Eminence Speakers Beta-12CX 12" 250W Coaxial Speaker Driver, 8 Ohm
Eminence Speakers BETA12CX: Picture 1 thumbnail
Eminence Speakers BETA12CX: Picture 2 thumbnail
Eminence Speakers BETA12CX: Picture 3 thumbnail
Eminence Speakers BETA12CX: Picture 4 thumbnail
See all Eminence Speakers items
22% Off

Eminence Speakers Beta-12CX 12" 250W Coaxial Speaker Driver, 8 Ohm

SKU: EMBETA12CX MFR: BETA12CX
Be the first to review this itemAsk a Question
$124.99
$159.99
Save: $35 (22%)
Earn VIP Reward Points

Key Features

  • Experience sound accuracy with the Eminence Beta-12CX coaxial speaker driver.
  • Achieve optimal frequency response in your studio monitors with this 12" driver.
  • Enjoy robust build quality and lasting performance with Eminence speaker components.
  • Customize your studio monitors with a driver that handles 250W power effectively.
  • Minimize distortion for clean audio; ideal for professional recording environments.
  • Fine-tune your sound; this coaxial speaker driver offers versatile connectivity options.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

1 Year

$15.99

2 Year

$23.99

3 Year

$35.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Eminence Speakers BETA12CX Specifications

General

General

Jump to...

  • Nominal Basket Diameter

    12" (305mm)

  • Nominal Impedance

    8 Ohm

  • Power Rating

    Music Program: 500W
    Watts: 250W

  • Resonance

    47 Hz

  • Usable Frequency Range

    57 Hz - 4.6 kHz

  • Sensitivity

    97.3 dB

  • Magnet Weight

    38 oz (1.7kg)

  • Gap Height

    0.312" (7.9mm)

  • Voice Coil Diameter

    2.0" (51mm)

Thiele & Small Parameters

Jump to...

  • Resonant Frequency (fs)

    47 Hz

  • DC Resistance (Re)

    5.42 Ohm

  • Coil Inductance (Le)

    0.64 mH

  • Mechanical Q (Qms)

    5.64

  • Electromagnetic Q (Qes)

    0.52

  • Total Q (Qts)

    0.48

  • Compliance Equivalent Volume (Vas)

    120.94L (4.27 cu ft)

  • Peak Diaphragm Displacement Volume (Vd)

    188.6 cc

  • Mechanical Compliance of Suspension(Cms)

    0.30 mm/N

  • BL Product (BL)

    10.79 T-M

  • Diaphragm Mass Inc. Airload (MMs)

    1.34 oz (38g)

  • Efficiency Bandwidth Product (EBP)

    90

  • Maximum Linear Excursion (Xmax)

    0.13" (3.50mm)

  • Surface Area of Cone (Sd)

    0.58 sq ft (538.9 sq cm)

  • Maximum Mechanical Limit (Xlim)

    0.4" (10.4mm)

Mounting Information

Jump to...

  • Recommended Enclosure Volume

    Sealed: 26.90-70.79L (0.95-2.50 cu ft)
    Vented: 32.85-158.58L (1.16-5.60 cu ft)

  • Driver Volume Displaced

    2L (0.071 cu ft)

  • Overall Diameter

    12.03'' (305.6mm)

  • Baffle Hole Diameter

    11.07'' (281.2mm)

  • Front Sealing Gasket

    Yes

  • Rear Sealing Gasket

    Yes

  • Mounting Holes Diameter

    0.25'' (6.4mm)

  • Mounting Holes B.C.D.

    11.59'' (294.4mm)

  • Depth

    4.47" (113.5mm)

  • Weight

    7.80 lb (3.54kg)

Materials of Construction

Jump to...

  • Coil Construction

    Copper voice coil

  • Coil Former

    Kapton former

  • Magnet Composition

    Ferrite magnet

  • Core Details

    Tapered Coax

  • Basket Materials

    Pressed steel basket

  • Cone Composition

    Paper cone

  • Cone Edge Composition

    Cloth cone edge

  • Dust Cap Composition

    Screened cloth dust cap

Other

Jump to...

  • UPC Code

    876358000135

About Eminence Speakers BETA12CX

Recommended for professional audio as a mid-bass in either vented, or sealed satellite or floor monitor enclosures. Also works nicely in vented two-way enclosures used for small coverage areas.

The data for this coaxial woofer was calculated with the ASD:1001 driver screwed into the woofer, but not active.

Eminence Speakers BETA12CX Features

  • Coaxial design for extended HF
  • HF device sold separately
  • Made in the USA

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Experience sound accuracy with the Eminence Beta-12CX coaxial speaker driver.
  • Achieve optimal frequency response in your studio monitors with this 12" driver.
  • Enjoy robust build quality and lasting performance with Eminence speaker components.
  • Customize your studio monitors with a driver that handles 250W power effectively.
  • Minimize distortion for clean audio; ideal for professional recording environments.
  • Fine-tune your sound; this coaxial speaker driver offers versatile connectivity options.

What's in the box:

  • Beta-12CX 12 " 250W Coaxial Speaker Driver (8 Ohm)
  • Eminence Speakers 7 Year Limited Warranty
