DJI Zenmuse H20N Gimbal and Camera Includes DJI Care Enterprise Basic

- Zenmuse H20N -

Vision Beyond Darkness. "N" for Night Vision
The Zenmuse H20N integrates starlight sensors into its zoom and wide-angle cameras. Pair this with dual zoom thermal cameras and a laser rangefinder, and you have a versatile hybrid payload that rises to the occasion.

Sensors Upgraded Across Multiple Dimensions

Infrared Zoom
• Dual Thermal Cameras
• Resolution: 640 x512
• 2x Zoom (Equivalent Focal Length: 53 mm)
• 8x Zoom (Equivalent Focal Length: 196 mm)

See the Big Picture
• Night Vision Wide Camera
• Starlight Sensor: 2MP
• Stronger Low-Light Performance

Pierce Through the Veil
• Night Vision Zoom Camera
• Starlight Sensor: 4MP
• 20 x Optical Zoom, 128 x Max Zoom
• Low-Light Details

Precise Distance Data
• Laser Rangefinder
• Range: 3 to 1200m
• Accuracy: +/- (0.2m + D x0.15%)2

Thermal and Starlight Vision to Elevate Your Operations

See Through the Night
The zoom and wide-angle cameras are equipped with starlight sensors that are tailor-made for low-light environments.

Infrared Zoom
Two thermal cameras respectively provide 2 x and 8 x zoom, together enabling up to 32 x zoom. Find hotspots and inspect in close detail after zoom-in.

Synchronized Split-screen Zoom
H20N supports synchronized zoom between thermal and starlight night vision cameras. Users can scale both images at the same time. This doubles efficiency and makes it easier to compare details side by side.

More Intelligent Features
• PinPoint
• Smart Track
• High-Res Grid Photo
• One-tap Panorama

Thermal Features

Color Palettes
Adjust the colors applied to the thermal data based on the mission requirements.

Isotherms
Visualize a specific band of temperatures to highlight your targets.

Temp. Alarm
Receive instant notifications in DJI Pilot when object temperatures exceed your preset alert values.

Gain Modes
Adjust gain modes to change the temperature range captured: High Gain Mode covers a smaller temperature range but is more sensitive to temperature differences; Low Gain Mode covers a wider temperature range.

R-JPEG Images
Images captured by the Zenmuse H20N are in R-JPEG format with embedded temperature information. By importing these images into the DJI Thermal Analysis Tool, you can measure temperature, and adjust parameters such as Emissivity, and Reflected Temp.

- Care Enterprise Basic -

Offers you the chance to renew your DJI Care Enterprise Basic, providing one more opportunity to replace your DJI product for a small additional charge in one year, and also covering damage from accidents like crashing, water damage, or signal interference. Furthermore, the warranty period of your product will be extended by at least 12 months, giving you greater peace of mind.

Comprehensive Protection for Your Fleet
DJI Care Enterprise Basic Renew offers you the chance to renew your DJI Care Enterprise Basic by extending its coverage for one more year, providing an additional opportunity to replace your damaged DJI product. As an added benefit, the warranty period of your product will be extended by at least 12 months.

One More Replacement, Total Peace of Mind
DJI Care Enterprise Basic Renew provides one additional replacement within a year to cover damage from drops, crashes, water, and other accidents.

Note: Replacement products are new or equivalent-to-brand-new products in performance and reliability. Minor flaws in appearance may exist.

One Year Warranty Renew with Quality Assurance
The warranty period is extended by at least 12 months beyond its original warranty, providing greater peace of mind.

Note: Applicable for select components

Fly Sooner with Free Shipping
DJI Care Enterprise covers sending and receiving shipment fees for the replacement service, providing a convenient and efficient service experience.

Note: Available for regions covered by the DJI Care Enterprise. The user is responsible for additional costs incurred beyond the scope of coverage.

Service Process
When damage occurs, send the affected product and components to the DJI Repair Centre for an assessment and quotation. You can then choose for repair or replacement
