Datavideo SE-650 HD 4-Channel Digital Video Switcher
See all Datavideo items

Datavideo SE-650 HD 4-Channel Digital Video Switcher

SKU: DVSE650

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?SOPHIA Z : it's for my customer. they requested it.Louis L : Someone recommend

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Datavideo SE-650 Specifications

  • Video Inputs

    2x HDMI
    2x HD-SDI

  • Video Outputs

    2x HDMI (HDMI 1 is user assignable / HDMI 2 is Multiview)
    1x HD-SDI (User assignable)

  • Audio Inputs

    1x Stereo RCA (L/R)
    2x Mono Microphone
    De-embedded Digital Audio (2 CH)

  • Audio Outputs

    1x Stereo RCA (L/R)
    1x Stereo headphone (Mini Jack with volume control)
    Embedded Digital Audio (2 CH / Channel 1 & 2)

  • Tally

    Yes / D-Sub 15 male connector

  • Software Update

    USB Port

  • Audio Fader

    5 VR (Variable Resistor)
    6 Channel (3 Pair) Audio Mixer

  • Audio LED Meter

    2 Rows (Left/Right)

  • Supported Resolutions

    1080i/50, 1080i/59.94, 1080i/60, 720p/50, 720p/59.94, 720p/60

  • Internal Processing

    YUV 4:2:2 10-bit

  • Keyers

    2 Keyers (2 Chroma Keyers); linear and luma keyer

  • Upstream Keyers

    2 (M/E Keyer & PIP)

  • Chroma Keyers

    2 High Quality Chroma Keyers; available in Keyer and PIP

  • PIP

    1x PIP with adjustable size, position, and crop. Border with adjustable width & color

  • Wipes

    32 Wipe Patterns such as Circle and Heart. Variable border width with Softness control.

  • Stills

    Any unused channel can also be used as a still buffer. Stills can be stored internally

  • Stinger Transitions

    Yes

  • Logo

    1

  • Operating Temperature

    0 to 50deg. C (32 to 122 deg. F)

  • Humidity

    10% to 80%

  • Power Consumption

    12V / 29W

  • Dimensions

    400 x 264 x 72mm (15.75 x 10.39 x 2.83")

  • Weight

    1.72kg (3.79 lbs)

  • UPC Code

    672255007181

About Datavideo SE-650

Where professional video production meets advanced technology, the Datavideo SE-650 HD 4-Channel Digital Video Switcher stands out. This high-quality, durable device is designed to cater to the needs of small scale video production, yet it doesn't compromise on delivering professional-grade performance.

Equipped with two HD-SDI and two HDMI inputs, the SE-650 supports a wide range of video formats, up to 1080i, ensuring compatibility with a variety of professional cameras and HDMI equipment. This user-friendly switcher also features two HDMI outputs and a user-assignable HD-SDI output, providing flexibility and convenience for live production switching.

Beyond its core functionalities, the Datavideo SE-650 boasts an integrated audio mixer, complete with microphone and unbalanced RCA audio inputs. This allows for seamless audio and video integration, enhancing the overall production quality.

The SE-650 is also packed with advanced tools that elevate your video production capabilities. These include Chroma key and Luma key for high-quality compositing, Picture-in-Picture (PiP) for simultaneous display of multiple video sources, a wipe generator for smooth transitions, a still store for image capture, and a tally system for on-air indication.

In essence, the Datavideo SE-650 HD 4-Channel Digital Video Switcher is a comprehensive solution for those seeking to produce high-quality, professional videos with ease and efficiency.

Datavideo SE-650 Features

  • 4 Input HD digital video switcher
  • Inputs: 2x HD-SDI, 2x HDMI
  • Outputs: 1x HD-SDI, 2x HDMI
  • Any Input can be used as a Frame store (Stills Store)
  • Assignable Outputs: Program (with LOGO), Clean Program (with out LOGO), Clean Preview (with out LOGO), Multiview
  • Frame Sync on each input
  • Flexible Mix/Effects Processor with 1 Upstream Keyer, supporting Chromakey & Linear/ Luma Key
  • 1 Upstream PIP, supporting Chromakey & Luma Key
  • Wipe Generator: 32 Wipe Patterns, including Circle & Heart - Borders & Softness Control
  • Full M/E Preview function
  • Logo insertion
  • XPT (Cross Point Assignment)
  • Tally Output
  • 6 Channel Audio Mixer
  • Audio inputs: 2x RCA Analogue (L/R), 2x Microphone
  • Audio outputs: 2x RCA Analogue (L/R), 1x Stereo headphone mini Jack
  • Audio em-bedded function
  • Multi-language support

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Elevate your live streams with this 4-channel HD digital video switcher.
  • Enjoy versatile compatibility with HDMI and HD-SDI inputs for seamless integration.
  • Create professional broadcasts with dual chroma keyers for stunning visual effects.
  • Achieve high video quality with internal 10-bit YUV 4:2:2 processing.
  • Use the intuitive controls and audio mixer for perfect sound and video balance.
  • Stream in real-time with confidence using reliable connectivity for uninterrupted broadcasts.

What's in the box:

  • Datavideo SE-650 HD 4-Channel Digital Video Switcher
  • AD Switch DC 12V with AC Cord
  • Datavideo Warranty
