Elite Screens ezFrame Specifications

  • Diagonal Size

    135" (343cm)

  • Aspect Ratio

    16:9

  • Material

    AcousticPro 1080P3

  • Case Color

    Black

  • Gain

    1

  • Viewing Angle

    180 Degree

  • Overall Width

    122.4" (311cm)

  • Overall Height

    70.9" (180.1cm)

  • Frame Width

    2.4" (6.1cm)

  • Frame Depth

    1.6" (4cm)

  • Dimensions (H x W)

    66.1 x 117.7" (167.6 x 297.2cm) (View area)

  • Weight

    30.6 lbs (13.9kg)

  • UPC Code

    848448000899

About Elite Screens ezFrame

The EZ-Frame Series is Award winning fixed frame projector screen with full tension uniformity. It offers AcousticPro 1080P3 screen materials model (sound transparent).

Design and Installation
• Anodized black aluminum frame with black velour surfacing to enhance the appearance with the stylish masked border that absorbs projector light overshoot
• Easy to assemble and install in minutes
• Sliding wall mounts ensure the installation is properly centered

AcousticPro 1080P3
The AcousticPro 1080P3 is an acoustically transparent perforated weave fabric front projection material. The angular weave eliminates the moire effect while presenting warm neutral colors for today's high definition 1080P (1920x1080) and 4K UHD projectors. The AcousticPro1080P3 allows speaker placement behind while allowing an exceptional acoustically transparent performance.

• Acoustically Transparent Matte White (perforated weave)
• Gain: 1.0
• Superb off-axis luminance
• Designed for 1080P (1920x1080) projector resolutions
• Detachable black backing eliminates backlighting artifacts from light bleed-through (only available on Sable Frame and ezFrame Series products)
• Mean attenuation of -3.09 dB
• Compatible with today's 1080P/4K UHD Projectors

Elite Screens ezFrame Features

  • 135-inch Diagonal, 16:9 Aspect Ratio. View Size: 66.2" H x 117.7" W. Overall Size: 70.9" H x 122.4" W x 1.6" D.
  • Moir -Free screen material: AcousticPro 1080P3, 1.0 Gain. Angular weaved, acoustically transparent front projection screen material with 160 degree viewing angle. 4K Ultra HD and Active 3D Projection Ready. Offers superb off-axis luminance and optimal color neutrality.
  • Features a sleek, black velvet-coated frame that absorbs projector overshoot and increases picture contrast. 2.36" width frame.
  • Sliding wall brackets that allow screen to slide horizontally for a properly centered installation are included.
  • 2-Year / 3-Year ENR-G, Manufactures Warranty by Elite Screens' an ISO9001 manufacturer since 2004 and Lifetime Tech Support by Email, Web Chat or Toll Free Phone Call by Elite's Professional Service Team.

Key Features

  • Fixed Frame Acoustic Sound Transparent Material

What's in the box:

  • ezFrame Series AcousticPro 1080P3 135" 16:9 Fixed Frame Projector Screen
  • Mounting Hardware
  • Elite Screens 2 Year Limited Warranty
