EVGA SuperNOVA Specifications

Cable Length

Cable Length

Jump to...
  • ATX Cable

    1x 600mm

  • EPS Cable

    2x 750mm

  • PCIe Cable

    4x 750mm, 2x 750mm, 900mm

  • SATA Cable

    4x 550mm, 650mm, 750mm

  • Four-Pin Peripheral Cable

    2x 550mm, 650mm, 750mm

  • Floppy Adapter

    1x 100mm

  • AC Power

    1x 1800mm

  • Modular Cable Type

    Full

  • Molex to FDD

    1x

Connector Quantity

Jump to...
  • 24 Pin ATX

    1x

  • EPS (CPU)

    2x 8-Pin (4+4)

  • PCIe

    8x 8-Pin (6+2)

  • SATA

    12x

  • Four-Pin Peripheral

    6x

  • Floppy

    1x

  • Input Voltage

    100-240 VAC

  • AC Input

    15-8A

  • Input Frequency Range

    60/50 Hz

  • Efficiency

    90% or Higher Typical

  • Max Output

    +3.3V Rail at 24A, 120W Maximum
    +5V Rail at 24A, 120W Maximum
    +12V Rail at 108.3A, 1299.6W Maximum
    -12V Rail at 0.5A, 6W Maximum
    +5Vsb Rail at 3.0A, 15W Maximum

  • Total Output

    1300W

General

Jump to...
  • Operating Temperature

    32 to 122 Degree F (0 Degree to 50 Degree C)

  • Japanese Capacitors

    100%

  • ECO Mode

    Yes

  • MTBF

    100,000 Hours

  • Approvals

    TUV, CB, CE, FCC, RCM, cTUVus, BSMI, CCC, WEEE, RoHS
    Compliance with ErP Lot 3 2014 Requirement

  • Fan Size / Bearing

    135mm Fluid Dynamic Bearing

  • Dimensions (H x W x L)

    3.38 x 5.90 x 7.87" (86 x 150 x 200mm)

  • Weight

    8.20 lbs (3.72kg)

  • UPC Code

    843368052522

About EVGA SuperNOVA

The New Gold Standard for Performance and Value
• Fully Modular
• Tighter 12V Voltage Regulation
• Quiet Fan with EVGA ECO Mode

The Super NOVA G+ PSU
Enter the SuperNOVA G+, the new and improved fully-modular power supply line-up from EVGA with an 80+ Gold Efficiency rating. These power supplies pick up where the award-winning EVGA 1600 G2 and 1300 G2 power supplies left off and continue the tradition of EVGA quality and performance.

Additionally, the SuperNOVA G+ power supplies feature a cleaner internal layout to increase airflow, a Variable Resistor module (to increase voltage stability), two DC to DC modules for more efficient power switching on all models, EVGA ECO Mode, a full suite of power supply protections.

Quiet and Long-Lasting Fans
Fluid Dynamic Bearings reduce the wear and tear on a fan's bearing, reduce noise, and feature a longer-lasting, life than dual ball bearing fans.

Tighter 12V Load Regulation
The SuperNOVA G+ is loaded in many areas, including a single 12v. rail, 100% Japanese capacitors, VR module, and DC to DC converter on all SuperNOVA G+ power supplies. this results in over 90% efficiency, 0.61% 12v. load regulation, and stable power to all connected devices.

Up To 35% Quieter Under Load
By combining quiet and long-lasting fan bearings with an optimized fan curve and with a cleaner internal layout, the 1300 G+ power supply reduces noise by up to 35%, compared to the 1300 G2 power supplies.

Gold-Rated Efficiency
80 Plus certification ensures your power supply isn't wasting power and turning it into excess heat. Under typical load, this power supply is 90% efficient or higher.

100% Japanese Capacitors
Get the most reliability and greatest performance with the use of the highest possible quality Japanese capacitors.

Fully Modular Design
A fully modular design allows cables to be removed from the power supply for ease of installation and removal. You can also leave off unnecessary cables to reduce case clutter and maximize case airflow.

Tight Voltage Regulation (<1%)
A single +12V rail offers the best power output, rail stability and compatibility with the latest hardware. EVGA SuperNOVA 1300 G+ provide up to 108.3A on a single rail!

Quiet and durable Fan bearings with EVGA ECO mode
A high-quality 135mm fluid dynamic bearing fan gives the SuperNOVA G+ an excellent thermal and acoustic profile, and its high reliability ensures a long PSU lifetime. With EVGA ECO Mode, your power supply will remain silent under medium to low loads.

To Protect and To Serve
This PSU will cover your circuits with complete protection: OCP, OVP, OTP, OPP, SCP and UVP.

EVGA SuperNOVA Features

  • 80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC-240VAC) efficiency or higher under typical loads
  • Fully Modular to reduce clutter and improve airflow
  • 100% Japanese Capacitors ensure long-term reliability
  • Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
  • DC-DC Converter improves 3.3V/5V stability
  • 135mm Fluid Dynamic Bearing Fan for ultra-quiet operation and increased lifespan
  • EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads

Key Features

  • 80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC-240VAC)
  • Fully Modular to reduce clutter and improve airflow
  • Heavy-duty protections, including OVP, UVP, OCP, OPP, SCP and OTP
  • 100% Japanese Capacitors ensure long-term reliability
  • EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads
  • DC-DC Converter improves 3.3V/5V stability

What's in the box:

  • EVGA SuperNOVA 1300W G+ Fully Modular Power Supply
  • Molex to FDD Adapter
  • 2x 3 Molex Cables
  • 4x 3 SATA Cables
  • 2x 2 x 8(6+2)-Pin PCI-E VGA Cables
  • 4x 8(6+2)-Pin PCI-E VGA Cables
  • 2x 8(4+4)-Pin EPS/ ATX 12V CPU Cables
  • 20+4-Pin ATX Cable
  • 4x Mounting Screws
  • User Manual
  • EVGA 10 Year Limited Warranty
