Elation SIX+ BAR S 6x 20W RGBLA+UV LED IP65 Batten Fixture

SKU: ELSIX226 MFR: SIX226
Earn VIP Reward Points

Key Features

  • Create stunning light shows with full pixel control using this Elation LED batten fixture.
  • Achieve vibrant washes & dynamic effects with the RGBLA+UV color array for any event.
  • Enjoy seamless control via DMX, Art-Net, or sACN for professional lighting setups.
  • This durable IP65-rated Elation light is perfect for outdoor events, rain or shine!
  • Customize your stage presence with variable CCT from 2400K to 8500K for warm tones.
  • Experience easy setup with included accessories like safety cable and frost filter.
See More Product Details
Special Order?Estimated to Ship: 08/08/2025
Free Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$154.99

5 Year

$269.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Elation SIX+ BAR S Specifications

  • Source

    6x 20W RGBLA+ UV LEDs
    30,000 Hour Average LED Life

  • Photometrics

    Total Lumen Output:
    4,435 (Goniometer)
    CRI- 90.9
    TLCI- 80

  • Beam Angle

    No Lens: 20 Degree
    Included Frost: 30 Degree

  • Field Angle

    No Lens: 33 Degree
    Included Frost: 60 Degree

  • Effects

    Full Pixel Control
    Electronic Dimmer and Strobe
    Variable 16-bit Dimming Modes and Curves

  • Color

    RGBLA+ UV Color Array
    CMY Emulation
    Variable CCT 2400K - 8500K
    Dim-to-Warm Fade
    Virtual Gel Swatch Book

  • Control / Connections

    13 DMX Channel Modes (1ch, 3ch, 6ch, 9ch, 13ch, 16ch, 16ch, 22ch, 22ch, 34ch, 46ch, 82ch, 36ch)
    6 Six Bar 500 Emulation DMX Channel Modes (6ch, 7ch, 11ch, 13ch, 18ch, 36ch)
    4 Button Control Panel, LED Display
    Aria 2x Wireless Device ManagementIP65 5pin XLR DMX In/Out
    IP65 RJ45 Ethernet In/Out (Art-Net, sACN, KlingNet)
    IP65 Locking Power Cable In/Out

  • Electrical / Thermal

    AC 100-240V - 50/60Hz
    110W Max Power Consumption
    Power Thru Capacity: @110V: 16 Units; @240V: 32 Units
    5 to 113 Degree F (-15 to 45 Degree C)
    BTU/hr (+/- 10%) 375.1

  • Approvals / Ratings

    CE | cETLus | IP65 | FCC | UKCA

  • Dimensions (L x W x H)

    6.9 x 19.69 x 8.11" (175.5 x 500 x 206mm)

  • Weight

    14.88 lbs (6.75kg)

  • UPC Code

    810008264485

About Elation SIX+ BAR S

Let your creativity shine with the Elation SIX+ BAR S 6x 20W RGBLA+UV LED IP65 Batten Fixture, a cutting-edge solution in LED batten lighting that merges advanced LED color technology with a versatile design for unparalleled artistic expression. As an enhanced version of Elation's popular SixBar 500, the SIX+ BAR S elevates performance with increased output, an expanded color spectrum, and superior light quality. Featuring 20W RGB+Lime+Amber+UV LEDs and a remarkable CRI of 90.9, this fixture delivers a vibrant array of colors, providing a beautifully homogenized wash of light with exceptional color accuracy.

The SIX+ BAR S is engineered with a sophisticated optical system that ensures even light distribution, while its proprietary RGBLA+UV engine produces high-fidelity whites and vivid primary colors without color fringing. Its extra-large 50 mm lenses are perfect for direct view applications, and the ability to control each cell individually offers endless design possibilities. Measuring half a meter in length, this fixture houses six powerful RGBLA+UV LEDs, delivering over 4000 lumens of luminous output.

With fully adjustable color temperature ranging from 2400K to 8500K, CMY emulation, and a virtual gel library, lighting designers can effortlessly access a wide spectrum of LED colors, including perfectly blended whites. The efficient SixBar emulation mode ensures seamless color matching and DMX control with existing SixBar fixtures. The integrated accessory slot accommodates the included frost filter, with optional ND filters and other optics available for enhanced versatility. Additionally, the fixture comes with a glare shield, ideal for wall wash applications.

Designed for maximum flexibility, the SIX+ BAR S features an innovative housing that allows for end-to-end interconnection and includes integrated L track on three sides for adaptable mounting and positioning. Trunnions can be attached to the L track at multiple points, optimizing placement around objects or obstacles. This fixture is perfect for a wide range of productions and can be easily integrated into installation applications, serving as a versatile wash light, uplight, wall/cyc wash, accent light, direct view pixel strip, and more.

Encased in a robust, fully IP65-rated housing, the SIX+ BAR S is built to withstand any environment, whether indoors or outdoors. Its C4-M marine-grade coating offers protection against harsh conditions, including salty coastal air. The fanless convection cooling system ensures silent operation, making it ideal for noise-sensitive settings. Control options include DMX/RDM, Art-Net, sACN, and KlingNet protocols, along with proprietary Aria x2 wireless device management for simplified system setup and maintenance. Experience the full potential of LED batten lighting and unleash your creative spirit with the Elation SIX+ BAR S.

Elation SIX+ BAR S Features

  • 6x 20W RGBLA+UV LED Array
  • >4000 Lumens, 90.9 CRI
  • Extra Large 50mm Lenses
  • Beam Angle: 30 Degree x 14 Degree (Frost Filter Included)
  • Full Pixel Control
  • Completely Fanless Cooling
  • Integrated L Track for Flexible Mounting
  • Unique End-to-End Interconnection System
  • Art-Net, sACN and KlingNet Support
  • IP65 Rated

Warranty Information

This product has a limited warranty of 24 months.

Key Features

  • Create stunning light shows with full pixel control using this Elation LED batten fixture.
  • Achieve vibrant washes & dynamic effects with the RGBLA+UV color array for any event.
  • Enjoy seamless control via DMX, Art-Net, or sACN for professional lighting setups.
  • This durable IP65-rated Elation light is perfect for outdoor events, rain or shine!
  • Customize your stage presence with variable CCT from 2400K to 8500K for warm tones.
  • Experience easy setup with included accessories like safety cable and frost filter.

What's in the box:

  • Elation SIX+ BAR S 6x 20W RGBLA+UV LED IP65 Batten Fixture
  • Safety Cable
  • IP65 Locking Power Cable
  • Frost Filter
  • Glare Shield
  • Fixture Interconnect Slice
  • Elation 2 Year Limited Warranty
