EVGA 700W BQ Semi-Modular Power Supply, 80 Plus Bronze Efficiency

SKU: EV110BQ0700V

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

EVGA BQ Power Supply Specifications

  • Compatibility

    ATX 24pin Power Supply Tester (Single)

  • Cable Length

    ATX Cable: 1x 600mm
    EPS Cable: 1x 600mm
    PCIe Cable: 1x 600mm, 700mm (m), 1x 600mm, 700mm
    SATA Cable: 2x 450mm, 570mm, 690mm
    Four-Pin Peripheral Cable: 1x 450mm, 570mm, 690mm + 810mm (Floppy)
    Floppy Adapter: 1x
    AC Power: 1x 1500mm (m)

  • Modular Cable Type

    Semi

  • Connector Quantity

    1x 24pin (20+4) ATX
    1x 8pin (4+4) EPS (CPU)
    4x 8pin (6+2) PCIe
    6x SATA
    3x Four-Pin Peripheral
    1x Floppy

  • Input Voltage

    100-240 VAC

  • AC Input

    12-6A

  • Input Frequency Range

    50 - 60 Hz

  • Efficiency

    85% Typical

  • Max Output

    +5V Rail at 20A, 130W Maximum
    +3.3V Rail at 20A, 130W Maximum
    +12V Rail at 58.3A, 699.6W Maximum
    -12V Rail at 0.3A, 3.6W Maximum
    +5Vsb Rail at 2.5A, 12.5W Maximum

  • Total output

    700W

  • Japanese Capacitors

    Main

  • ECO Mode

    No

  • MTBF

    100,000 Hours

  • Approvals

    TUV, CB, CE, FCC, RCM, cTUVus, BSMI, CCC, WEEE, RoHS
    Compliance with ErP Lot 6 2013 Requirement

  • Fan Size / Bearing

    120mm Fluid Dynamic Bearing

  • Dimensions (H x W x L)

    3.3 x 5.9 x 5.5" (85 x 150 x 140mm)

  • Weight

    5 lbs (2.27kg)

  • UPC Code

    843368051372

About EVGA BQ Power Supply

Great Quality, Great Value
Introducing the next generation in value; the EVGA BQ series. These power supplies take some of the best features from EVGA's award winning power supply lineup, like a 120mm fan with near silent operation and modular cables to make one of the best values today in high performance power supplies.

Ultra-Quiet
The Teflon nano-steel-bearing fan on these PSUs allowS for near-silent operation, even under the toughest loads.

Excellent Performance
85% efficiency or higher under typical loads with the high-quality Japanese capacitors that also ensure long-term reliability.

Single +12V Rail
A single +12V rail offers the best power output, rail stability and compatibility with the latest hardware.

Modular
Modular design allows for some cables to be removed from the power supply for ease of installation and customization. You can leave out unnecessary cables to reduce case clutter and maximize case airflow.

80 Plus Bronze Rated Efficiency
80 Plus Bronze certification ensures your power supply isn't wasting power and turning said power into excess heat. Under typical loads these power supplies are 85% more efficient or higher.

EVGA BQ Power Supply Features

  • Quiet and Intelligent Auto Fan for near-silent operation
  • Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), and SCP (Short Circuit Protection)
  • 80 PLUS Bronze certified, with 85% efficiency or higher under typical loads

Key Features

  • Quiet and Intelligent Auto Fan for near-silent operation
  • Heavy-duty protections, including OVP, OCP, OPP, SCP , and OTP
  • 80 PLUS Bronze certified, with 85% efficiency or higher under typical loads

What's in the box:

  • EVGA 700W BQ Semi-Modular Power Supply
  • EVGA 5 Year Limited Warranty
