Elmo TT-12F Visual Presenter - Interactive Document Camera
See all Elmo items

Elmo TT-12F Visual Presenter - Interactive Document Camera

SKU: EL1378
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Elmo TT-12F Specifications

Camera

Camera

Jump to...

  • Image Pick-Up Device

    1/2.3" CMOS sensor 3,400,000 pixels

  • Effective Pixels

    4,168 (H) x 3,062 (V)

  • Frame Rate

    60 fps

  • Resolution

    Analog RGB: 800 (H) x 800 (V) TV lines or more

Optics

Jump to...

  • Zoom

    Powered, 12x optical

  • Lens

    F3.2-3.6, f=4.0 mm- 48.0 mm

  • Shooting Area

    Shooting Area 1080p: Max: 16 9/16" x 9 3/16" (420 x 233mm)
    Min: 1 15/16" x 1 1/16" (48.5 x 27.5mm)

    720p: Max: 16 9/16" x 9 3/16" (420 x 233mm)
    Min: 1 15/16" x 1 1/16" (48.5 x 27.5mm)

    SXGA: Max: 16 9/16" x 13 1/8" (420 x 334mm)
    Min: 1 15/16" x 1 1/2" (48.5 x 38.5mm)

  • Shooting Area (Contd.)

    WXGA: Max: 16 9/16" x 10 3/16" (420 x 259mm)
    Min: 1 15/16" x 1 3/16" (48.5 x 30.5mm)

    XGA: Max: 16 9/16" x 12 5/16" (420 x 313mm)
    Min: 1 15/16" x 1 7/16" (48.5 x 36.5mm)

  • Focus

    One-push Auto / Zoom Sync

Functions

Jump to...

  • White Balance

    Auto / One-Push / Fluorescent / Indoor / Outdoor

  • Image Mode

    Text1 / Text2 / Text3 / Graphics1 / Graphics2

  • Edge Enhancement

    Provided (only for graphics mode)

  • Pause

    Provided

  • Still Image Storage

    Provided

  • Movie Storage

    Provided

  • USB Image Output

    Provided (ELMO original, UVC (USB Video Class))

  • Digital Zoom

    12x

  • Gamma Setting

    Provided (only for graphics mode)

  • Graphical Osd (On-Screen Display)

    Provided

  • Slide Show

    Provided (image data)

  • Image Save

    SD memory card / SDHC memory card / USB flash drive

  • State Presetting

    Up to 3 user settings

  • Annotation

    Provided (CRA-1 use)

  • Brightness Control

    Manual

  • Support Functions

    Highlight, Mask, Scroll (in digital zoom), Mosaic, Split screen, PinP (Picture-in-Picture), Color filter, Microscope, Image rotation (0 Degree/180 Degree), Positive/negative conversion, Color/B&W selection

Interface

Jump to...

  • Input Selection

    Main / External

  • Output Terminals

    RGB output mini D-sub 15-pin connector, female x 1
    HDMI output terminal x 1
    Line Out terminal 3.5 mm-diameter stereo mini jack x 1

  • Input Terminals

    RGB input mini D-sub 15-pin connector, female x 1
    HDMI imput terminal x1
    Mic In/Line In terminal (shared), 3.5 mm-diameter stereo mini jack x1

  • Ext. Control Terminal

    USB device (2.0 compliant) (UVC Compliant) Mini-B receptacle x 1

  • Analog RGB Output

    1080p: 1,920 x 1,080 @ 60 Hz
    720p: 1,280 x 720 @ 60 Hz
    SXGA: 1,280 x 1,024 @ 60 Hz
    WXGA: 1,280 x 800 @ 60 Hz
    XGA: 1,024 x 768 @ 60 Hz

  • HDMI Output

    Image output: 1080p/720p
    Audio output: PCM 44.1 kHz sampling frequency

  • Memory Interface

    SD memory card slot x 1, USB host (2.0 compliant) Type A receptacle x 1

Lighting

Jump to...

  • Illumination Lamp

    White LED

Others

Jump to...

  • Security Slot

    Provided

  • Power Source

    12V DC (AC adapter AC 100 - 240V)

  • Power Consumption

    21 W (AC adapter included)

  • Dimensions (W x D x H)

    13.74 x 14.84 17" (349 x 377 x 432mm) (main unit only)

  • Weight

    Approx. 6.6 lbs (3kg)

Other

Jump to...

  • UPC Code

    008404105291

About Elmo TT-12F

Meet the most powerful TT Series Visual Presenter ever. The TT-12F offers stunning images in true 4K Ultra HD resolution at up to 30fps over both HDMI and USB 3.0 outputs. The exceptionally powerful 288x total zoom lens will never leave a small detail unnoticed. HDMI and RGB passthrough allow for easy connectivity for just about any auxiliary device.

Features

288x zoom in 4K Ultra HD
The TT-12F offers 288x digital zoom at 4K resolution, capturing video in True 4K Ultra HD at 30fps or Full HD at 60fps without any loss of quality.

Multiple Outputs
The TT-12F comes with Super Speed USB 3.0 for up to 4K resolution, HDMI, and RGB/VGA output options to connect seamlessly to a wide variety of devices. The TT-12F also allows for HDMI passthrough.

A3 Size Shooting Area
The TT-12F captures an area of up to A3 landscape.

Remote Control Dock
The TT-12F comes with a built-in remote control dock so you'll never misplace your remote control again.

Elmo TT-12F Features

  • UHD 4K Classroom Document Camera
  • 288x zoom in 4K Ultra HD
  • HDMI, USB, VGA Output; HDMI Pass-Through
  • A3 Size Shooting Area
  • Remote Control Dock

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • UHD 4K Classroom Document Camera
  • 288x zoom in 4K Ultra HD
  • HDMI, USB, VGA Output; HDMI Pass-Through
  • A3 Size Shooting Area
  • Remote Control Dock

What's in the box:

  • TT-12F Visual Presenter
  • Power Cable
  • AC Adapter
  • USB Cable
  • Remote Control
  • AAA Battery for Remote
  • Image Mate Software CD
  • Elmo 5 Year Limited Warranty
