This item is no longer available.
Review Summary
IPS
LED
23.8" / 60 cm (604 mm diagonal)
1920 x 1080 (16: 9 aspect ratio)
527 x 296.4 mm
0.2745 x 0.2745 mm
16.77 million
178 deg. , 178 deg.
250 cd/m2
1000:1
5 ms (Gray-to-gray
D-Sub mini 15 pin x 1, DVI-D 24 pin x 1 (with HDCP), HDMI x 1 (with HDCP), DisplayPort x 1 (with HDCP)
31-68kHz, 59-61Hz (VGA Text: 69-71Hz)
31-81kHz, 55-76Hz
Separate
1 port for monitor control
2-port USB hub
USB 3.0
1.0 W +1.0 W
3.5 mm stereo jack
3.5 mm headphone jack
Volume, Power Save, Source (DisplayPort, HDMI)
AC 100 - 120 V / 200 - 240 V, 50 / 60 Hz
47W
12W
Less than 0.3W
Power Save (VESA DPM, DisplayPort Rev. 1.1a, and DVI DMPM), Eco Timer
FineContrast (Paper, Movie, sRGB, User1, User2)
Yes
Yes
English, French, German, Italian, Japanese, Simplified and Traditional Chinese, Spanish, Swedish
140 mm
35 deg. Up, 5 deg. Down
344 deg.
90 deg. (both clockwise and counter clockwise)
100 x 100 mm
TCO Displays 6.0, EPEAT Gold (US), TUV/Ergo- nomics (including ISO9241-307), TUV/GS, RCM, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA Energy Star, RoHS, WEEE, China RoHS, CCC, EAC
537.6 x 333.5 - 473.5 x 233 mm / 21.17 x 13.13 - 18.64 x 9.17"
Without Stand: 537.6 x 317.6 x 47.9mm / 21.17 x 12.50 x 1.89"
6.2kg / 13.67lbs
Without Stand: 3.8kg / 8.38lbs
690592038590




Fusion Design
World's Thinnest Bezels for Multi-Monitor Environments
The monitor features 1 mm ultra-slim bezels on the sides and top with black borders of 4.3 mm and a depth of a mere 47.9 mm. This makes for an attractive design that blends in with the desktop and reduces eye movement in a multi-monitor setup.
Say Goodbye to Tired Eyes
Clear View From All Angles
The monitor uses an LED-backlit IPS (in-plane switching) LCD panel with 178deg. viewing angle that minimizes color shift and contrast changes when viewing the screen at an angle.
Auto Brightness Control
To prevent eye fatigue, a brightness sensor called Auto EcoView detects the changes in the ambient brightness that occurs throughout the day and automatically adjusts the screen to the ideal brightness level.
Adjustable to Less Than 1% of Maximum Brightness
In a dimly-lit work environment, a monitor with low brightness settings is more comfortable to use. With its LED backlight, the monitor is adjustable to 1 cd/m2 which is less than 1% of the maximum.
Flicker-Free Images
Due to the way brightness is controlled on LED backlights, a small number of people perceive flicker on their screen which causes eye fatigue. The FleXScan EV series utilizes a hybrid solution to regulate brightness and make flicker unperceivable without any drawbacks like compromising color stability.
Less Blue Light Reduces Eye Fatigue
In the visible light spectrum, blue light has wave lengths adjacent to ultraviolet light. Compared to the factory preset setting of 6,500 K of typical LCD monitors, Paper Mode is closer to the spectral distribution with long reddish wavelengths so it reduces the amount of blue light, a cause of eye fatigue and helps prevent eyestrain when reading documents.
Lower Your Costs
LED Backlights - Less Power, Longer Life
Compared to CCFL backlights, LED backlights last longer and consume less power. They are also mercury-free for minimal environmental impact.
Reduce Power by up to 30%
A new feature called EcoView Optimizer 2 saves energy by up to 30% by reducing the backlight brightness and increasing the gain. To maintain image quality, EcoView Optimizer 2 only boosts the gain with a screen consisting mostly of dark content because the accompanying reduction in brightness is almost unperceivable.
Presence Sensor for Energy Savings
A presence sensor called EcoView Sense prompts the monitor to switch to power save mode when you are absent and then power on again when you return. It even works in a multi-monitor setup so all monitors remain on when you're at your desk.
5-Year Warranty
A manufacturer's 5-year warranty covers all components including the LCD panel to ensure a long service life. This warranty is 2-years or 67% longer than the standard 3-year warranty of most monitor brands for significantly lower running costs.
Simplify Screen Adjustment with EIZO-Developed Software
ScreenManager Pro for Personal Settings
ScreenManager Pro lets users adjust color and EcoView settings with the mouse and keyboard instead of the on-screen display menu. It also offers multimonitor matching which allows adjustments to be applied to all FleXScan monitors connected to a single PC.
EIZO Monitor Configurator for Administrators
EIZO Monitor Configurator lets system administrators control the settings of all FleXScan EV monitors with a USB connection. The settings of one monitor can be saved as an Xml file and can apply to other monitors via USB or office network.
