Datavideo SE-2200 HD Switcher Studio Kit, Includes SE-2200 Switcher, HDR-70 Recorder with Removable Drive Bay, ITC-100 Wired intercom System, CB-28 Tally Cable

SKU: DVSE2200SK MFR: SE2200SK
Earn VIP Reward Points

Key Features

  • Create seamless live productions with this HD video switcher's smooth transitions.
  • Record directly in HD with the included HDR-70 recorder, perfect for archiving events.
  • Enjoy low latency and reliable connection, ensuring a professional broadcast experience.
  • Streamline communication using the ITC-100 intercom system for clear team coordination.
  • Easily manage multiple video sources with 6 HD-SDI & 2 HDMI inputs on this video switcher.
  • Achieve high resolution video output with assignable SDI & HDMI ports for flexible setups.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$189.99

3 Year

$219.99

4 Year

$279.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Datavideo SE-2200 Specifications

  • Switcher: Video Standard

    HD

  • Switcher: Video Format

    1080i 50/59.94/60Hz
    576i 50Hz, 480i 59.94Hz
    720p 50/59.94/60 Hz

  • Switcher: Video Processing

    SDI: 4:2:2
    HDMI: YUV 4:2:2, RGB 4:4:4

  • Switcher: Input Routable / Crosspoint

    All 6, repeatable

  • Switcher: Video Input

    6x HD-SDI, 2x HDMI (on CH5 and 6)

  • Switcher: Computer Graphic Interface

    2 via HDMI

  • Switcher: Video output

    6x SDI Outputs assignable: AUX 1-4, PGM, PVW, PGM Clean and Multi-view
    2x HDMI assignable: PGM and Multi-view

  • Built-in Multi-view monitoring out

    2x HDMI

  • Switcher: Audio input

    4x Balanced XLR

  • Switcher: Audio output

    2x Balanced XLR

  • Switcher: Embedded audio support

    Input up to 16 channels, Output 4 channels

  • Switcher: A+V switching

    Yes

  • Switcher: DSK

    DSK support Lumakey and Linear key (Key / Fill)

  • Switcher: Picture in Picture

    2

  • Switcher: Logo Insertion

    2 (or 1 logo + 1 clock)

  • Switcher: Still Store

    6

  • Switcher: Effects

    FTB, Cut, 8 Wipe with border

  • Switcher: Transition Preview

    PiP and DSK

  • Switcher: Sync / Reference In/Out

    Built-in Genlock

  • Switcher: Tally Output

    D-sub 25pin, dual color

  • Switcher: PC Remote Control

    Via Ethernet (free Window software) or RS-422 / RS-232

  • Switcher: Special Functions

    6x6 Matrix seamless switch

  • Switcher: Chassis

    2 units, rack-mount mainframe

  • Switcher: Power

    DC 12V 32W

  • Switcher: Power Adapter

    100 to 240 VAC

  • Recorder: Video Standard

    HD and SD

  • Recorder: Video Format

    1080P 23.97/24Hz
    1080i 50/59.94/60Hz
    720P 50/59.94/60Hz
    525i/ 625i

  • Recorder: Supported Video Input Signal

    SDI

  • Recorder: Monitoring/ Playback output

    SDI (input loop thru)
    HDMI
    SDI (Out)

  • Recorder: Analog Audio I/p & Audio O/p

    2x Balanced XLR (Stereo pair)

  • Recorder: Embedded Audio

    Yes, both In and Out (8-CH on SDI and 4-CH on HDMI)

  • Recorder: Storage Medium

    2.5" Hard Drive / SSD, Max capacity 750GB

  • Recorder: Estimated Record Time

    SD: 22 (50Mbps) to 75 (8Mbps)
    HD: 10 (125Mbps) to 68 (10Mbps) (min per 10GB)

  • Recorder: Storage File System

    NTFS (read/write on Window, read only on MAC)

  • Recorder: Recorded File Format

    MXF OP1A, MOV

  • Video Recording Bit Rate/Color Sampling1

    MPEG2 Long GOP HD:
    10Mbps 4:2:0 1440x1080/1280x720
    25Mbps 4:2:0 1440x1080/1280x720
    35Mbps 4:2:2 1920x1080/1280x720
    50Mbps 4:2:2 1920x1080/1280x720
    65Mbps 4:2:2 1920x1080/1280x720
    120Mbps 4:2:2 1920x1080/1280x720

    MPEG2 Long GOP SD:
    8Mbps 4:2:0 720x480/720x576 (to be F/W upgrade)
    15Mbps 4:2:2 720x480/720x576
    30Mbps 4:2:2 720x480/720x576
    50Mbps 4:2:2 720x480/720x576

  • Video Recording Bit Rate/Color Sampling2

    MPEG2 I-Frame Only HD:
    80Mbps 4:2:2 1920x1080/1280x720
    100Mbps 4:2:2 1920x1080/1280x720
    125Mbps 4:2:2 1920x1080/1280x720

    MPEG2 I-Frame Only SD:
    25Mbps 4:2:2 720x480/720x576
    50Mbps 4:2:2 720x480/720x576

  • Recorder: Audio Recording Format

    Uncompressed PCM Sampling rate 48KHz 24bit

  • Recorder: Time code in/out

    Yes

  • Recorder: External Sync/ Genlock

    Yes, Black Burst and Tri-level with loop thru

  • Recorder: Power failure protection

    Content saved up to last second before power failure

  • Recorder: Chassis

    1RU 19" rackmountable

  • Intercom: Frequency Response

    550Hz to 3.6kHz < +/-3dB

  • Intercom: Total Harmonic Distortion

    < 3% (THD)

  • Intercom: Signal to Noise Ratio

    > 50dB

  • Intercom: Operating Range

    Up to 660' (201.17m) Between Base Station and Slave

  • Intercom: Connectors

    12V 1.5A Power Input
    2x 15-Pin Sub D Tally Connectors
    3.5mm Stereo Headphone/Mic Combo Jack
    1/4" Stereo Headphone Jack
    3-Pin XLR Light Socket
    XLR/TRS Combo Mic Input

  • Intercom: Speaker

    2.75 x 1.2" / 69.85 x 30.48mm, 3W, 32Ohms

  • Intercom: Operating Temperature

    41 to 104 deg. F / 5 to 40 deg. C

  • Intercom: Rack unit

    1RU

  • Tally cable: Connector Type

    25-pin DIN to 15-pin DIN

  • Tally cable: Length

    41" / 104.14cm

  • Switcher: Dimensions (W x H x D)

    Processor: 19.0 x 3.5 x 11.9" / 48.26 x 8.89 x 30.23cm
    Control Panel: 27.54 x 5.67 x 17.19" / 69.95 x 14.4 x 43.66cm

  • Switcher: Weight

    Processor: 19.84lbs / 9kg
    Control Panel: 10lbs / 4.54kg

  • Intercom: Weight

    4.2lbs / 1.91kg

About Datavideo SE-2200

Where professional video production meets superior technology, the SE-2200 HD Switcher Studio Kit stands out. This comprehensive kit includes the SE-2200 Switcher, HDR-70 Recorder with a removable drive bay, ITC-100 Wired Intercom System, and CB-28 Tally Cable.

The SE-2200 Switcher, housed in a convenient table-top rack, is a separate control panel and processor system that seamlessly switches between High Definition HD-SDI video signals and HDMI signals. With six inputs, this switcher is an ideal solution for events and meetings, offering versatility in three configurations: solo (Switcher), table-top (Studio Kit), or suitcase (Mobile Studio).

The ITC-100 wired intercom/tally system, included in the kit, comes with four belt packs, headsets, microphones, and tally lights. This system ensures smooth communication among crew members during production.

The kit also includes a hard drive recorder, the HDR-70, for saving the final output. This recorder features a removable drive bay, providing flexibility and convenience for your recording needs.

The SE-2200 Switcher is equipped with 16 wipe effects and mix (dissolve) capabilities, enhancing your production with a variety of transition options. The Tally Output feature ensures efficient Tally Light communication with crew members, while the Dual Picture-in-Picture functionality allows for creative video compositions.

The SE-2200 can also perform a Freeze Frame, capturing a still image from the video, and supports Lumakey, a feature that allows for the superimposition of video layers.

In summary, the SE-2200 HD Switcher Studio Kit is a comprehensive, high-quality solution for professional video production, offering a range of features and capabilities to meet your creative needs.

Datavideo SE-2200 Features

  • 6-input HD Switcher for versatile video production and live events
  • Dual Picture-in-Picture functionality for creative video compositions
  • 16 dynamic wipe effects with mix/dissolve transitions
  • Integrated wired intercom system with four belt packs for crew coordination
  • HDR-70 Recorder with removable drive bay for flexible recording options
  • Tally Output for efficient on-set communication with Tally Light system

Key Features

  • Create seamless live productions with this HD video switcher's smooth transitions.
  • Record directly in HD with the included HDR-70 recorder, perfect for archiving events.
  • Enjoy low latency and reliable connection, ensuring a professional broadcast experience.
  • Streamline communication using the ITC-100 intercom system for clear team coordination.
  • Easily manage multiple video sources with 6 HD-SDI & 2 HDMI inputs on this video switcher.
  • Achieve high resolution video output with assignable SDI & HDMI ports for flexible setups.

What's in the box:

  • Datavideo SE-2200 Processor
  • SE-2200 Control Panel
  • 12VDC Power Adapter and Cord
  • Base Station
  • 4x 65' Cables
  • 4x Headsets
  • 4x Beltpacks
  • Tally Light Set for 4 Users
  • HDR-70 HDD Recorder for SD/HD-SDI with Removable Drive Bay
  • 320 GB HDD
  • 2x HDD25 2.5 " Hard Disk Drive Enclosure
  • 2x Rack Mount Ears
  • Power Adapter & Cable
  • CB-28 Tally Cable
  • RKM-2000 Holder
  • Datavideo 2 Year Warranty (1 Year + 1 Year with Registration)
