edelkrone Pan Module for JibONE Camera

SKU: EDKCX

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the Pan Module for JibONE Camera?

The Pan Module for JibONE Camera is a motorized single-axis panning solution that can be attached to edelkrone JibONE, edelkrone Sliders & Dollies, and tripods. It offers an unlimited JibONE experience or ultimate panning ability for heavier camera setups.

Can the Pan Module for JibONE Camera be hand-controlled?

Yes, the Pan Module for JibONE Camera can be hand-controlled. You can manually adjust the pan angle with Pan PRO, eliminating the need for a remote control.

What is the carrying capacity of the Pan Module for JibONE Camera?

The Pan Module for JibONE Camera has a high carrying capacity and can support heavy professional cameras as well as the entire JibONE setup.

How does the Pan Module for JibONE Camera connect to other devices?

The Pan Module for JibONE Camera can connect wirelessly to JibONE, edelkrone Sliders & Dollies. This instant connection allows for quick automation and programming of creative camera motions.

Does the Pan Module for JibONE Camera require assembly?

No, the Pan Module for JibONE Camera does not require any tools or assembly. It can be set up in minutes for quick filming and scene changes.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

edelkrone Pan Module Specifications

  • Material

    CNC machined aluminum and stainless steel components

  • Mounting options

    3/8"-16 mounting port on bottom, 3/8"-16 mounting screw on camera plate

  • Recommended maximum setup load

    30 lbs (13.5kg) or less (Jib + Head + Camera + 4 kg Counterbalance weights)

  • Min. step size

    0.022 degree

  • Max. speed

    5 degree/sec when used with JibONE

  • Max. rotation

    Infinite x 360 Degree

  • Number of axes

    Single

  • Additional features

    Safety lock, Instant feedback screen

  • Supported fps

    All

  • Motor type

    Step motor with ultra high-res encoder

  • Power input

    1x LP-E6 type battery (battery not included) or DC Adapter (Does not charge batteries)

  • Battery life

    With x1 Canon LP-E6 battery (14.4 Wh) Operates 6 hours (continuously at full speed)

  • Can be paired with

    JibONE

  • Can be controlled via

    edelkrone App, Controller for edelkrone Moco

  • Mobile device connection

    2.4 GHz direct link for inter-device communication and BLE for pairing / mobile phone connection

  • App. compatibility

    iOS 11.0 or later & Android 5.0 or later

  • DC plug specs

    Voltage input: 100-240V, Voltage out: 9.0V, Current output: 2.2A, Polarization: positive center, Output connector: Barrel plug, 2.1mm I.D. x 5.5mm O.D x 9.5mm

  • Battery Info

    Optional, not included

  • Battery Material

    Lithium ion

  • Battery Type

    Non-universal

  • Battery Quantity

    1

  • Dinesions (W x D x H)

    4.33 x 5.31 x 2.36" (110 x 135 x 60mm)

  • Weight

    1.89 lbs (858g)

About edelkrone Pan Module

Why settle for ordinary when you can elevate your filming experience with the Pan Module for JibONE Camera This motorized single-axis panning solution, designed to seamlessly integrate with edelkrone JibONE, edelkrone Sliders & Dollies, and tripods, offers an unparalleled filming experience.

The Pan Module for JibONE Camera is not just an accessory; it's a game-changer. It allows you to achieve an unlimited JibONE experience or ultimate panning ability for heavier camera setups, setting you apart from the crowd.

One of the standout features of this module is its hand-controlled operation. With the Pan PRO, you can manually adjust the pan angle, eliminating the need for a remote control. This feature not only speeds up your workflow but also makes the entire process more intuitive.

Despite its compact design, the Pan PRO boasts a high carrying capacity. It is capable of supporting heavy professional cameras and the entire JibONE setup. This robust yet portable module is a testament to edelkrone's commitment to delivering high-quality, user-friendly products.

The Pan PRO is more than just an add-on; it's an upgrade. Designed to add a panning axis to JibONE, it can be easily attached between your tripod and JibONE to unlock a new axis. Pair it with the HeadPLUS for an unlimited motorized jib experience.

Setting up the Pan PRO is a breeze. It requires no tools or assembly and can be set up in minutes for quick filming and scene changes. It also features a locking mechanism for secure placement, eliminating the need for disassembly during relocation.

The Pan PRO is not just about power; it's about precision. It provides the necessary smoothness for macro shots and steady speed control when panning, thanks to its backlash-free mechanical design. It can also repeat any motion perfectly, making it ideal for visual effects.

As the newest member of the edelkrone ecosystem, the Pan PRO connects wirelessly to JibONE, edelkrone Sliders & Dollies. This instant connection allows for quick automation and programming of creative camera motions.

Whether you're looking for motorized camera panning motion or motorized jib panning motion for the entire JibONE setup, the Pan PRO has got you covered. It can carry camera setups of up to 30 lb and can be paired with JibONE for a truly immersive filming experience.

In conclusion, the Pan Module for JibONE Camera is more than just a tool; it's a pathway to unlimited creative possibilities.

edelkrone Pan Module Features

  • Works with JibONE, Sliders & Dollies
  • Remote + App controlled
  • High carrying capacity (Up to 30lb)
  • Can be hand-controlled
  • Ultra quiet operation

Key Features

  • Hand-controlled operation with Pan PRO for intuitive and speedy workflow
  • High carrying capacity to support heavy professional cameras and entire JibONE setup
  • Compact, portable design with easy setup and secure locking mechanism
  • Provides smooth, precise motions for macro shots and visual effects

What's in the box:

  • edelkrone Pan Module
  • LP-E6 Battery Plate
  • AC/DC Adapter
  • Allen key
  • edelkrone Lifetime Limited Warranty
