DigiTech JamMan Solo XT Stereo Looping Compact Pedal with JamSync, 35 Minutes Internal Memory, USB Output and microSDHC Slot

SKU: DTJMSXT

This item is no longer available.

Recommended Alternatives

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

DigiTech JamMan Solo XT Specifications

Digital

Digital

Jump to...
  • A/D/A Conversion

    24-bit

  • Sampling Frequency

    44.1kHz

  • Loop File Format

    44.1kHz, 16-bit (stereo), uncompressed WAV file

  • USB

    2.0 High Speed (USB 1.1 compatible)

  • Connector Type

    5-pin Type B

  • Max. Individual Loop Time

    10 minutes (stereo)

  • Internal Memory Capacity

    Over 35 minutes total loop time (up to 200 loops total)

  • External Memory Type

    Micro SD/SDHC up to 32GB (optional)

  • External Memory Capacity

    Over 32 hours (10.6MB/minute) of recording time, when using 16GB or larger Micro SDHC card (up to 200 loops total)

Inputs/Outputs

Jump to...
  • Left (Mono)/Right Inputs

    Connector Type: 1/4" Unbalanced (Tip-Sleeve)
    Input Impedance: 500KOhms Mono/1MOhms Stereo
    Unity Gain Input to Output: Loop Level knob set to 12 o'clock position
    Max Input Level at Unity: +4dBu DFS
    Left and Right Audio Paths: Each channel maintains analog dry path

  • Aux Input

    Connector Type: 1/8" Stereo (Tip-Ring-Sleeve)
    Input Impedance: 1MOhms
    Maximum Input Level: +4dBu DFS
    Aux In Audio Path: Maintains analog dry path

  • Footswitch Input

    Connector Type: 1/4" Stereo (Tip-Ring-Sleeve), compatible with optional DigiTech FS3X 3-button footswitch

  • Left (Mono)/Right Outputs

    Connector Type: 1/4" Unbalanced (Tip-Sleeve)/Balanced (Tip-RingSleeve)
    Output Impedance: 100Ohms Unbalanced/ 200Ohms Balanced
    Maximum Output Level: +4dBu DFS
    Playback Unity Gain: Loop Level knob set to 12 o'clock position

Performance

Jump to...
  • Frequency Response

    +0/-3dB 20-20kHz

Power Requirements

Jump to...
  • Consumption

    <9W

  • Current Draw

    <350mA

Power Adapter

Jump to...
  • Input

    100-240 VAC, 50/60Hz

  • Output

    9 VDC, 2.0A

Minimum System Requirements

Jump to...
  • Windows

    JamManager XT v2.3.5:
    Windows 7, 8, 8.1, 10 (32/64bit)
    Intel Core 2.0GHz or higher
    2GB RAM
    USB Port

  • Mac

    JamManager XT v2.3.5:
    OS X 10.8.5 - 10.12.6
    Intel Core Processor
    2GB RAM
    USB Port

General

Jump to...
  • Dimensions (LxWxH)

    5 x 3.12 x 2.25" (12.70 x 7.92 x 5.72cm)

  • Weight

    0.75 lbs (0.34kg)

  • UPC Code

    691991202704

About DigiTech JamMan Solo XT

After inventing looping nearly three decades ago, DigiTech's JamMan Solo XT brings you the definitive stereo looping experience. Build up the energy in your performance and find new inspiration with virtually limitless loops. Seamless transitions between looped phrases make the JamMan Solo XT an invaluable tool for composing and performing.

• Store over 35 minutes of stereo, CD-Quality loops in 200 internal memories
• Optional micro SDHC card can store over 16 hours of CD-quality audio in 200 additional memories
• Record rhythm loops and solo over them on the fly, completely Hands-Free
• Sync multiple JamMan Solo XT pedals together to create a multi-track looper or loop with other musicians
• Connect to your computer via USB and use the JamManager Loop Librarian software to organize and archive your loops
• Aux Input lets you import music from CD and MP3 players
• Load up the JamMan with bass lines, drums, harmonies and more; create an entire backup band, take it with you and perform anywhere
• Slow down or speed up any loop without changing pitch
• Metronome with multiple rhythm sounds and time signatures
• Rugged metal chassis
• Power supply included
• Optional footswitch adds additional Hands-Free functionality
• Single Phrase & Loop Playback
• Stereo 44.1 kHz 16-Bit .wav File Format
• Selectable Time Signature
• Tap Tempo
• 9 Built-In Rhythm Guide Patterns
• Auto Record Sensing
• Auto Quantization
• Time Stretching
• Reverse Loop Playback
• 3 Selectable Stop Modes
• Stereo 1/4" Inputs & Outputs
• 1/8" Stereo Auxiliary Input
• Mini-B USB Jack for File Transfer Using JamManager XT Loop Librarian Software for Mac & PC

Get the stereo looping experience you need from straight-forward backing loops to intricate loop layers by yourself or with your band. Perfect your performance with Auto-Record, Auto-Quantize, adjustable BPMs and three different Stop modes. Use the powerful JamSync to link JamMan Solo XTs and create the ultimate multi-looping system. The JamMan Solo XT gives your musical performance a rich, full sound while staying true to the sound you compose. Get your JamMan Solo XT today and tear down your musical limitations.

JamManager XT
The new JamManager XT loop librarian works with the JamMan Solo XT for synchronizing loops, creating JamLists and building your loop library. JamManager XT is used for transferring loops between the JamMan Solo XT and your computer via the USB port. It is available as a free download and will run on both Windows and Intel Mac computers.

What's in the box:

  • DigiTech JamMan Solo XT Stereo Looping Compact Pedal with JamSync
  • PS0920DC-01 Power Adapter
  • Manual
  • DigiTech 1 Year Parts and Labor Limited Warranty
