DVDO 1x8 4K HDMI 18Gbps Splitter with HDR
See all DVDO items
New Arrival

DVDO 1x8 4K HDMI 18Gbps Splitter with HDR

SKU: DVDSPLITTR18 MFR: DVDO-SPLITTER-18
Be the first to review this itemAsk a Question
$239.00
OR
$40/mo suggested payments with 6‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Effortlessly share your 4K HDMI content across 8 displays with this reliable 1x8 splitter.
  • Enjoy stunning visuals with full 18Gbps bandwidth and HDR support for vibrant colors.
  • Benefit from HDCP 2.2 compliance, ensuring seamless playback of protected content on all screens.
  • Experience crystal-clear audio with support for advanced formats like Dolby Atmos and DTS:X.
  • Ideal for retail, hospitality, or home theater, this splitter simplifies your AV distribution.
  • Its durable metal enclosure and easy-to-use design provide long-lasting, dependable performance.
See More Product Details
New Item?Request assistance or get notified
Free Shipping

See Options

1
Add to ListGet Sale Alert

Add Adorama Protect:

Available to U.S. customers only.
1-Year Adorama Protect$29.99
2-Year Adorama Protect$49.99
3-Year Adorama Protect$59.99

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

DVDO HDMI Splitter Specifications

Technical

Technical

Jump to...

  • HDMI Compliance

    HDMI 2.0b

  • HDCP Compliance

    HDCP 2.2

  • Video Bandwidth

    18Gbps / 594MHz

  • Video Resolutions

    480i-1080p@50/60Hz, 4K2K@24/30Hz, 4K2K@60Hz

  • HDMI Audio Formats

    PCM 2CH, LPCM 7.1/5.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X

  • ESD Protection

    Human body model - +/-8kV (Air-gap discharge), +/-4kV (Contact discharge)

Connections

Jump to...

  • Input ports

    1x HDMI Type A (19-pin female)
    1x Service (Micro USB, Update port)

  • Output ports

    8x HDMI Type A (19-pin female)

Mechanical

Jump to...

  • Power Supply

    Input: AC100 - 240V 50/60Hz
    Output: DC 12V/1A (US/EU standards, CE/FCC/UL certified)

  • Power Consumption

    6.15W

  • Operating Temperature

    14 - 122 Degree F (-10 - 50 Degree C)

  • Storage Temperature

    -4 - 140 Degree F (-20 - 60 Degree C)

  • Relative Humidity

    20 - 90% RH (no condensing)

Physical

Jump to...

  • Color

    Black

  • Material

    Metal Enclosure

  • Dimensions (W x D x H)

    9.57 x 4.02 x 0.63" (243 x 102 x 16mm)

  • Weight

    20.1 oz (572g)

Other

Jump to...

  • UPC Code

    880802002828

About DVDO HDMI Splitter

The DVDO-Splitter-18 18Gbps 1x8 HDMI Splitter is an advanced solution for splitting a single HDMI signal to 8 HDMI outputs synchronously. It supports up to 18Gbps bandwidth, HDMI 2.0b/HDCP 2.2 content up to 4K@60Hz 4:4:4. It can be set to COPY/AUTO EDID configuration and provides reliable and high quality HDMI distribution.

Applications
• Conference Rooms
• Education
• Hospitality
• Restaurants
• Digital Signage
• Retail
• Houses of Worship
• Residential

DVDO HDMI Splitter Features

  • HDMI 2.0b, HDCP 2.2 compliant
  • Supports 18Gbps bandwidth
  • Supports resolution up to 4K@60Hz 4:4:4
  • Supports HDR function
  • Supports COPY / AUTO EDID control
  • Compact design for easy and flexible installation

Warranty Information

This product has a limited warranty of 36 months.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Effortlessly share your 4K HDMI content across 8 displays with this reliable 1x8 splitter.
  • Enjoy stunning visuals with full 18Gbps bandwidth and HDR support for vibrant colors.
  • Benefit from HDCP 2.2 compliance, ensuring seamless playback of protected content on all screens.
  • Experience crystal-clear audio with support for advanced formats like Dolby Atmos and DTS:X.
  • Ideal for retail, hospitality, or home theater, this splitter simplifies your AV distribution.
  • Its durable metal enclosure and easy-to-use design provide long-lasting, dependable performance.

What's in the box:

  • DVDO 1x8 4K HDMI 18Gbps Splitter
  • 12V/1A DC Locking Power Adapter
  • User Manual
  • DVDO 3 Year Limited Warranty
