EVGA SuperNOVA 1000W P3 Fully Modular Power Supply, 80 Plus Platinum Efficiency

SKU: EV22P31000X1

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

EVGA SuperNOVA Specifications

Cable Length

Cable Length

Jump to...
  • ATX Cable

    1x 600mm

  • EPS Cable

    2x 750mm

  • PCIe Cable

    2x 750mm, 900mm 4x 750mm

  • SATA Cable

    4x 550mm, 650mm, 750mm

  • Four-Pin Peripheral Cable

    1x 550mm, 650mm, 750mm, 850mm

  • Floppy Adapter

    1x 100mm

  • AC Power

    1x 1500mm

  • Modular Cable Type

    Full

Connector Quantity

Jump to...
  • 24-Pin ATX

    1x

  • EPS (CPU)

    2x 8-Pin (4+4)

  • PCIe

    8x 8-Pin (6+2)

  • SATA

    12x

  • Four-Pin Peripheral

    4x

  • Floppy

    1x

  • Input Voltage

    100-240 VAC

  • AC Input

    12-6A

  • Input Frequency Range

    60/50 Hz

  • Efficiency

    92% (115VAC) / 94% (220VAC-240VAC) or Higher Typical

  • Max Output

    +3.3V Rail at 25A, 125W Maximum
    +5V Rail at 25A, 125W Maximum
    +12V Rail at 83.3A, 1000W Maximum
    -12V Rail at 0.5A, 6W Maximum
    +5Vsb Rail at 3A, 15W Maximum

  • Total Output

    1000W

General

Jump to...
  • Operating Temperature

    32 to 122 Degree F (0 Degree to 50 Degree C)

  • Japanese Capacitors

    100%

  • ECO Mode

    Yes

  • MTBF

    100,000 Hours

  • Approvals

    TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
    Compliance with ErP Lot 3 2014 Requirement

  • Fan Size / Bearing

    135mm Fluid Dynamic Bearing

  • Dimensions (H x W x L)

    3.38 x 5.90 x 7.09" (86 x 150 x 180mm)

  • Weight

    9 lbs (4.08kg)

  • UPC Code

    843368059149

About EVGA SuperNOVA

A New Generation of Platinum Power
EVGA SuperNOVA power supplies are well-known for their extreme efficiency, performance and reliability. EVGA's dedication to performance has forged its newest higher-wattage power supply platform: the EVGA Super NOVA P3 Series. With these new power supplies, EVGA took the best features of the award-winning P2 lineup and made them even better. The SuperNOVA P3's smaller size, improved performance and a new Fluid Dynamic Bearing fan give you ultra-quiet performance with an increased lifespan.

Smaller Size Big Performance
A reduced size does not mean reduced performance with the EVGA SuperNOVA P3 power supplies. At only 180mm long, this makes the P3 one of the smaller 80 Plus Platinum power supplies on the market today, while offering improved performance and features.

Fluid Dynamic Bearing Fan
Better performance, quieter operation and a longer lifespan.

Next Gen Performance
Next-generation deserve Next-generation performance. The EVGA SuperNOVA P3 takes the already efficient P2 series and makes it even better with improved efficiency and lower ripple. These power supplies are over 92% efficient!

Whisper Quiet
EVGA ECO mode means the power supply is completely silent during low to medium loads. This is one quiet power supply!

Fully Modular Design
Use only the cables you need, reducing cable clutter and improving case airflow.

EVGA SuperNOVA Features

  • 80 PLUS Platinum certified, with 92% (115VAC) / 94% (220VAC-240VAC) efficiency or higher under typical loads
  • 100% Japanese Capacitors ensure long-term reliability
  • Fully Modular to reduce clutter and improve airflow
  • Full-bridge LLC Resonant Converter and DC-DC design leads to tight voltage regulation and low ripple & noise
  • Fluid Dynamic Bearing Fan for ultra-quiet operation and increased lifespan
  • EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads
  • Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
  • Active Power Factor Correction

Key Features

  • 80 PLUS Platinum certified, with 92% (115VAC) / 94% (220VAC-240VAC)
  • 100% Japanese Capacitors ensure long-term reliability
  • Fully Modular to reduce clutter and improve airflow
  • Full-bridge LLC Resonant Converter and DC-DC design leads to tight voltage regulation
  • Fluid Dynamic Bearing Fan for ultra-quiet operation and increased lifespan
  • EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads

What's in the box:

  • EVGA SuperNOVA 1000W P3 Fully Modular Power Supply
  • Molex to FDD Adapter
  • 4 Molex Cable
  • 4x 3 SATA Cables
  • 2x 2 x 8(6+2)-Pin PCI-E VGA Cables
  • 4x 8(6+2)-Pin PCI-E VGA Cables
  • 2x 8(4+4)-Pin EPS/ ATX12V CPU Cables
  • 24-Pin ATX Cable
  • 24-Pin PSU Tester
  • 4x Mounting Screws
  • User Manual
  • EVGA 10 Year Limited Warranty
