Green Extreme NP-F550 Battery Pack
    Green Extreme NP-F550 Battery Pack

    Qty: 2

  • +
  • Green Extreme Dual Smart Charger with LCD Screen Base (No Battery Plates)
    Green Extreme Dual Smart Charger with LCD Screen Base (No Battery Plates)
  • +
  • 1 more

Note: 1 or more items are unavailable for immediate shipping

Key Features

  • Experience reliable video transmission with this DJI SDR combo, up to 3km range.
  • Enjoy low latency (80ms) for real-time monitoring with this wireless video transmitter.
  • Capture stunning visuals with 1080p/60fps high-resolution wireless broadcast equipment.
  • Stable & anti-interference technology ensures seamless streaming for live events.
  • This wireless video system includes 2 batteries & charger for extended shooting.
  • Benefit from strong signal penetration, ideal for complex environments with this system.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$69.99

3 Year

$94.99

4 Year

$119.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Accessories
Learn
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?NICOLAS Z : is the best nowTIM J : It specs out to be better than anything else on the market currently, in the price range.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

DJI SDR Transmission Specifications

Transmitter

Transmitter

Jump to...
  • Ports

    SDI Input Port
    HDMI Input Port
    3.5mm Stereo Jack
    USB-C Firmware Update Port
    USB-C Power and Gimbal Communication Port

  • Operating Frequency

    SDR Operating Frequency
    Non-DFS Frequency Band:
    2.4000-2.4835 GHz
    5.725-5.850 GHz
    DFS Frequency Band:
    5.470-5.725 GHz

    Wi-Fi Operating Frequency
    2.4000-2.4835 GHz
    5.150-5.250 GHz

  • Transmitter Power (EIRP)

    SDR:
    2.4000-2.4835 GHz:
    < 30 dBm (FCC)
    < 20 dBm (SRRC/CE/MIC)

    5.470-5.725 GHz:
    < 30 dBm (FCC)
    < 23 dBm (CE/MIC)

    5.725-5.850 GHz:
    < 30 dBm (FCC)
    < 14 dBm (CE)
    ¼±30 dBm (SRRC)

    Wi-Fi:
    2.4000-2.4835 GHz:
    < 26 dBm (FCC)
    < 20 dBm (SRRC/CE/MIC)

    5.150-5.250 GHz:
    < 26 dBm (FCC)
    < 23 dBm (SRRC/CE/MIC)

  • Wi-Fi Protocol

    802.11b/a/g/n/ac/ax
    Supports 2 x2 MIMO Wi-Fi

  • Max Bandwidth

    SDR: 20 MHz
    Wi-Fi: 20 MHz

  • Max Bitrate

    SDR: 20 Mbps
    Wi-Fi: 8 Mbps

  • Power Consumption

    8.2W

  • Power Supply

    USB-C Power Supply Type 1: 9 V, 2 A (PD protocol)
    USB-C Power Supply Type 2: 6.8-17.2 V DC
    NP-F Battery Power Supply Voltage: 6.8-8.4 V

  • Input Video Format

    1080p: 23.98/24/25/29.97/30/50/59.94/60fps
    1080i: 50/50.94/60fps (1080i is not available in Broadcast mode).
    720p: 50/59.94/60fps

  • Input Audio Format

    SDI embedded, HDMI embedded

  • Video Transmission System

    SDR + Wi-Fi

  • Video Transmission Latency

    SDR: 80 ms
    Wi-Fi: 110 ms

  • Video Coding Format

    H.264

  • Max Transmission Distance

    SDR:
    3 km (FCC)
    2 km (CE/SRRC/MIC)

    Wi-Fi: 200 m

  • Operating Temperature

    14 Degree to 104 Degree F (-10 Degree to 40 Degree C)

  • Dimensions (L x W x H)

    Excluding Antennas: 3.40 x 2.51 x 1.25" (86.5 x 64 x 32mm)

  • Weight

    5.11 oz (145g) (Approx.) (including antennas)

Receiver

Jump to...
  • Ports

    SDI Output Port
    HDMI Output Port
    3.5mm Stereo Jack
    USB-C Firmware Update and Video Output Port
    USB-C Power Port

  • Operating Frequency

    SDR Operating Frequency
    Non-DFS Frequency Band:
    2.4000-2.4835 GHz
    5.725-5.850 GHz

  • Transmitter Power (EIRP)

    SDR:
    2.4000-2.4835 GHz:
    < 30 dBm (FCC)
    < 20 dBm (SRRC/CE/MIC)

    5.725-5.850 GHz:
    < 30 dBm (FCC)
    < 14 dBm (CE)
    < 23 dBm (SRRC)

  • Max Bandwidth

    20 MHz

  • Max Bitrate

    20 Mbps

  • Power Consumption

    8.3W

  • Power Supply

    USB-C Power Supply Type 1: 9 V, 2 A (PD protocol)
    USB-C Power Supply Type 2: 6.8-17.2 V DC
    NP-F Battery Power Supply Voltage: 6.8-8.4V

  • Output Video Format

    1080p: 23.98/24/25/29.97/30/50/59.94/60fps
    1080i: 50/50.94/60fps (1080i is not available in Broadcast mode).
    720p: 50/59.94/60fps

  • Output Audio Format

    PCM

  • Video Transmission System

    SDR

  • Video Transmission Latency

    80 ms

  • Video Coding Format

    H.264

  • Max Transmission Distance

    3 km (FCC)
    2 km (CE/SRRC/MIC)

  • Operating Temperature

    14 Degree to 104 Degree F (-10 Degree to 40 Degree C)

  • Dimensions (L x W x H)

    Excluding Antennas: 3.40 x 2.51 x 1.25" (86.5 x 64 x 32mm)

  • Weight

    5.11 oz (145g) (Approx.) (including antennas)

Battery

Jump to...
  • Battery Info

    Required, Not Included

  • Battery Material

    Lithium ion

  • Battery Type

    NP-F

  • Battery Quantity

    2

  • UPC Codes

    192223254510, 6941565984012, 840014139668, 840014129959, 840014116287

Related Articles & Videos

New DJI SDR Transmission System Delivers Unparalleled Performance In A Compact Package

New DJI SDR Transmission System Delivers Unparalleled Performance In A Compact Package

Today marks the introduction of DJI’s brand-new SDR Transmission line of Transmitters and Receivers. The DJI SDR Transmission system leverages both SDR (Software-Defined Radio) and Wi-Fi video transmission technologies into an easy-to-use solution that delivers unparalleled video transmission perfor...
Read more

5 Accessories for DJI SDR Transmission Combo, 3 km/10,000 ft 1080p/60fps SDR Wireless Video Transmission, Transmitter & Receiver, Stable & Anti-Interference, Strong Penetration, High Bitrate + 2x Batteries & Charger

  • All Accessories (5)
  • Receiver (1)
  • Transmitter (1)
  • Phone Mount (1)
  • Tablet Holder (1)
  • Cables & Adapters (1)

About DJI SDR Transmission

Why settle for anything less than exceptional when it comes to video and audio broadcasting? The DJI SDR Transmission Combo is the ultimate solution for professionals demanding superior performance and reliability. This state-of-the-art wireless video transmission system is engineered to deliver crystal-clear high-definition 1080p/60fps video over an impressive range of up to 3 km or 10,000 feet, making it ideal for a wide array of applications, from live event broadcasting to professional videography and high-end surveillance.

At the heart of the SDR Transmission Combo is a powerful transmitter and receiver duo, designed to ensure stable and anti-interference broadcasting. Its robust penetration capabilities and high bitrate guarantee that your video and audio content is transmitted with exceptional clarity and without quality loss, even in the most challenging environments. This makes it an indispensable tool for professionals who require consistent and reliable performance.

The system is equipped with a comprehensive array of input and output ports, catering to various devices and applications. It includes industry-standard SDI and HDMI ports, ensuring seamless video connectivity with a wide range of equipment. Additionally, a 3.5mm stereo jack is available for audio input, while USB-C ports facilitate firmware updates, power supply, and gimbal communication, enhancing the system's versatility and ease of use.

To ensure uninterrupted operation, the SDR Transmission Combo comes with two high-capacity batteries and a charger, providing a dependable power source for extended sessions. Whether you're capturing live events, conducting professional videography, or engaging in sophisticated surveillance tasks, this wireless video transmission system offers the reliability, versatility, and high-quality performance that professionals demand. Choose the DJI SDR Transmission Combo for a seamless and superior broadcasting experience.

DJI SDR Transmission Features

  • SDI and HDMI for video, 3.5mm jack for audio, and USB-C for power and data
  • SDR: 2.4000-2.4835 GHz, 5.725-5.850 GHz, and 5.470-5.725 GHz (DFS)
  • Wi-Fi Protocol Supports 802.11b/a/g/n/ac/ax with 2x2 MIMO capability
  • Maximum Bandwidth 20 MHz for both SDR and Wi-Fi
  • Maximum Bitrate 20 Mbps for SDR and 8 Mbps for Wi-Fi
  • Power Consumption 8.2W to 8.3W
  • Power Supply: Multiple USB-C options and NP-F battery support
  • Video Formats: Supports 1080p, 1080i, and 720p across various frame rates
  • Audio Formats: SDI and HDMI embedded audio, with PCM output
  • Maximum Transmission Distance Up to 3 km for SDR and 200 m for Wi-Fi

Warranty Information

This product has a limited warranty of 12 months.

Product Documents

User Manual

Key Features

  • Experience reliable video transmission with this DJI SDR combo, up to 3km range.
  • Enjoy low latency (80ms) for real-time monitoring with this wireless video transmitter.
  • Capture stunning visuals with 1080p/60fps high-resolution wireless broadcast equipment.
  • Stable & anti-interference technology ensures seamless streaming for live events.
  • This wireless video system includes 2 batteries & charger for extended shooting.
  • Benefit from strong signal penetration, ideal for complex environments with this system.

What's in the box:

  • SDR Transmission Transmitter (TX)
  • SDR Transmission Receiver (RX)
  • USB-A to USB-C Cable (43cm)
  • TX Camera Mounting Adapter Plate
  • TX Gimbal Mounting Adapter Plate
  • DJI 1 Year Limited Warranty
  • 2x Green Extreme NP-F550 7.2V 18.72Wh Li-Ion Batteries
  • Green Extreme Dual Smart Charger with LCD Screen Base and Battery Plates
