Review Summary
System Type: 12" two-way, self-powered, horn-loaded HF
Frequency Range (-10 dB): 43 Hz to 20 kHz
Frequency Response (+/-3 dB): 51 Hz to 20 kHz
Maximum Peak SPL (Measured): 133 dB at 3.3' (1m)
Coverage Pattern (Averaged): 90 deg. H x 60 deg. V
Directivity Index (D.I.): 9.5 dB
Peak Power: 2400 W (1600 W LF + 800 W HF)
Continuous Power: 1200 W (800 W LF + 400 W HF)
Amplifier Topology: Class D/switching, bridged LF and HF
Amplifier Cooling: Passive
12" (305mm) high excursion cone transducer
3" (76mm) high-temperature voice coil, ferrite magnet
1.75" (45mm) voice coil, ferrite magnet compression driver with 1" (25mm) acoustic aperture
System Control:
High-pass & low-pass crossover filters
Transducer EQ and delay compensation
Transducer excursion, thermal, and amplifier clip protection
User Controls (5 DSP EQ Modes): Flat, Contour, 80 Hz HP, EXT LF, User
Wireless Type: Bluetooth 2.0 + EDR Class 2 RF
Wireless Range (typical): 82' / 25 m clear line-of-sight
Wireless Control App: Live Drive (App by Alto Professional, available on the App Store)
Simultaneous Devices Connectable: 1 to 3 Delta Series loudspeakers
Compatible Wireless Devices: iPhone 3GS and newer, iPad 2 and newer, iPod touch (4th generation) and newer
iOS Version Requirements: iOS 6.1 and newer
Wireless Control Features:
Level Control (-Infinity to + 10 dB)
Mute
Signal level metering (-70 to 0 dB)
DSP mode (Flat, Contour, 80 Hz HP, Ext. LF, User)
Rear Panel control lockout
3 Band EQ (Low, Mid, High)
Delay
Polarity
User high-pass filter
Monitoring (Limit, Peak, Fault)
Power Supply Design: Fully regulated switching (with Power Factor Correction)
Input Voltage Nominal Range: 100-240 VAC, 50/60 Hz
Input Voltage Operating Range: 90-264 VAC, 50/60 Hz
Voltage Selection: Automatic (self-regulating)
Power Connector: Male IEC
Current Requirement: 6 A per system at 120 VAC, 3 A per system at 240 VAC
AC Line Cord: 9.8' / 3 m IEC female to regional AC male, 18 AWG
Input Connectors: 2x XLR/TRS combo connectors, balanced
Input Impedance: 10 kOhms balanced, 20 kOhms unbalanced
Input level Controls: 2x rotary volume control
Acoustic Polarity: Positive voltage applied to XLR Pin 2 generates positive pressure from LF driver
Line/Mic Level Selector: Push-button switch
Output Connector: Male XLR
Output Mix Control: Switch to select output mix pre- or post-volume control
Ground Switch: Push-button to lift input signal input ground connection
Bluetooth: Momentary contact to initiate Bluetooth pairing mode
DSP Mode Selection: Momentary contact to cycle through DSP EQ modes
DSP Modes Available (5 Total): Flat, Contour, 80 Hz HP, EXT LF, User
DSP Wireless Control: Live Drive iOS app over Bluetooth
Grille Logo LED On/Off Control: Recessed push-button switch
Standby Mode On/Off Control: Recessed push-button switch
LED Indicators: Signal Present/Limit, Power/Standby
Line Input Level Control Range: -Infinity to 0 dB, +4 dBu nominal, +10 dBu for max output
Mic Level Control Range: -Infinity to +50 dB
Construction: 0.6" (15.0mm) and 0.7" (18.0mm) premium plywood, internally-braced
Finish: High-durability, textured, catalyzed polyurethane, black
Mounting: 12 x M10 female threaded screw sockets
Handles: Ergonomic handle with aluminum cross-bar
Stand mount: 1 x 1.4" (35.0mm) female socket
Grille: 0.0" (1.2mm) perforated steel, black powder-coat
14 to 104 deg.F (-10 to 40 deg.C)
24.1 x 14.3 x 14.6" (61.2 x 36.3 x 37.1 cm)
52.2lbs (23.7 kg)
0694318017258
When you need the ultimate in speaker performance, Denon Professional proudly offers the Delta Series-a family of powered loudspeakers that delivers the very highest level of acoustic performance, essential for critical musical productions, dynamic AV playback and clear, articulate spoken presentations. The Delta Series was designed from a clean sheet of paper to exacting performance standards, using custom-developed, purpose-matched components.
Unrivaled acoustic accuracy via advanced engineering and design
2400 watts peak Class D power (1200 Watts continuous)
12" LF transducer, 1.75" HF driver with 1" acoustic aperture
Optimized 90deg. x 60deg. sound coverage field
Works with free Denon Drive app for wireless sound-shaping control
Wirelessly level-match, EQ, delay-compensation and more
DSP-controlled, custom crossover and active thermal protection
Built-in mixer, (2) Mic/Line inputs, volume control, XLR output
Limit/Clip indicator with red LED
EQ contour switch; Ground Lift switch
Trapezoidal cabinet with custom-molded heavy-duty handle
Flyable via (12) M10 rigging points
Designed and tuned in the U.S.A.
Dynamic Acoustic Performance
The Delta 12 features an integral low-distortion Class D amplifier capable of 2400 watts peak output (1200 watts continuous). The ultra-durable, linear transducers are paired with custom DSP-controlled crossovers and computer-designed high-frequency waveguide for an optimized 90deg. x 60deg. coverage field. Highly flexible connection/control facilities easily adapt the speaker to any usage condition. Plus, the entire Delta series utilizes dynamic thermal protection to ensure reliable, studio-grade sound reproduction at any volume level.
However, it's not the printed specifications or the number of inputs and outputs that qualifies the Delta 12 as such an elite performer. It's the performance. The sound is effortless, clear and natural. There is no sense of strain or coloration. With lesser speakers, the listener can immediately hear the "reproduced" nature of the sound; that unmistakable nasal artificiality and edgy, strident distortion that betrays the sound of an inaccurate speaker system.
When you hear the Delta 12, it sounds like real life. The full frequency range is conveyed with absolute authority, providing convincing, realistic sound from any genre of music. Bass instruments are full and muscular. Vocals are distinct and precise, while horns are rich and energetic, their characteristic "sheen" perfectly preserved. Drums and percussion have great impact and impressive weight. Even today's complex, multi-layer music is reproduced with agility and nuance at any volume, from subtle indoor settings to full-volume outdoor concerts. When you need even greater low-frequency extension and output, simply add either the Delta Series 15 Sub or 18 Sub to create a system of absolutely uncompromised capability.
The Right Connections
Denon Professional recognizes that adaptability and connection flexibility are just as important to a successful event as outstanding sonic performance. Therefore, the Delta series features a built-in mixer with multiple inputs and outputs. The cabinets are scratch-resistant, fronted with a powder-coated metal grille-perfect for anything from vocal reinforcement in a lecture hall to music-rich multimedia presentations in convention.
Even their rubber feet are reinforced with steel. You can hang the Delta series via their integrated M10 rigging points or use the "tops" as floor wedge monitors. They may also be mounted via industry-standard built-in 35mm pole sockets. This level of connection and mounting options means that virtually every situation benefits from using Delta Series loudspeakers.
Remote Control
Even if you can't physically reach the speakers, you can still adjust them with your iPad or iPhone using the Drive iOS app. With their wireless technology, you can precisely tailor the performance parameters of your Delta Series loudspeakers remotely. Level-match, adjust EQ, delay-compensation and more-from virtually anywhere. It's streamlined, sound-shaping control at your fingertips, so you can easily adapt the Delta Series to new venues or performances, even if you're away from the mix position.
