Questions & Answers

FAQ

Can the EXALUX CONTROL ONE be used with any DMX fixtures?

Yes, the EXALUX CONTROL ONE is designed to be compatible with all fixtures that feature Lumen Radio's CRMX technology, making it a versatile tool for controlling various DMX fixtures.

How can I update the DMX library on the EXALUX CONTROL ONE?

The DMX library on the EXALUX CONTROL ONE can be easily updated using the USB port. The device supports regularly released updated libraries, making it future-proof and ready to control the latest fixtures.

Does the EXALUX CONTROL ONE offer wireless operation?

Yes, the EXALUX CONTROL ONE can be converted into a wireless DMX transmitter if needed. You just need to launch the TX App. It can also be used in a fully wireless mode when paired with the EXALUX CONNECT RX200N and RX100S receivers.

What types of controls does the EXALUX CONTROL ONE offer?

The EXALUX CONTROL ONE offers hybrid controls, combining hardware and touch controls that can be used simultaneously. This makes it easy to operate even in outdoor and cold conditions.

Can I record lighting sequences with the EXALUX CONTROL ONE?

Yes, the EXALUX CONTROL ONE features a small DMX recorder that can record sequences of 80 seconds from the DMX input. This allows you to record and play back your most useful effects on set.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Exalux CONTROL ONE Specifications

Apps & Features

Apps & Features

Jump to...
  • Lighting Control

    Universal fixture controller

  • DMX TX

    Application enabling the re-routing of DMX input to DMX output and CRMX

  • Recorder

    Real time DMX recorder
    8 memories
    up to 80s recording @44Hz max

  • Memory Player

    Fader : 8 banks memory player
    Fixture : 8 banks memory player
    Recorder : 8 banks memories / 1 time / loop mode

  • Update

    Firmware and DMX fixtures update through the USB port

Technical

Jump to...
  • Interface

    TFT 5.0'', 800x480 pixels, Capacitive Touch, Super bright
    Master & settings (knobs)
    Memory store/restore
    CRMX Link, Black-out, Lock

  • Power Consumption

    Min : -2,1W (Screen Off)
    MAX : -4,2W (Screen & CRMX On)
    STANDBY : -0,025W

  • Housing / Mounting

    Aluminum, black painting

  • IP Rating

    IP30

  • Certifications

    CE, RoHS

Radio Interface

Jump to...
  • Standard / Technology

    CRMX by Lumen Radio

  • Frequency

    2.402 - 2.480 GHz

  • Antenna

    Omnidirectional
    2.4GHZ 2.0dBi, SMA

  • RF Output

    20 dBm (100mW)

  • RF Modulation

    GFSK
    Up to 300m (depending on the transmitter and the environment)

DMX Interface

Jump to...
  • Protocol

    DMX512-A

  • Universe support

    1

  • DMX frame rate

    0.8-830Hz

  • End to end latency

    < 5ms

  • DMX Input

    Neutrik XLR 5 pins Female

  • DMX Output

    Neutrik XLR 5 pins Male

USB Interface

Jump to...
  • Standard

    USB Device

  • Ports

    micro-USB, type B

Power Supply

Jump to...
  • USB

    5VDC

  • XLR 4 PINS

    10VDC-24VDC

Operating Conditions

Jump to...
  • Storage Temperature

    Min: -22 Degree F (-30 Degree C)
    Typ: 77 Degree F (25 Degree C)
    Max: 176 Degree F (80 Degree C)

  • Operating Temperature

    Min: -4 Degree F (-20 Degree C)
    Typ: 77 Degree F (25 Degree C)
    Max: 140 Degree F (60 Degree C)

Battery

Jump to...
  • Battery Info

    Optional, not included

  • Battery Material

    Lithium ion

  • Battery Type

    Non-universal

  • Battery Quantity

    1

Physical

Jump to...
  • Dimensions

    7.1 x 1.96 x 9.1" (180 x 50 x 232mm)

  • Weight

    24.69 oz (700g) (without battery)

About Exalux CONTROL ONE

Be in command of your lighting setup with the EXALUX CONTROL ONE, an all-in-one wireless DMX controller. Designed to simplify and enhance your control over popular DMX fixtures, this device is an indispensable tool for cinema sets and small TV studio setups. Whether you prefer a wired or wireless setup, the CONTROL ONE can adapt to your needs, even transforming into a wireless DMX transmitter with the launch of the TX App.

The CONTROL ONE is compatible with all fixtures featuring Lumen Radio's CRMX technology, making it a versatile addition to your equipment. Pair it with the EXALUX CONNECT RX200N and RX100S receivers for a fully wireless experience, offering you complete freedom in controlling your DMX fixtures.

Dubbed as the 'Swiss army knife of DMX', the CONTROL ONE is packed with five apps in a sleek, compact enclosure. This lightweight device can be comfortably worn around the neck, allowing you to configure your lights while standing next to the camera or monitoring the screen.

Future-proof your lighting setup with the CONTROL ONE's upgradable features. Regularly updated libraries ensure that your device is always ready to control the latest fixtures. Simply update your DMX library using the USB port.

The CONTROL ONE offers hybrid controls, combining hardware and touch controls that can be used simultaneously. Its user-friendly interface is designed to withstand outdoor conditions, and the controls can be locked to prevent any accidental changes.

With a small DMX recorder capable of recording sequences of 80 seconds from the DMX input, the CONTROL ONE allows you to record and play back your most useful effects on set. Power it with a V-Lock battery, an external PSU, or a small PowerBank, thanks to its wide supply range (+5 to 28VDC). Switching from one power mode to another won't disconnect your DMX devices from the unit.

Based on Lumen Radio CRMX technology, the CONTROL ONE ensures DMX fidelity without any latency. It features all the essentials you need to operate your favorite fixtures, including an advanced DMX console, a basic DMX console, a DMX recorder, a memory manager, and a Wireless DMX transmitter.

The CONTROL ONE also includes a Fader App, Fixture App, Tx App, and Recorder App, each designed to provide you with maximum control over your lighting setup. With the ability to control up to 40 various DMX fixtures and record 512 DMX channels in real time, the CONTROL ONE truly puts your lighting needs at your fingertips.

Exalux CONTROL ONE Features

  • 5-in-1 DMX tools
  • 1 DMX universe
  • 8 tact switches to save/restore memories
  • Black out function
  • Lock / unlock function
  • Runs up to 7h with a 10Ah/36Wh PowerBank
  • Fully compatible with EXALUX CONNECT

Key Features

  • Take control with the Exalux CONTROL ONE DMX controller for seamless lighting.
  • Wirelessly manage your lighting setup with CRMX technology, up to 300m range.
  • Record and playback real-time DMX sequences with 8 memory banks for dynamic shows.
  • Use as a universal fixture controller, update firmware via USB for the latest features.
  • The 5" capacitive touch screen offers intuitive control over your DMX lighting.
  • Compact & durable aluminum housing ensures reliability for on-the-go lighting control.

What's in the box:

  • Exalux CONTROL ONE All-In-One Wireless DMX Controller
  • D-Tap to XLR 4-Pin Female Cord
  • USB Cable
  • Exalux 1 Year Limited Warranty
